Compaq Evo Notebook N400c Specification

Hide thumbs Also See for Evo Notebook N400c:
Table of Contents

Advertisement

Quick Links

See also: Maintenance and Service Manual

QuickSpecs

Overview

W h a t ' s N ew
Mobile Intel Pentium III 850
MHz processor with SpeedStep™
technology
A t A G l a n c e
Weighs only 3.5 lb/1.59 kg
Less than 1 in/2.3 cm thin
12.1-inch XGA TFT display
128-MB SDRAM upgradeable to
512 MB
20-GB User removable SMART
hard drive
Integrated Mini PCI 56K V.90
modem plus 10/100 NIC
Complete set of system ports
Microsoft Windows 2000
preinstalled/Windows NT 4.0 on
CD, or Windows 98SE
Protected by a Three-year,
Worldwide Limited Warranty —
Certain restrictions and
exclusions apply. Consult the
Compaq Customer Support
Center at 1-888-88-COMPAQ.
What's Special
Ultra-light weight – 3.5 lb/1.59 kg
Innovative MultiPort
Full sized keyboard
Support for up to four
batteries*
Optional Mobile Expansion Unit
providing Multimedia, storage and
enhanced security features
Magnesium display enclosure
Compatible with current Compaq
enterprise docking solutions
Industry leading PC lifecycle
solutions
NOTE: * = Requires optional MEU.
DA-10844
Canada — Version 18 — August 27, 2002
Compaq Evo Notebook N400c
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evo Notebook N400c and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq Evo Notebook N400c

Summary of Contents for Compaq Evo Notebook N400c

  • Page 1 QuickSpecs Compaq Evo Notebook N400c Overview W h a t ' s N ew Mobile Intel Pentium III 850 MHz processor with SpeedStep™ technology A t A G l a n c e Weighs only 3.5 lb/1.59 kg Less than 1 in/2.3 cm thin 12.1-inch XGA TFT display...

  • Page 2: Standard Features

    12.1-inch TFT XGA display with 1024x768 resolution up to 16.7M colors NOTE: Compaq now offers Flexible Solutions via CTO (Configure to Order). Order the Evo Notebook N400c the way you want it by selecting the processor/panel, hard drive, memory and more. Purchase directly from Compaq or from an Authorized Compaq Agent.
  • Page 3 Professional operating system, the next version of Windows for enhanced business computing, Compaq is participating in the Windows XP Ready program. The Evo N400c meets the minimum hardware requirements to run Microsoft Windows XP. Hardware drivers, if necessary, will be available from Compaq upon the release of Windows XP.
  • Page 4 DMI and Wired for Management, while pioneering new ground in client manageability. Compaq introduced the industry’s first line of manageable clients in 1995 and has been driving the industry ever since. With Compaq’s lifecycle management philosophy, enterprises have all of the pieces for end- to-end management and proven tools for hassle-free management of PCs.
  • Page 5 S e r v i c e a n d S u p p o r t Compaq Services includes a Three-year, Worldwide Limited Warranty, pick-up or carry-in, toll-free 7 x 24 hardware technical phone support. Optional services include; upgrade to three years standard warranty, onsite warranty, application and operating system support.
  • Page 6 QuickSpecs Compaq Evo Notebook N400c Standard Features The Etymology of a Model name: N a m i n g C o n v e n t i o n DA-10844 Canada — Version 18 — August 27, 2002...
  • Page 7 QuickSpecs Compaq Evo Notebook N400c Standard Features 12.1-inch colour TFT XGA N4CP850X220C12PoL Display P/N 470026-529/-633 Mobile Intel Pentium III 850 MHz Processor 256-KB, L2 Cache Cache Memory Standard 256-MB SDRAM Memory Maximum 512-MB SDRAM None Optical Drive 20-GB SMART Hard Drive Type III Mini PCI 56K (V.90) modem, 10/100 NIC Combo...
  • Page 8 32-MB (100 MHz) Memory Upgrade 400311-B21 NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility. NOTE: 256-MB and 512-MB (133 MHz) memory are not compatible with the Evo Notebook N400c.
  • Page 9 386504-B21 AC Line Cord (10-ft/3.1 m) 217932-002 NOTE: * = Use of this option with Compaq Evo N400c requires the optional Mobile Expansion Unit (MEU). NOTE: The Universal Battery Charger (P/N 135555-001) will charge the N600c, M700, and E500 internal primary batteries and the N400c and M300 external handle batteries.
  • Page 10 USB 2 Button Scroll Mouse (carbon) 195255-B25 USB/PS2 10-Key Numeric Keypad (carbon) 294317-B21 Security Biometric PC Card 146805-B25 Security Cable Lock 294316-B21 Compaq Smart Card PC Card Reader 135646-B25 PC Guardian Lock 261680-B21 Useful Accessories MP1400 Microportable Projector 174626-xx1 MP1800 Microportable Projector 180226-xx1...
  • Page 11 64-MB (133 MHz) Memory Upgrade 197896-B25 NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility. NOTE: 256-MB and 512-MB (133 MHz) memory are not compatible with the Evo Notebook N400c.
  • Page 12 QuickSpecs Compaq Evo Notebook N400c Storage Hard Drive MultiBay MultiBay R I V E U P P O R T System Drive Support Removable Media Quantity Drive Bay Supported Supported 1.44-MB Diskette Drive (optional) Up to 1 External connects via parallel port...

