Alpine TME-M710 Owner's Manual

6.5-inch wide lcd monitor
Hide thumbs Also See for TME-M710:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual
FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/
PARA USO EN AUTOMÓVILES/SOLO PER L'UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/
TME-M710
ALPINE ELECTRONICS, INC.
1-1-8 Nishi Gotanda,
Shinagawa-ku, Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road, Toronto,
Ontario M3J 2M9, Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
Qingdao Dongli Xinhaiyuan
Printing Co., Ltd.
No.17, jiushuidong road,
Qingdao, China
6.5-INCH WIDE LCD MONITOR
• OWNER'S MANUAL
Please read before using this equipment.
• BEDIENUNGSANLEITUNG
Lesen Sie diese Bedienungsanleitung bitte vor
Gebrauch des Gerätes.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• ISTRUZIONI PER L'USO
Si prega di leggere prima di utilizzare il
attrezzatura.
• ANVÄNDARHANDLEDNING
Innan du använder utrustningen bör du läsa
igenom denna användarhandledning.
•
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS GmbH
Frankfurter Ring 117, 80807 München,
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K., LTD.
Fletchamstead Highway,
Coventry CV4 9TW. U.K.
Phone 0870-33 33 763
Germany
R
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile, Z.I. Paris
Nord II, B.P. 50016, 95945, Roissy
Charles de Gaulle Cedex, France
Phone 01-48 63 89 89
ALPINE ITALIA S.p.A.
Viale C. Colombo 8,
20090 Trezzano Sul Naviglio (MI), Italy
Phone 02-48 47 81
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava) - APDO 133, Spain
Phone 945-283588
Designed by ALPINE Japan
Printed in China (S)
68-02278Z74-A
EN
DE
FR
ES
IT
SE
CH

Advertisement

Table of Contents
loading

Related Manuals for Alpine TME-M710

Summary of Contents for Alpine TME-M710

  • Page 1 • ANVÄNDARHANDLEDNING Innan du använder utrustningen bör du läsa igenom denna användarhandledning. • ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ELECTRONICS FRANCE S.A.R.L. 1-1-8 Nishi Gotanda, 161-165 Princes Highway, Hallam (RCS PONTOISE B 338 101 280) Shinagawa-ku, Tokyo 141-0031, Japan Victoria 3803, Australia 98, Rue de la Belle Etoile, Z.I.

  • Page 2: Table Of Contents

    ENGLISH Contents Installation and Connections Operating Instructions Warning ............11 WARNING Caution ............11 WARNING ..........2 Precautions ............12 CAUTION ........... 3 Installation ............13 PRECAUTIONS ......... 3 Connections ............ 16 Basic Operation Screen Display ON/OFF ........4 Adjusting the Volume ......... 4 Switching the Source .........

  • Page 3: Warning

    WARNING DO NOT WATCH VIDEO WHILE DRIVING. WARNING Watching the video may distract the driver from looking ahead of the vehicle and cause an accident. This symbol means important instructions. Failure to heed them can result in serious INSTALL THE PRODUCT CORRECTLY SO THAT THE injury or death.

  • Page 4: Caution

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Fuse Replacement Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or When replacing the fuse(s), the replacement must be of the nearest Alpine Service Centre for repairing.

  • Page 5: Basic Operation

    Basic Operation Switching the Screen Position If the screen is out of position when, for example, navigation system is connected to the AUX IN 1 or AUX IN 2 terminal by using the RCA extension cable, switch the screen position. Switch the mode to AUX1 or AUX2 to display the navigation screen.

