Sanyo PLC-XU305A - 3000 Manual
Expand serial command functional specifications
Hide thumbs
Also See for PLC-XU305A - 3000:
- Owner's manual (144 pages) ,
- Manual (26 pages) ,
- Specification sheet (2 pages)
Related Manuals for Sanyo PLC-XU305A - 3000
Summary of Contents for Sanyo PLC-XU305A - 3000
- Page 1 EXPAND SERIAL COMMAND FUNCTIONAL SPECIFICATIONS PLC-XU305A PLC-XU355A Ver. 1.00 SANYO Electric Co., Ltd DS Company Projector Division...
-
Page 2: Table Of Contents
PLC-XU305A/355A Expand Serial Command Functional Specifications - CONTENTS - Overview .........................8 Serial Interface Specification ..................8 2.1 Transfer Specification ....................8 2.2 Connection .........................8 Notes for communication ....................9 Name Definition ......................9 Functional Execution Command Table ..............10 Image Command Table ..................10 PC Adjust Control Command Table .............. - Page 3 PLC-XU305A/355A Expand Serial Command Functional Specifications 8.4.9 CF_PROGV Command ................. 19 8.4.10 CF_NZRED Command .................. 19 8.4.11 CF_IMAGE Command .................. 20 8.4.12 CF_IMAGEADJ Command ................20 PC Adjust Control Command ................21 8.5.1 CF_FSYNC Command .................. 21 8.5.2 CF_TDOTS Command .................. 21 8.5.3 CF_CLAMP Command..................
- Page 4 PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.1 CF_LANG Command ..................33 8.10.2 CF_MENUPOSITION Command ..............33 8.10.3 CF_AUTOSETUPPCADJ Command ............33 8.10.4 CF_AUTOSETUPKEYSTONE Command ............ 34 8.10.5 CF_INPUTSEARCH Command ..............34 8.10.6 CF_AUTOSETUP ................... 34 8.10.7 CF_BACKGND Command ................34 8.10.8 CF_DISP Command ..................
- Page 5 PLC-XU305A/355A Expand Serial Command Functional Specifications 9.4.3 CR_COLOR Command ................. 44 9.4.4 CR_TINT Command ..................44 9.4.5 CR_SHARP Command ................. 44 9.4.6 CR_GAMMA Command ................45 9.4.7 CR_WBAL – R Command ................45 9.4.8 CR_WBAL – G Command ................45 9.4.9 CR_WBAL –...
- Page 6 PLC-XU305A/355A Expand Serial Command Functional Specifications 9.8.6 CR_HPOS Command ..................55 Lamp Status Read Command ................56 9.9.1 CR_LAMPREPL Command ................56 9.9.2 CR_LAMPH Command ................. 56 9.9.3 CR_LAMPCORRESPH Command ............... 56 9.9.4 CR_LAMPMODE Command ................. 56 9.9.5 CR_LAMPMSTS Command................57 9.9.6 CR_PROJH Command .................
- Page 7 PLC-XU305A/355A Expand Serial Command Functional Specifications 9.12 Other Status Read Command ................65 9.12.1 CR_STATUS Command ................65 9.12.2 CR_SIGNAL Command ................65 9.12.3 CR_VMUTE Command ................. 65 9.12.4 CR_FREEZE Command ................65 9.12.5 CR_PTIMER Command ................66 9.12.6 CR_TEMPWARN Command ................. 66 9.12.7 CR_TEMP Command ..................
