Removal and Replacement Procedures
5.8 Mini PCI Communications Board
Lucent Win Modem + Intel PRO-100 (S)P
Mobile Combo Adapter
Type III mini PCI combination 56 Kbps modem/NIC board
Type III mini PCI 56 Kbps modem board
1. Prepare the notebook for disassembly (Section 5.3).
2. Remove the palm rest (Section 5.5).
5–20
Mini PCI Communications Board
Spare Part Number Information
Maintenance and Service Guide
230339-001
230338-001
230337-001
