Asus P8H61-M PLUS User Manual page 52

Power On By PCI [Disabled]
[Disabled]
[Enabled]
Power On By PCIE [Disabled]
[Disabled]
[Enabled]
Power On By Ring [Disabled]
[Disabled]
[Enabled]
Power On By RTC [Disabled]
[Disabled]
[Enabled]
2-20
E6335_P8H61-M PLUS.indb 20
Disables the PME to wake up from S5 by PCI devices.
Allows you to turn on the system through a PCI LAN or modem card. This
feature requires an ATX power supply that provides at least 1A on the
+5VSB lead.
Disables the PCIE devices to generate a wake event.
Enables the PCIE devices to generate a wake event.
Disables Ring to generate a wake event.
Enables Ring to generate a wake event.
Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
Minute/Second will become user-configurable with set values.
ASUS P8H61-M PLUS