-
Page 8: Overview
PLC-XU305A/355A Expand Serial Command Functional Specifications Overview 1.1 This Functional Specification defines communication functions for PLC-XU305A/355A. 1.2 Compatible to Firmware Ver. 1.x of the projector. 1.3 Most commands can be used to control projector remotely from PC by RS-232C. Therefore, the commands are defined as Expand Serial Commands. -
Page 9: Notes For Communication
PLC-XU305A/355A Expand Serial Command Functional Specifications Notes for communication 1. Expand Serial Command is defined as one command / one line that starts with “C” and ends with carriage return (0x0D) 2. There are two types of commands: Functional Execution Command and Status Read Command. -
Page 10: Functional Execution Command Table
PLC-XU305A/355A Expand Serial Command Functional Specifications 5. Functional Execution Command Table 5.1 Image Command Table Execute command Item CF_BRIGHT_%1[CR] Set Brightness value CF_CONT_%1[CR] Set Contrast value CF_COLOR_%1[CR] Set Color value CF_TINT_%1[CR] Set Tint value CF_SHARP_%1[CR] Set Sharpness value CF_GAMMA_%1[CR] Set Gamma value CF_WBAL-R_%1[CR] Set White Balance Red value CF_WBAL-G_%1[CR]... -
Page 11: Lamp Command Table
PLC-XU305A/355A Expand Serial Command Functional Specifications 5.5 Lamp Command Table Execute command Item CF_LAMPMODE_%1[CR] Select Lamp mode CF_LAMPLIFECONTRL_%1[CR] Select Lamp life mode 5.6 Sound Command Table Execute command Item CF_VOLUME_%1[CR] Set Volume value CF_MUTE_%1[CR] Control ON/OFF of Sound Mute 5.7 Setting Command Table Execute command Item CF_LANG_%1[CR]... -
Page 12: Status Read Command Table
PLC-XU305A/355A Expand Serial Command Functional Specifications 6. Status Read Command Table 6.1 Image Status Read Command Table Status read command Item CR_BRIGHT[CR] Get Brightness value CR_CONT[CR] Get Contrast value CR_COLOR[CR] Get Color value CR_TINT[CR] Get Tint value CR_SHARP[CR] Get Sharpness value CR_GAMMA[CR] Get Gamma value CR_WBAL-R[CR]... -
Page 13: Screen Status Read Command Table
PLC-XU305A/355A Expand Serial Command Functional Specifications 6.5 Screen Status Read Command Table Status read command Item CR_SCREEN[CR] Get selected screen size CR_KYSTNMODE[CR] Get setting status of Keystone Store mode CR_VSCALE[CR] Get setting status of Vertical Scale CR_VPOS[CR] Get setting status of Vertical Position CR_HSCALE[CR] Get setting status of Horizontal Scale CR_HPOS[CR]... -
Page 14: Other Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 6.9 Other Status Read Command Status read command Item CR_STATUS[CR] Get setting status of Projector behavior CR_SIGNAL[CR] Get Signal Status if there is a signal or not CR_VMUTE[CR] Get setting status of No Show CR_FREEZE[CR] Get setting status of Freeze CR_PTIMER[CR]... -
Page 15: Error Code Table
PLC-XU305A/355A Expand Serial Command Functional Specifications 7. Error Code Table Error Code Contents -When the received data cannot be decoded -Parameter determination error (digit number error, including invalid value, etc.) The function is not available in the selected Mode Selected value is out of range (Not reflected) Command mismatched to Hardware (command for Optional function which is not installed) When reached upper or lower limit of increasing or... -
Page 16: Functional Execution Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8. Functional Execution Command 8.1 Format PC issues commands in format as below: Pattern1 : “CF_COMMAND” [CR] Pattern2 : “CF_COMMAND_”%1 [CR] CF_ : Header COMMAND : Character line %1 : Parameter (Character line) _ : Space (To separate COMMAND and Parameter) The projector decodes the received command and when it is ready to receive the next command, it returns the response. -
Page 17: Image Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.4 Image Command 8.4.1 CF_BRIGHT Command Command "CF_BRIGHT_%1”[CR] "000~063” --------------- Directly select Brightness setting value "UP” ----------------------- Current Brightness setting value + 1 "DN” ----------------------- Current Brightness setting value – 1 Set Brightness value of user control The value set by this command will not be saved to projector. -
