Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles on
modules (such as power supplies, fans, or cards); these types of handles are not designed to support the weight
of the unit. Statement 1032
Warning This equipment must be installed and maintained by service personnel as defined by AS/NZS 3260. Incorrectly
connecting this equipment to a general-purpose outlet could be hazardous. The telecommunications lines must be
disconnected 1) before unplugging the main power connector or 2) while the housing is open, or both.
Statement 1043
Warning Ultimate disposal of this product should be handled according to all national laws and regulations. Statement 1040
Warning To prevent the system from overheating, do not operate it in an area that exceeds the maximum recommended
ambient temperature of 40 deg. Statement 1047

Installing the Router

Note Cisco 2800 series routers are normally ordered with modules and interface cards. Before you remove or install any
modules or interface cards, see the documents that accompany those items or to the online Cisco 2800 series hardware
installation documentation at the following URL:
http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/2800/hw/index.htm
For module and interface card compatibility information, see the data sheet for each module and interface card.
Warning Before working on a system that has an on/off switch, turn OFF the power and unplug the power cord. Statement 1
You can set any Cisco 2800 series router on a desktop or install it in a rack. A Cisco 2811 router can also be mounted on a wall
or other flat surface. See the applicable instructions in the following sections.
• Rack-Mounting the Router, page 12
• Wall-Mounting the Router—Cisco 2811 Routers Only, page 16
• Installing the Router on a Desktop, page 17
Caution To prevent damage to the chassis, never attempt to lift or tilt the chassis by the plastic panel on the front. Always
hold the chassis by the metal body.

Rack-Mounting the Router

Cisco 2811, Cisco 2821, and Cisco 2851 routers can be installed in 19- and 23-inch (48.26-cm and 58.42-cm) racks. Cisco 2801
routers can be installed only in 19-inch racks, and cannot be center mounted. Use the standard brackets for mounting the chassis
in a 19-inch rack; use the optional larger brackets for mounting the chassis in a 23-inch rack.
