Connector Pin Assignments
Pin
Signal
1
Carrier detect
2
Receive data
3
Transmit data
4
Data terminal ready
5
Signal ground
Pin
Signal
1
Audio out
A–2
Table A-2
Serial
Table A-3
Stereo Speaker/Headphone
Pin
Signal
6
Data set ready
7
Ready to send
8
Clear to send
9
Ring indicator
1
2
Pin
Signal
2
Ground
Maintenance and Service Guide