Page 18: Cf_Sharp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.4.5 CF_SHARP Command Command “CF_SHARP_%1”[CR] “000~015” ---------------- Directly select Sharpness setting value “UP” ------------------------ Current Sharpness setting value + 1 “DN” ------------------------ Current Sharpness setting value - 1 Set Sharpness value of user control The value set by this command will not be saved to projector. -
Page 19: Cf_Coltemp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.4.8 CF_COLTEMP Command Command “CF_COLTEMP_%1”[CR] “000” ------ Xlow “001” ------ Low “002” ------ Mid “003” ------ High Set Color Temperature. (Available only in the normal Power ON status) The value set by this command will not be saved to the projector. Therefore, when Details turning into Standby-mode or ALL is OFF, the value returns to original setting. -
Page 20: Cf_Image Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.4.11 CF_IMAGE Command Command “CF_IMAGE_%1”[CR] “DYNAMIC” ------ Dynamic (Fixed value to enable projection with a sharp, powerful picture tone) “STAND” ---------- Standard (Image adjust value is set to factory default) “REAL” ------------ Real (Fixed value to display graphic image with natural tone) “CINEMA”... -
Page 21: Pc Adjust Control Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.5 PC Adjust Control Command 8.5.1 CF_FSYNC Command Command “CF_FSYNC_%1”[CR] “0000~0031” --------------- Directly select Fine Sync setting value “UP” -------------------------- Current Fine Sync setting value + 1 “DN” -------------------------- Current Fine Sync setting value - 1 Set Fine Sync value of PC signal The value set by this command will not be saved to projector. -
Page 22: Cf_H - Pos Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.5.4 CF_H – POS Command Command “CF_H-POS_%1”[CR] “0000~nnnn” --- Directly select Horizontal Position setting value “nnnn” shows maximum value, it is current Total Dots value - Display Dots value “UP” -------------- Current Horizontal Position setting value + 1 “DN”... -
Page 23: Cf_Dline Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.5.7 CF_DLINE Command Command “CF_DLINE_%1”[CR] “0100”~”nnnn” --- Directly select Display Line setting value “nnnn” shows maximum value, it is current Total Line value – Vertical Position value “UP” -------------- Current Display Line setting value + 1 “DN”... -
Page 24: Input Control Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.6 Input Control Command 8.6.1 CF_INPUT Command Command “CF_INPUT_%1”[CR] “CONPUTER1” ----- Select Computer1 Input “COMPUTER2” ----- Select Computer2 Input “VIDEO” --------------- Select Video Input “S-VIDEO” ------------ Select S-video “NETWORK” -------- Select Network “UP” ------------------- Switch Input setting forward Computer1 →... -
Page 25: Cf_Input1 Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.6.3 CF_INPUT1 Command Command “CF_INPUT1_%1_”[CR] “ANALOG” ----------Select Analog RGB Input “YPBPR” ------------- Select Component “SCART” ------------- Select SCART Select Computer 1 input and source specified by %1 at the same time. Details This command is available in normal Power ON status. Acceptable “000”[CR] Response... -
Page 26: Cf_Input_%1_%2 Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.6.8 CF_INPUT_%1_%2 Command Command “CF_INPUT_%1_%2”[CR] “COMPUTER1” ------ Select Computer1 Input “COMPUTER2” ------ Select Computer2 Input “VIDEO” ---------------- Select Analog Input “S-VIDEO” ------------- Select S-video Input When %1 is COMPUTER1 “ANALOG” ----------Select Analog RGB Input “YPBPR”... -
Page 27: Cf_System Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.6.9 CF_SYSTEM Command Command “CF_SYSTEM_%1”[CR] “VGA1” ------------- Select VGA1 “XGA1” ------------- Select XGA1 “WXGA3” ------------ Select WXGA3 “1080I” --------------- Select 1080I Input is “1035I” --------------- Select 1035I Computer “720P” ---------------- Select 720P ”575P” ---------------- Select 575P ”480P”... -
