Installation Requirements Based on the NPE or NSE Installed

Installation Requirements Based on the NPE or NSE Installed
To ensure that your Cisco 7200 series port adapter configuration is within the router operating
limitations, determine your model of network processing engine or network services engine and observe
the following guidelines:
•
•
•
•

NPE-G1 or NPE-G2 Bandwidth Calculation and Configuration Instructions

For each port adapter in your system, check the footnotes in
Step 1
If you have any dual-wide port adapters in your system, carefully read the port adapter configuration
Step 2
document to see what special conditions apply to these port adapters.
Calculate the bandwidth points requirements. For each port adapter in your system, go to
Step 3
write down the bandwidth points requirements. Use the blank
to record your requirements.
Note
Assign each port adapter in your system to a chassis slot.
Step 4
•
•
Make sure that the bandwidth points are evenly distributed between the left (odd-numbered slots) and
Step 5
right (even-numbered slots) buses. Include the I/O controller in your determination of balance for the
left odd-numbered slots. Fill the slots in the following order: 2, 1, 4, 3, 6, 5.
Check your Cisco IOS release and port adapter SDRAM memory requirements as detailed in
Step 6
"Memory
You are finished calculating your port adapter configuration.
Cisco 7200 Series Port Adapter Hardware Configuration Guidelines
1-8
For NPE-G1 or NPE-G2, go to the
Instructions" section on page
NPE-G1 or NPE-G2 with a Port Adapter Jacket Card—Bandwidth Calculation and Configuration
Instructions, page 1-9
For NPE-400, NPE-300 and NSE-1, go to the
Calculation and Configuration Instructions" section on page
For NPE-225, NPE-200, NPE-175, NPE-150, and NPE-100, go to the
NPE-175, NPE-150, and NPE-100 Bandwidth Calculation and Configuration Instructions" section
on page 1-11.
Do not calculate bandwidth points for an I/O controller if it is installed in the Cisco 7200 VXR
router with an NPE-G1 or NPE-G2. With the NPE-G1 or NPE-G2, I/O controllers do not use
bandwidth or bandwidth points.
Make sure that the total bandwidth points for slots 0, 1, 3, and 5 (left bus) are less than or equal to
600.
Make sure that the total bandwidth points for slots 2, 4, and 6 (right bus) are less than or equal to 600.
Requirements.".
Chapter 1 Cisco 7200 Series Port Adapter Installation Requirements
"NPE-G1 or NPE-G2 Bandwidth Calculation and Configuration
1-8.
"NPE-400, NPE-300, and NSE-1 Bandwidth
Table 1-6
1-9.
"NPE-225, NPE-200,
to see if any apply to your system.
Bandwidth Calculation Table, page
Table 1-6 and
1-22,
Chapter 2,
OL-3875-11
