PS-18YC/A
DC 18V Plug-in Power Supply
PS-18YC/A
DESCRIPTION:
The PS-18YC/A is an 18V DC power supply with a
1.2A output. It is Class 2, compact in size, and plugs
in to a standard AC outlet. The DC output connects
directly to the device it is powering with spade
connectors.
UL and CSA listed, designed for indoor use only.
Mounting brackets are included for wall mounting.

SPECIFICATIONS:

Input Voltage:
Output Voltage:
Output Current:
Power Consumption:
Wiring Connection:
Dimensions (H x W x D):
Intercom Solutions For
Communications and Security
Aiphone Communication Systems • 1700 130th Ave. NE • Bellevue, WA 98005
(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • http://www.aiphone.com
AC 120V, 60Hz
DC 18V
1.2 A
30W
Spade Connectors
Red = Pos.; Blue = Neg.
6-1/4" x 3-5/16" x 1-3/4"
SPECIFICATIONS
PRODUCT APPLICATIONS:
The PS-18YC/A can be used for the
following Aiphone Communication
systems:
• MK-1MD/A
• MY-1CD
• MYH-CU or MYH-CUB
(1 PS-18YC/A per 2 monitors)
• TB-M audio-only system
PS-18YCA-SS 99306 0299
Printed in USA