Page 28: Screen Control Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.7 Screen Control Command 8.7.1 CF_SCREEN Command Command “CF_SCREEN_%1”[CR] “NORMAL” ---------------------- Select Normal size “TRUE” -------------------------- Select True size “WIDE” -------------------------- Select Wide size “FULL” --------------------------- Select Full screen size “CUSTOM” ---------------------- Select Custom size Input is “DZOOM_UP”... -
Page 29: Cf_Kystnmode Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.7.4 CF_KYSTNMODE Command Command “CF_KYSTNMODE_%1”[CR] “STR” --------- Set Keystone store mode to Store “RST” --------- Set Keystone store mode to Reset Set Keystone store mode Details This command is available in normal Power ON status. Acceptable “000”[CR] Response... -
Page 30: Cf_Hscale Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.7.7 CF_HSCALE Command Command “CF_HSCALE_%1”[CR] “032” --------- +32 “031” --------- +31 ÿ “002” --------- +2 “001” --------- +1 “000” --------- +0 “-01” ---------- -1 “-02” ---------- -2 ÿ “-31” ---------- -31 “-32” ---------- -32 “UP”... -
Page 31: Lamp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.8 Lamp Command 8.8.1 CF_LAMPMODE Command Command “CF_LAMPMODE_%1”[CR] “NORMAL” ------- Set lamp to Normal mode status “ECO” ------------- Set lamp to 3L mode status “UP” --------------- Switch Lamp mode forward “DN” --------------- Switch Lamp mode backward Select Lamp Mode The value set by this command is stored in EEPROM and its setting is effective Details... -
Page 32: Sound Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.9 Sound Command 8.9.1 CF_VOLUME Command Command “CF_VOLUME_%1”[CR] “000-063” -------------------------- Directly select Volume setting value “UP” --------------------------------- Current Volume setting value +1 “DN” --------------------------------- Current Volume setting value -1 Control Volume value The same operation of Volume Up/Down as projector and RC, and directly select Volume setting value. -
Page 33: Setting Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10 Setting Command 8.10.1 CF_LANG Command Command “CF_LANG_%1”[CR] “ENG” --------------------------- Select English “DEU” --------------------------- Select German “FRA” --------------------------- Select French “ITA” ----------------------------- Select Italian “ESP” ---------------------------- Select Spanish “POR” --------------------------- Select Portuguese “NED” --------------------------- Select Dutch “SVE”... -
Page 34: Cf_Autosetupkeystone Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.4 CF_AUTOSETUPKEYSTONE Command Command “CF_AUTOSETUPKEYSTONE_%1”[CR] “AUTO” ------------------- Set Auto Keystone function to Auto “MANUAL” --------------- Set Auto Keystone function to Manual “OFF” --------------------- Set Auto Keystone function to OFF Set Keystone function of Auto setup This command is available in normal Power ON status. -
Page 35: Cf_Disp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.8 CF_DISP Command Command “CF_DISP_%1”[CR] “ON” ----------------------------- Select Display “OFF” --------------------------- Cancel Display “CNTDWNOFF” -------------- Count down OFF “UP” --------------- Switch Display mode forward ÿ On → Count down OFF → Off → On → 0û 0 û ÿ “DN”... -
Page 36: Cf_Ceil Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.10 CF_CEIL Command Command “CF_CEIL_%1”[CR] “ON” ------------------------ Set Ceiling to ON “OFF” ----------------------- Set Ceiling to OFF Set/Cancel Ceiling setting. The value set by this command is stored in EEPROM and its setting is effective Details even after ALL is OFF This command is available in normal Power ON status. -
Page 37: Cf_P-Manetime Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.14 CF_P-MANETIME Command Command “CF_P-MANETIME_%1”[CR] “01” ~ ”30” ----------------------- Directly select setting time by the minute “UP” ------------------------------- Plus one minute (01 → 02 → ÿ e ÿ e ÿ e → 30 → 01) ÿ... -
