Summary of Contents for Alpine INE-AW409S

  • Page 2: Table Of Contents

    Contents Operating instructions ..................- 1 - Tools that may be required ................- 3 - Spare Parts list ....................- 3 - General operation of the status bar ..............- 4 - 1.1 Common shortcut keys .................. - 4 - 1.2 Drop-down menu ...................

  • Page 3: Operating Instructions

    Stop using immediately if any problems occur Failure to do so may result in personal injury or damage to the product. Please return the product to an authorized Alpine dealer or nearby Alpine service center for repair. This product is only suitable for vehicles with a 12V negative ground Otherwise, accidents such as fires may occur.
  • Page 4 +60°C and20°C. Maintenance If you encounter any problems, do not attempt to repair it yourself. Please return the product to an authorized Alpine dealer or nearby Alpine service center for repair. Installation location This device cannot be installed in any of the following locations: ’...

  • Page 5: Tools That May Be Required

    Tools that may be required (depending on the vehicle) Panel removal Phillips Socket Electric drill tools screwdriver Cross screwdriver socket spanner Spanner Wire cutter cable clamp Wire stripper Multimeter Oscilloscope Spare Parts list Intelligent Vehicle-mounted networking System x1 Wire kit x1 *Disposal of electronic products should take place through appropriate recycling channels in order to reduce e-waste pollution.

  • Page 6: General Operation Of The Status Bar

    General operation of the status bar 1.1 Common shortcut keys 1. Home button [ ]: In non-main interface, click the home button icon to return to the main interface. 2. Back button [ ]: In non-main interface, click the back button icon to return to the previous interface.

  • Page 7: Introduction To Main Interface Functions

    Introduction to main interface functions 2.1 Main interface and application interface 1. After the machine starts up, it defaults to the main menu page, which mainly displays shortcuts to commonly used functions. Users can also adjust the layout of this page according to their preferences. Click the "Mode Switch" icon to enter the large icon mode.

  • Page 8: Introduction Of Main Functions

    Introduction of main functions 3.1 Radio Click the "Radio" icon to enter the radio interface. ① Stored station list. ② RDS function. ③ Band: Click to pull down and select from FM1/FM2/FM3/AM1, which offers 5 band options, defaulting to FM1. ④...

  • Page 9: Music

    Introduction of main functions 3.2 Music Click the "Music" icon to enter the music playback interface. ① Current playback information area: Click on ⑨ to switch between displaying song title and artist name, spectrum, and lyrics. ② Source switching: Switch between local music and Bluetooth music. ③and ④...

  • Page 10: Mixer

    Introduction of main functions 3.3 Mixer 1. Click the "Mixer" icon to enter the sound effects interface. In the equalizer mode, you can choose the Custom mode to adjust the frequencies of treble, midrange, and bass in three segments. You can also choose from system presets like Normal, Pop, Rock, Classic, and Jazz.

  • Page 11: Videos

    Introduction of main functions 3.4 Videos Click the "Video" icon to enter the video interface. 1. Button explanations: ① List of folders. ② Playlist. ③ Play progress bar. ④ Full-screen/half-screen playback switch. ⑤ Play the previous video. ⑥ Play/Pause. ⑦ Play the next video. 2.

  • Page 12: Photo

    Introduction of main functions 3.5 Photo Click the "Photo" icon to enter the Photo list interface. 1. Photo list: You can swipe left or right to browse folders. 2. Viewing Photo: When viewing Photo, pinch out with two fingers to zoom in on the Photo;...

  • Page 13: Bluetooth Phone

    Introduction of main functions 3.6 Bluetooth phone Click the "Bluetooth Phone" icon to enter the "Dialing" interface. When the phone Bluetooth is successfully connected to the main unit Bluetooth, input the phone number by touching the numeric keypad on the screen, then touch the dial icon [ ] to make a call.

  • Page 14: Navigation

    Introduction of main functions 3.7 Navigation Click the [Navigation] icon to enter the navigation interface. 1. Google Maps is an electronic mapping service provided by Google, including detailed satellite photos. In Google Maps, you can view real-time traffic information, nearby locations, and other information. Press the home button ] to exit the navigation interface and switch to the main interface.

  • Page 15: Easy Connection

    Introduction of main functions 3.8 Easy connection 1. Easy Connection is a technology and product that connects mobile phones with car infotainment systems. Through Easy Connection, users can project the contents of their phones onto the car's infotainment system, providing a more convenient and enriched user experience.

  • Page 16: Setup

    Introduction of main functions 3.9 Setup 1. Network ① WLAN connection Turn on the WLAN switch to start detecting nearby WLAN networks, displaying a list of available networks. If there is a [ ] icon next to the WLAN in the list, it means that the correct password needs to be entered to connect.
  • Page 17 Introduction of main functions 3. Sound setting ① Reverse Media Volume: When reversing, the media volume is played at a percentage of the original volume; adjustment range: 0~100%.; adjustable range: 0~100%. ② System Volume: Adjustment range: 0~30. When the system volume is set to 0, the system is muted, and a mute icon is displayed in the top left corner.
  • Page 18 Introduction of main functions 9. Language and input method ① Select text language, supporting 15 language packs. ② Set input method, choose between Android keyboard or third-party input method. 10. System ① Click on [System Restart], a dialog box prompts for confirmation, and after confirming, the system automatically shuts down and restarts.

  • Page 19: Help-Frequently Asked Questions

    Help-frequently asked questions 1. Unable to connect phone Bluetooth to the car Bluetooth? If Bluetooth connection fails, you can first turn off the phone's Bluetooth, then turn it back on and search again before reconnecting. If it still doesn't work, you can click on the Bluetooth settings reset, wait a few seconds, then pair and connect again.