  • Page 6: Switching The Display Mode

    Switching the display mode Adjusting Press the DISP button. Press and hold the SELECT button for at least 2 Each press of the button will cycle through the seconds. modes as follows: Adjustment screen will appear. Press the SELECT or DISP button and select WIDE CINEMA NORMAL...
  • Page 7 Basic Operation 7 Dimmer adjustment (DIMMER) 3 Color depth adjustment (COLOR) Change depth can be adjusted from –15 AUTO : Turning on/off the headlight switches (MIN) to +15 (MAX). the screen brightness between * Adjustment cannot be made in the DIMMER HI LEVEL and DIMMER LO NAVIGATION (RGB connection) mode.
  • Page 8 q Beep tone setting (BEEP) After completing adjustments, press and hold the SELECT button for at least 2 seconds. The screen will return to the normal mode. • If no operation is made for 10 seconds after selecting a mode to be adjusted, the adjustment mode will be cleared.
  • Page 9 Base Operation Remote Control Sensor Remote sensor • Receives the remote control signal from connected ALPINE products such as navigation and DVD players.

  • Page 10: Information

    Alpine dealer. Screen is out of position. No function or display. • Navigation system is connected by using the RCA extension cable.

  • Page 11: Specifications

    Information Specifications MONITOR Screen Size 6.5-type Display System Low reflection rear projection type TN liquid crystal panel Drive System Active matrix drive, normally white display Number of Picture Elements 280,800 pcs. (H:1200 x V:234 dots) Effective Number of Picture Elements 99.99% or more Light Source Internal optical system (U- type cold cathode fluorescent...

  • Page 12: Installation And Connections

    Installation and Connections Before installing or connecting the unit, please DO NOT DAMAGE PIPE OR WIRING WHEN read the following and pages 2 and 3 of this DRILLING HOLES. manual thoroughly for proper use. When drilling holes in the chassis for installation, take precautions so as not to contact, damage or obstruct pipes, fuel lines, tanks or electrical wiring.

  • Page 13: Precautions

    When in doubt, consult your ALPINE dealer. • The TME-M710 uses female RCA-type jacks for connection to other units having RCA connectors. You may need an adaptor to connect other units. If so, please contact your authorized ALPINE dealer for assistance.

  • Page 14: Installation

    Installation Installing AV Interface Unit Attaching with screws This Unit can be placed inside the trunk, on the 1. Place the unit on the location chosen for installa- kick panel of the front passenger's seat or tion. underdash. However, to avoid unnecessary 2.
  • Page 15 Installation and Connections Attaching the monitor and stand (for Check the sticking position. European customers only) 1 Temporarily fasten the stand with gum tape. 2 Loosen the adjustment screws, and adjust to a • For customers in other countries: safe, viewable position. The stand is not included.
  • Page 16 Remove the main unit from the stand. Remove the mount from the stand and stick it to the dashboard etc.. Remove any dirt on the place to install, using the supplied cloth. Fixing screws (M4 x 12 Supplied) If the place of attachment is curved, then bend this part...

  • Page 17: Connections

    Installation and Connections Connections Make connections correctly. Improper connections may cause a fire or operation failure. Basic connection...
  • Page 18 34Remote control output lead (White/Brown) • If you add an optional noise suppressor, To remote control input lead of ALPINE products connect it as far away from the unit as used in the system. possible. Your Alpine dealer carries various...
  • Page 20 Stimmen Sie dem Kontakt Q10.Haben Sie dieses Alpine- compare it with other sign your name in the indicated durch Alpine zu, so würden wir Sie Gerät vor dem Kauf mit brand? space and return the card. Any bitten, in dem dafür vorgesehenen Feld 1.
  • Page 21 2. Sustitución cette fiche, et en l’envoyant à solicitada es voluntario. Si Vd. ↓ ↓ Alpine, vous acceptez que ces • Marque précédente • ¿Sustitución de marca anterior? nos la remite, será utilizada de remplacée? 1. Instalado en la fábrica informations soient utilisées par...
  • Page 22 1. No richiesta di una Vostra opinione circa i 2. Due o tre volte prodotti o i servizi forniti da Alpine. Se Q10.Nell’acquistarlo, avete siete d’accordo, Vi preghiamo di paragonato questo ritornarci il formulario completato prodotto ad un’altra...
  • Page 23 Ich stimme dem Kontakt durch Alpine für Informations- und Befragungszwecke zu. J’accepte les termes de cette carte d’information produit Alpine. Estoy conforme con los términos de la tarjeta de información sobre producto de Alpine. Accetto i termini della scheda informazioni prodotti Alpine.