Page 38: Cf_Ccaptioncolor Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.18 CF_CCAPTIONCOLOR Command Command “CF_CCAPTIONCOLOR_%1”[CR] “COLOR” ------- Select Color “WHITE” -------- Select White Select color of Closed caption. The status set with this command is stored in EEPROM and its setting is effective even after ALL is OFF. Details This command is available in normal Power ON status. -
Page 39: Cf_Pjpincode Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.21 CF_PJPINCODE Command Command “CF_PJPINCODE_%1”[CR] “0000” – “9999” ---------Set PJ PIN CODE directly Set PJ PIN CODE to release PJ LOCK. PIN CODE cannot be changed by this command. -When PJ LOCK is in operation PIN CODE is correct ------------------------- Command is valid (Acceptable) PIN CODE is incorrect ----------------------- Command is invalid(Error Code”102”) PIN CODE is out of %1 range ------------- Command is invalid (Error Code “? “) -
Page 40: Cf_Filtimer Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.10.24 CF_FILTIMER Command Command “CF_FILTIMER_%1”[CR] “100” -------------------- Set 100 hours “200” -------------------- Set 200 hours “300” -------------------- Set 300 hours “OFF” ------------------- No warning display “UP” --------------------- Switch Filter timer forward ÿ Off →100 → 200 → 300 → Offÿ “DN”... -
Page 41: Other Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.11 Other Command 8.11.1 CF_KEYENU Command Command “CF_KEYENU_%1”[CR] “RIGHT” ------------------------- Shift Pointer on OSD Menu to right “LEFT” --------------------------- Shift Pointer on OSD Menu to left “UP” ------------------------------ Shift Pointer on OSD Menu to right “DN”... -
Page 42: Cf_Freeze Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 8.11.4 CF_FREEZE Command Command “CF_FREEZE_%1”[CR] “ON” ------------------------ Set Freeze to ON “OFF” ----------------------- Set Freeze to OFF “UP” ------------------------------ Switch setting (On → Off → On → ÿ e ÿ e ÿ e ) “DN”... -
Page 43: Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9. Status Read Command 9.1 Format PC issues commands in format as below: “CR_Command” [CR] Command : Character Line When projector receives the appropriate command, it returns a character line as the required data “000ÿ... -
Page 44: Image Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.4 Image Status Read Command 9.4.1 CR_BRIGHT Command Command “CR_BRIGHT”[CR] Details Get Brightness value of user control Acceptable “000_ÿ ÿ A ”[CR] Response “000”~“063” Unacceptable “Error Code”[CR] 9.4.2 CR_CONT Command Command “CR_CONT”[CR] Details Get Contrast value of user control Acceptable “000_ÿ... -
Page 45: Cr_Gamma Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.4.6 CR_GAMMA Command Command "CR_GAMMA”[CR] Details Get Gamma value of user control Acceptable “000_%a”[CR] Response “000”~“015” Unacceptable “Error Code”[CR] 9.4.7 CR_WBAL – R Command Command "CR_WBAL-R”[CR] Details Get White Balance Red value of user control Acceptable “000_%a”[CR] Response... -
Page 46: Cr_Nzred Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.4.11 CR_NZRED Command Command “CR_NZRED”[CR] Details Get setting status of Noise Reduction Acceptable “000_%1”[CR] “L1” -------- Noise Reduction for moving image Response “L2” -------- Noise Reduction for still image “OFF” ----- Noise Reduction is OFF Unacceptable “Error Code”[CR] 9.4.12 CR_PROGV Command... -
Page 47: Pc Adjust Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.5 PC Adjust Status Read Command 9.5.1 CR_FSYNC Command Command "CR_FSYNC”[CR] Details Get Fine Sync value Acceptable “000_%a”[CR] “0000”~“0031” Response “Error Code”[CR] ----- When the command is invalid due to Unacceptable condition such as Input source “?”[CR] -------------------- When unclear command is received 9.5.2 CR_TDOTS Command... -
