Patch Release Note
Patch 54266-01
For AR440S and AR441S ADSL Routers
Introduction
This patch release note lists the issues addressed and enhancements made in
patch 54266-01 for Software Release 2.6.6 on existing models of AR440S and
AR441S ADSL routers. Patch file details are listed in
Table 1: Patch file details for Patch 86264-03.
Base Software Release File
GUI Resource File Names
Patch Release Date
Compressed Patch File Name
Compressed Patch File Size
This release note should be read in conjunction with the following documents:
Release Note: Software Release 2.6.6 for AR440S ADSL Routers (Document
Number C613-10412-00) available from
documentation/documentation.html.
AR400 Series router Documentation Set for Software Release 2.6.6 available
on the Documentation and Tools CD-ROM packaged with your switch, or
from www.alliedtelesyn.co.nz/documentation/documentation.html.
Errata to the Documentation: Software Release 2.6.6 for AR440S ADSL
Routers (Document Number C613-06011-00) available from
www.alliedtelesyn.co.nz/documentation/documentation.html.
WARNING: Using a patch for a different model or software release may cause
unpredictable results, including disruption to the network. Information in this
release note is subject to change without notice and does not represent a
commitment on the part of Allied Telesyn International. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesyn International
can not accept any type of liability for errors in, or omissions arising from the
use of this information.
Table
1.
54-266.rez
d440Se14.rsc (AR440S)
d441Se14.rsc (AR441S)
21-Oct-2004
54266-01.paz
161304 bytes
www.alliedtelesyn.co.nz/
Simply connecting the world

Advertisement

loading

Summary of Contents for Allied Telesis AR441S

  • Page 1 This patch release note lists the issues addressed and enhancements made in patch 54266-01 for Software Release 2.6.6 on existing models of AR440S and AR441S ADSL routers. Patch file details are listed in Table 1: Patch file details for Patch 86264-03.
  • Page 2 Level 4 AR441S ADSL Router Hardware Platform Patch 54266-01 includes support for the AR441S ADSL (Annex B) router. Each AR441S router consists of a base CPU card, enclosure, and power supply. The base CPU card supports: ■ One Asymmetric Digital Subscriber Line (ADSL) Annex B port.
  • Page 3: Power Supply

    Patch 54266-01 Main system Main features of the AR440S routers are: ■ 300 MHz RISC processor. ■ 64 MBytes of SDRAM. ■ 16 MBytes of flash memory (1 MByte reserved for boot block code). ■ 5 x 10/100 Mbps full duplex, Layer 2 switched Ethernet LAN ports. All LAN ports have Auto-MDI, however if Auto-MDI is turned off, then all ports are hardwired as MDI-X.
  • Page 4 This patch, together with the base software release, supports the AR441S ADSL (Annex B) router. With this patch, the AR440S ADSL port operates in Annex A mode for ADSL over POTS, and the AR441S ADSL port operates in Annex B mode for ADSL over ISDN.
  • Page 5 PCR: 40625 The GUI on the AR441S did not display a port map on the System Status page. This issue has been resolved. GUI resource file d441Se14.rsc or later is also required to display the port map on the AR441S.
  • Page 6 Features in 54266-01 Patch Release Note PCR: 40647 Module: ETH Level: 2 When a virtual Eth interface was created over ATM, for example, using the command: create eth=0 over=atm=0.1 and a VPN configuration was applied directly to that Eth interface, the router ran out off buffers and caused a fatal exception under heavy reception load.
