10-Port 100BASE-FX and 20-Port 10/100BASE-TX Fast Ethernet Layer 2 Switching Modules Quick Start Guide
Table 2 Mapping the 24-port GEN SFM and the 10-port FEN Switching Module to the 8-slot Chassis
Chassis Number of SFM
Slot Backplane Ports
Number Allocated to Slot
1 4; up to 2 can be
accessed by this
module
2 4; up to 2 can be
accessed by this
module
3 4; up to 2 can be
accessed by this
module
4 4; up to 2 can be
accessed by this
module
5 4; up to 2 can be
accessed by this
module
6 4; up to 2 can be
accessed by this
module
7 Reserved for an SFM
8 Reserved for an SFM
10-port Switching SFM Backplane Port
Module Backplane Numbers Assigned to
Port Numbers Chassis Slot
11 1
12 2
11 5
12 6
11 9
12 10
11 13
12 14
11 17
12 18
11 21
12 22
Not applicable Not applicable
Not applicable Not applicable
9
SFM LED Numbers
Assigned to Backplane
Port Numbers
1
2
3
4
5
6
7
8
9
10
11
12
Not applicable
Not applicable
