Getting Started with
pcXset
Release 5.0
Published April 2005
http://www.3com.com/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the pcXset - NBX - PC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3Com pcXset - NBX - PC

Summary of Contents for 3Com pcXset - NBX - PC

  • Page 1 Getting Started with pcXset Release 5.0 Published April 2005 http://www.3com.com/...
  • Page 2 3Com Corporation. Marlborough, MA 3Com Corporation reserves the right to revise this documentation and to make changes in content from time 01752-3064 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change.

  • Page 3: Table Of Contents

    ONTENTS ETTING TARTED WITH PC Overview Computer Requirements Installing the pcXset Software Configuring the pcXset Software Customizing pcXset’s Display Configuring Network Settings Configuring Advanced Settings Editing the Access Button Labels and Tooltip Pop-ups Keyboard Shortcuts Troubleshooting Audio Buffers Need Adjusting Audio Sounds Distorted Audio Stream Error DTMF Tones Echo Back to the Analog Line Card...

  • Page 5: Getting Started With Pc Xset

    You use the computer’s mouse and keyboard to operate the pcXset controls. 3Com recommends that you use a USB headset with your computer. Do not use the computer’s built-in speaker and microphone due to sound quality issues.

  • Page 6: Computer Requirements

    Windows XP. RAM — 32 MB (Windows 98), 64 MB (Windows 2000) ■ Video display — 640 x 480 pixels with 16 colors minimum. 3Com ■ recommends 800 x 600 pixels with 256 colors or greater. Network — An Ethernet network adapter.

  • Page 7: Installing The Pcxset Software

    Installing the pcXset Software Installing the You install the pcXset software from the NBX Resource Pack CD. pcXset Software Each NBX system is shipped with one pcXset license. To use more than one pcXset Soft Telephone on a system, you must purchase additional pcXset licenses and enter the license key into the NBX system.

  • Page 8: Configuring The Pcxset Software

    Software the Call Processor and with the computer on which it is installed. To configure the pcXset software: 1 Select Start > 3Com NBX > NBX pcXset Configuration Wizard. The Configuration Wizard window appears (Figure Figure 1 Configuration Wizard Window...
  • Page 9 Configuring the pcXset Software Table 1 Windows Access Buttons Windows Configuration Type Button Multimedia Control Panel — Displays Multimedia properties for your PC. Volume Control — Allows you to set the volume for speaking and listening using the pcXset application. Network Control Panel —...

  • Page 10: Customizing Pcxset's Display

    ETTING TARTED WITH PC Customizing pcXset’s After you launch pcXset, you can set the pcXset display: Display 1 Select pcXset Tools > Options > Display. See (Figure Figure 2 Options Dialog Box - Display Tab...
  • Page 11 Configuring the pcXset Software 2 Select from the following display types: Windows style — This Windows application-style appearance ■ (Figure 3) is recommended for computers with a video card capable of displaying only 256 colors. Figure 3 Windows-style Display...
  • Page 12 ETTING TARTED WITH PC Large NBSet or Small NBSet — You can set this realistic telephone ■ display (the classic NBX Business Telephone as shown in Figure 4) to large or small to suit your preference. To display only the telephone image on the screen, select Display >...

  • Page 13: Configuring Network Settings

    Configuring the pcXset Software telephone. This substitution makes the pcXset software sound more like a PC application. Configuring Network In the Network tab (Figure 5), you can customize or adjust the network Settings settings that you applied in the Configuration Wizard. Figure 5 Options Dialog Box - Network Tab...

  • Page 14: Configuring Advanced Settings

    ETTING TARTED WITH PC Configuring Use the Advanced tab (Figure 6) to adjust your audio parameters and Advanced Settings communications strategy. Figure 6 Options Dialog Box - Advanced Tab Tone Volume — Allows independent volume control of dial tone, ■ dialing, and DTMF tone sounds (that is, telephone audio tones) which are generated when you press digits to dial a telephone number.
  • Page 15 Configuring the pcXset Software You can also access the Volume Control program by clicking the Volume Control icon (see Table 1) in the NBX pcXset Configuration Wizard. You can set and save a set of mixer state values for use with the pcXset application.
  • Page 16 ETTING TARTED WITH PC system. When you use Layer 3, the pcXset application requires the IP address of the NBX system. You specify this setting using the pcXset Configuration Wizard, or using the Network tab of the Options dialog box. When you use Layer 3, you must also specify the version of your NBX software.

  • Page 17: Editing The Access Button Labels And Tooltip Pop-Ups

    Editing the Access Button Labels and Tooltip Pop-ups Editing the Access You can edit the labels to the right of the Access buttons on both the Button Labels and NBX Telephone display and the Windows style display. You can add brief Tooltip Pop-ups text that describes the feature or speed dial that you have assigned to the button.

  • Page 18: Keyboard Shortcuts

    ETTING TARTED WITH PC Keyboard Shortcuts Table 2 lists the keyboard shortcuts you can use instead of clicking telephone control buttons with the mouse. Table 2 Keyboard Shortcuts Press Key To Select 0 through 9 Digits 0 through 9 Star Hash or pound F1 through F12 Line Appearance Buttons L1 through L12...

  • Page 19: Audio Buffers Need Adjusting

    Troubleshooting that 3Com recommends that you use your system’s USB audio capabilities rather than using sound card audio. Audio Buffers Need Choppy audio occurs during telephone conversations or during the audio Adjusting test in the Configuration Wizard, or there are delays in audio playback during telephone conversations.
  • Page 20 ETTING TARTED WITH PC The following messages appear during an audio test, microphone test, or during pcXset startup: Error code: [80044802H] Error running audio stream from engine. Could be caused by accidentally running pcXset and the configuration wizard at the same time. A similar message may appear in the log file: ERROR: XXXXX [80044802H] Error running audio stream from engine.

  • Page 21: Dtmf Tones Echo Back To The Analog Line Card

    Troubleshooting 3 Use Windows Sound Recorder to verify that you can play the wave files. See the solution under “Full-Duplex Errors”, later in this guide, for more information. DTMF Tones Echo The pcXset software cannot make external calls through any Analog Line Back to the Card port, but calls to internal extensions are successful.

  • Page 22: Incorrect Ip Address For The Call Processor

    ETTING TARTED WITH PC applications at once. Play a wave file in one application while recording in another application. If you get an error message, your audio card does not support full-duplex audio. Solution Use a USB audio headset. Incorrect IP Address The following message appears during pcXset startup or after you click for the Call Processor Test on the IP Info tab of the Configuration Wizard.
  • Page 23 Troubleshooting ERROR: XXXXX [80046000H] This error has occurred in the Communications object. Please contact your technical support representative. Description This error occurs if the system cannot open the packet driver (Layer 2). Solution 1 Select Start > Options > Control Panel. 2 The next steps depend on your operating system: Windows NT —...

  • Page 24: The Pcxset Software Won't Initialize

    ETTING TARTED WITH PC If the NBX Packet Driver entry exists, click the Bindings tab to determine if the driver has been bound to the network adapters. If not, try uninstalling and reinstalling the driver. The pcXset Software If the pcXset software does not initialize, a message like the following Won't Initialize may appear: ERROR: [80046000H]...

  • Page 25: Pc Standby Mode Causes Pcxset Calls To Be Missed

    Troubleshooting PC Standby Mode The pcXset application does not wake a PC from standby mode on an Causes pcXset Calls incoming call, so the user misses incoming calls. to be Missed Description The pcXset software provides no mechanism to wake a computer from standby mode.
  • Page 26 ETTING TARTED WITH PC...
