3.5.6

Onboard Devices Configuration

EFI BIOS Utility - Advanced Mode
Ai Tweaker
Main
Back Advanced\ Onboard Devices Configuration >
HD Audio controller
Front Panel Type
SPDIF Out Type
VIA 1394
PCI Express X16_3 slot (black) bandwidth
Marvell Storage Controller
Marvell Storage OPROM
JMB Storage Controller
JMB Storage OPROM
Display OptionRom in POST
Intel LAN
Intel PXE OPROM
Asmedia USB 3.0 Controller
Asmedia USB 3.0 Battery Charging Support
Scroll down to display the following items:
> Serial Port Configuration
HD Audio Controller [Enabled]
[Enabled] Enables the High Definition Audio Controller.
[Disabled] Disables the controller.
The following two items appear only when you set the Azalia HD Audio item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC'97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD] Sets the front panel audio connector (AAFP) mode to high definition audio.
[AC97] Sets the front panel audio connector (AAFP) mode to legacy AC'97
ASUS P8P67 PRO REV 3.1
Advanced
Enabled
Enabled
Auto
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Disabled
Enabled
Enabled
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Version 2.00.1201. Copyright (C) 2010 American Megatrends, Inc.
Monitor Boot
Enabled/Disabled Azalia HD Audio
HD
SPDIF
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save
Exit
Tool
ESC: Exit
3-19