Page 48: Cr_V - Pos Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.5.5 CR_V – POS Command Command “CR_V POS”[CR] Details Get Vertical Position value Acceptable “000_%a”[CR] “0000”~“nnnn” (nnnn = Total Line - Display Line) Response “Error Code”[CR] -------- When the command is invalid due to Unacceptable condition such as Input source “?”[CR] ----------------------- When unclear command is received... -
Page 49: Video Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.6 Video Status Read Command 9.6.1 CR_SERSYS Command Command “CR_SERSYS”[CR] Get currently selected signal Details Returns auto-detected signal in Auto mode Only available for Video input. (N/A when Input is computer) Acceptable “000_%a”[CR] “1080I60” -------------- 1080i 60Hz “1080I50”... -
Page 50: Input Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.7 Input Status Read Command 9.7.1 CR_INPUT Command Command “CR_INPUT”[CR] Details Get selected INPUT No. Acceptable “000_%1”[CR] Response Request data “1”-”5” Unacceptable “Error Code”[CR] 9.7.2 CR_SOURCE Command Command “CR_SOURCE”[CR] Details Get selected Source Acceptable “000_%1”[CR] “DIGITAL”... -
Page 51: Cr_Srcinp4 Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.7.6 CR_SRCINP4 Command Command "CR_SRCINP4” [CR] Details Get selected source of Input 4_S-video Acceptable “000_%1”[CR] Response Request data “Sÿ VIDEO” -------- S-Video Input is selected Unacceptable “Error Code”[CR] 9.7.7 CR_SRCINP4 Command Command "CR_SRCINP5” [CR] Details Get selected source of Input 5_Network Acceptable... -
Page 52: Cr_System Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.7.8 CR_SYSTEM Command Command “CR_SYSTEM”[CR] Details Get selected System Acceptable “000_%1”[CR] “VGA1” -------------- VGA1 is selected “VGA2” -------------- VGA2 is selected ÿ “XGA1”-------------- XGA1 is selected ÿ “WXGA3” --------- WXGA3 is selected “1080I” ------------ 1080i is selected “1035I”... -
Page 53: Cr_Syslist Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.7.9 CR_SYSLIST Command Command “CR_SYSLIST”[CR] Details Get selectable System titles Acceptable “000_%1_%2_..._%x” [CR] - When Input is PC-Analog “XGA1” ------------ XGA1is selectable “1080I ” ----------- 1080i is selectable Projector does not return Auto,Mode1-5 When there is no signal, it returns Error Code “101” -When Input is PC-Digitalÿ... -
Page 54: Screen Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.8 Screen Status Read Command 9.8.1 CR_SCREEN Command Command “CR_SCREEN”[CR] Details Get selected on-screen image size Acceptable “000_%a”[CR] “NORMAL” --------------- Normal mode is selected “TRUE” -------------------- True mode is selected Input “WIDE” --------------------- Wide mode is selected “FULL”... -
Page 55: Cr_Hpos Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.8.6 CR_HPOS Command Command “CR_HPOS”[CR] Details Get setting status of Horizontal Position Store Mode Acceptable “000_%1”[CR] Response “-15” ~ “015” Unacceptable “Error Code”[CR] 55/68... -
Page 56: Lamp Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.9 Lamp Status Read Command 9.9.1 CR_LAMPREPL Command Command “CR_LAMPREPL”[CR] Details Get information of Lamp Replacement time Acceptable “000_%1”[CR] “1Y” -------------------------- Over lamp replacement time “1N” -------------------------- Within lamp replacement time “1” means the number of lamps. Response (1 lamp model→... -
Page 57: Cr_Lampmsts Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.9.5 CR_LAMPMSTS Command Command “CR_LAMPSTS”[CR] Details Get Lighting status of lamp Acceptable “000_%1”[CR] “ÿ N **** ” A number of * should be among 1-4. First character shows how many lamps are incorporated in projector. -
Page 58: Cr_Volume Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.10 Sound Status Read Command 9.10.1 CR_VOLUME Command Command “CR_VOLUME”[CR] Details Get Volume value of user control Acceptable “000_%a”[CR] Response “000”~“063” Unacceptable “Error Code” [CR] 9.10.2 CR_MUTE Command Command “CR_MUTE”[CR] Details Get sound mute setting status Acceptable “000_%a”[CR] “ON”... -
