Electric Touch-Control Drop-In Cooktop
E30EC70FSS
4 Element Configuration
One 9" / 12" double element (1700W / 2700W),
one 5" / 7" / 9" triple element (1000W / 1800W /
2700W) and two 6" elements (1200W) are
arranged to provide four concentric rings of
incomparable choices.
Ceramic Smoothtop Glass
Glass cooktop is flat, smooth and easy to clean
and maintain.
Custom-Set
The smooth cooktop surface is undisturbed
with knobs for a look that is sleek and flush with
your countertop.

Hot Surface Indicator

For added safety, when an element is still hot, a
blue LED indicator will stay on until surface cools.
Touch-Controls
Designed for the well-lived home.
30" ELECTRIC TOUCH-CONTROL DROP-IN COOKTOP
Configuration
FEATURES
Black Ceramic Smoothtop Glass Surface
6" Element – 1200W
5" to 7" to 9" Element – 1000W / 1800W / 2700W
9" to 12" Dual Element – 1700W / 2700W
Custom-Set
Electronic Controls
ACCESSORIES
Granite Countertop Installation Kit – PN # 903061-9010
SPECIFICATIONS
Overall Exterior Dimensions –
Height
Width
Depth
Power Supply Location
Amps @ 240 / 208 Volts
Connected Load (kW Rating) @ 240 / 208 Volts
Electrical – Single phase 3- or 4-wire cable, 120 / 240 V or
120 / 208 V, 60 Hz, fused on both sides of line with ground.
Armored Electrical Cable
Approved for Single Oven Combination Installation*
Approved for Downdraft Vent Combination Installation*
Shipping Weight (Approx.)
*Approved to be used over any Electrolux ICON
®
Single Wall Oven and in combination
with an Electrolux ICON
®
Downdraft Vent.
NOTE: Always consult local and / or national electric codes. Refer to Product Installation
Guide for detailed installation instructions on the web at electroluxicon.com.
Specifications subject to change.
4 Electric Elements
Yes
2
1
1
Yes
Optional
5"
30-3/4"
21-1/2"
Middle
33.0 / 29.0
7.8 / 5.9
Required
Included
Yes
Yes
48 Lbs.
electroluxicon.com
electroluxicon.com