  • Page 13: Technical Specifications

    QuickSpecs Compaq Evo Notebook N400c Technical Specifications Dimensions (H x W x D) 12.1-inch TFT panel display 0.89 x 10.5 x 9.5 in/2.2 x 26.6 x 24.2 cm System Unit Weight Minimum/Maximum 3.5 lb/1.58 kg Stand-Alone Power Nominal Operating Voltage 14.8 VDC...
  • Page 14 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Hard Drives MultiBay Drive Adapter 20 GB Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm Weight 0.15 lb/0.07 kg Drive Weight 0.21 lb/0.1 kg...
  • Page 15 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Dimensions (H x W x D) Secondary Lithium-Ion Battery 0.9 x 10.47 x 0.9 in/2.3 x 26.6 x 2.3 cm Pack Weight 0.48 lb/0.21 kg Cells 4-cell Lithium-Ion Energy Voltage 14.4 V Amp-hour capacity 1.96 Ah...
  • Page 16 QuickSpecs Compaq Evo Notebook N400c Technical Specifications MultiBay DVD/CD-RW Combo MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm Drive Weight 0.74 lb/0.34 kg Center Hole Diameter 0.59 in/1.5 cm...
  • Page 17 QuickSpecs Compaq Evo Notebook N400c Technical Specifications MultiBay Drive MultiBay DVD-ROM Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm Weight 0.66 lb/0.3 kg Center Hole Diameter 15 mm Disc Diameter...
  • Page 18 QuickSpecs Compaq Evo Notebook N400c Technical Specifications MultiBay Drive MultiBay Diskette Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm Weight 0.51 lb/0.23 kg Diskette Size 3.5 in Activity Indicator On system Height 0.5 in/1.27 cm...
  • Page 19 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Dimensions (H x W x D) MultiBay Iomega Zip 250 Drive 5.26 x 5.24 x 5.71 in/13.35 x 13.3 x 14.5 cm Weight 9.8 oz or Xg (0.27 kg) Transfer Rates 250 Media: 1200 – 2400 KB/s 100 Media: 138 –...
  • Page 20 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Receiver Sensitivity – Bit 802.11b MultiPort Module (continued) 11 Mbps: -85 dBm Error Rate (1E-5) 5.5 Mbps: -87 dBm 2 Mbps: -91 dBm 1 Mbps: -94 dBm Maximum Receive Level –4 dBm Output Power (approximately) 18 dBM...
  • Page 21 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Form Factor Bluetooth MultiPort Module Compaq MultiPort Bluetooth 1.1 Compliant Dimensions 2.2 x 6.6 x 0.55 in/5.6 x 16.7 x 1.4 cm Weight 0.22 lb/100 g (maximum) Temperature Operating 50 to 104 F/10 to 40 C Non-operating –4 to 140 F/–20 to 60 C...
  • Page 22 QuickSpecs Compaq Evo Notebook N400c Technical Specifications Bluetooth MultiPort Module (continued) Usage Models Service Discovery (determine what Bluetooth devices are within range and support authorization) Synchronization: PDAs to PCs Portable to Desktop File Transfer: File and directory browsing and navigation on another Bluetooth device.
  • Page 23 Windows 98 (Gold, SE), Windows NT4.0, Windows 2000, Windows Millennium (with all released Service Packs) Edition, DOS Application Support under Windows Power Management Support APM Revision 1.2, ACPI, Compaq Power Management Extensions for Windows Approvals/Certifications UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark,...
  • Page 24 Printed in Canada. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is without warranty of any kind and is subject to change without notice. The warranties for Compaq products are set forth in the express limited warranty statements accompanying such products.
