14 10-Port 100BASE-FX and 20-Port 10/100BASE-TX Fast Ethernet Layer 2 Switching Modules Quick Start Guide
Table 7 Mapping the 9-port GEN SFM and the 10-port FEN Switching Module to the 7-slot Chassis
Chassis Number of SFM
Slot Backplane Ports
Number Allocated to Slot
1 1
2 1
3 1
4 1
5 1
6 1
7 Reserved for an SFM
Table 8 Mapping the 9-port GEN SFM and the 10-port FEN Switching Module to the 8-slot Chassis
Chassis Number of SFM
Slot Backplane Ports
Number Allocated to Slot
1 1
2 1
3 1
4 1
5 1
6 1
7 Reserved for an SFM
8 Reserved for an SFM
10-port Switching SFM Backplane Port
Module Backplane Numbers Assigned to
Port Numbers Chassis Slot
11 1
11 2
11 3
11 4
11 5
11 6
Not applicable Not applicable
10-port Switching SFM Backplane Port
Module Backplane Numbers Assigned to
Port Numbers Chassis Slot
11 1
11 2
11 3
11 4
11 5
11 6
Not applicable Not applicable
Not applicable Not applicable
SFM LED Numbers
Assigned to Backplane
Port Numbers
1
2
3
4
5
6
Not applicable
SFM LED Numbers
Assigned to Backplane
Port Numbers
1
2
3
4
5
6
Not applicable
Not applicable