Page 59: Setting Status Read Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11 Setting Status Read Command 9.11.1 CR_LANG Command Command “CR_LANG”[CR] Details Get selected language Acceptable “000_%a”[CR] “ENG” -------------------------- English is selected “DEU” -------------------------- German is selected “FRA” -------------------------- French is selected “ITA” --------------------------- Italian is selected “ESP”... -
Page 60: Cr_Backgnd Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11.5 CR_BACKGND Command Command “CR_BACKGND” [CR] Details Get setting status of Screen for no signal Acceptable “000_%1” [CR] “BLUE” -------------------------------- Blue Back is selected Response “USER” ------------------------------- User is selected “BLACK” ------------------------------ Black Back is selected Unacceptable “Error Code”... -
Page 61: Cr_Pointer Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11.10 CR_POINTER Command Command “CR_POINTER” [CR] Details Get Pointer setting status Acceptable “000_%a”[CR] “SPOTLIGHTMAX” ------- Spotlight Maximum mode “SPOTLIGHTMID” ------- Spotlight Medium mode “SPOTLIGHTMIN” ------- Spotlight Minimum mode Response “ARROW” ------------------- Arrow Mode “FINGER” ------------------- Finger Mark Mode “LASER”... -
Page 62: Cr_Ccaptiondisp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11.15 CR_CCAPTIONDISP Command Command “CR_CCAPTIONDISP”[CR] Details Get selected channel of Closed caption Acceptable “000_%a”[CR] “OFF” --------- Off “CC1” --------- CC1 is selected Response “CC2” --------- CC2 is selected ÿ a “CC3”--------- CC3 is selected “CC4”... -
Page 63: Cr_Keydis Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11.19 CR_KEYDIS Command Command “CR_KEYDIS”(CR) Details Get disability status of RC/Projector keys (valid or invalid) Acceptable “000_%a”[CR] “NONE” -------------------------- RC / Projector keys are valid Response “RC” ------------------------------ RC keys are invalid “KEY” ----------------------------- Projector keys are invalid Unacceptable “Error Code”... -
Page 64: Cr_Filh Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.11.24 CR_FILH Command Command “CR_FILH”[CR] Details Get Filter used time Acceptable “000_%1”[CR] Response “00000”~”99999” ------------------- 0 hour to 99999 hours Unacceptable “Error Code”[CR] 9.11.25 CR_FILREPL Command Command “CR_FILREPL”[CR] Details Get the information of Filter replacement time Acceptable “000_%1”[CR] “1Y”... -
Page 65: Cr_Status Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.12 Other Status Read Command 9.12.1 CR_STATUS Command Command “CR_STATUS”(CR) Get status of Projector behavior. Details This command affects the same as ”CR0” of Basic Serial command, but this has an error code. Acceptable “000_%1”[CR] “00”= Power ON “80”= Stand by... -
Page 66: Cr_Ptimer Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.12.5 CR_PTIMER Command Command "CR_PTIMER”[CR] Details Get status of Presentation Timer Acceptable “000_%a”[CR] “ON” -------------------- Presentation timer is in operation Response “STOP” ----------------- Presentation timer is paused “OFF” ------------------- Presentation timer is not operating Unacceptable “Error Code”... -
Page 67: Cr_Temp Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.12.7 CR_TEMP Command Command "CR_TEMP”[CR] Get current temperature inside a projector. Details If there are several sensors installed, it is possible to get information from all the sensors at once. Acceptable “000_%1_%2_%3”[CR] %1= Sensor 1 temperature (Outside temperature) %2= Sensor 2 temperature (Inside temperature1) %3= Sensor 3 temperature (Inside temperature2) %1,%2 are consists of 6 bites fixed... -
Page 68: Cr_Tempfail Command
PLC-XU305A/355A Expand Serial Command Functional Specifications 9.12.8 CR_TEMPFAIL Command Command "CR_TEMPFAIL”[CR] Get the temperature inside a projector when abnormal temperature occurs. Details If there are several sensors installed, it is possible to get information from all the sensors at once. Acceptable “000_%a_%b_%c”[CR] %a ------------------ Sensor 1 temp.
