OKICOLOR 8 Convenience Color Copier System
Installation/User's Manual
READ THIS INFORMATION BEFORE YOU START THE INSTALLATION !
Before you install the DS600C Flatbed Copier Unit, you must ensure that the OKICOLOR 8 Printer has
been installed. REFER TO THE OKICOLOR 8 SETUP GUIDE INCLUDED WITH YOUR PRINTER.
IF YOU ARE USING THIS PRODUCT AS A CONVENIENCE COLOR COPIER SYSTEM (NOT
ATTACHED TO A COMPUTER), you'll need to visit the Oki Data Web Site at:
www.okidata.com/copier
and download the instructions for the alternative method of calibrating the color output of your
OKICOLOR 8 Printer. These instructions will replace Step 11 in the OKICOLOR 8 SETUP GUIDE.
Also, you do not have to perform Step 10 in the OKICOLOR 8 SETUP GUIDE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OKICOLOR8cccs and is the answer not in the manual?

Questions and answers

Related Manuals for Oki OKICOLOR8cccs

Summary of Contents for Oki OKICOLOR8cccs

  • Page 1 REFER TO THE OKICOLOR 8 SETUP GUIDE INCLUDED WITH YOUR PRINTER. IF YOU ARE USING THIS PRODUCT AS A CONVENIENCE COLOR COPIER SYSTEM (NOT ATTACHED TO A COMPUTER), you'll need to visit the Oki Data Web Site at: www.okidata.com/copier and download the instructions for the alternative method of calibrating the color output of your OKICOLOR 8 Printer.
  • Page 3 Trademarks Microsoft is a U.S. registered trademark of Microsoft Corporation. Windows and MS-DOS are trademarks of Microsoft Corporation. IBM, PC, AT, XT are registered trademarks of International Business Machines Corp. Other brands and product names herein are trademarks or registered trademarks of their respective holders. Copyright All rights reserved.
  • Page 4 FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication.

  • Page 5: Table Of Contents

    Table of Contents 1. Introduction ______________________________________________________________________________1-1 DS600C Installation _______________________________________________________________________2-1 2.1 Precautions ____________________________________________________________________________2-1 2.2 Unlocking the DS600C ___________________________________________________________________2-2 2.3 Connecting the DS600C and OKICOLOR 8 Printer as a Convenience Copier ________________________2-3 2.4 Connecting the DS600C so you can also Print to the OKICOLOR 8 ________________________________2-4 2.5 Document Placement_____________________________________________________________________2-5 Operating the DS600C Copier _______________________________________________________________3-1 3.1 The DS600C Control Panel _______________________________________________________ 3-1, 3-2, 3-3...
  • Page 6 3.4 Using the Copier Features ________________________________________________________________ 3-6 3.4.1 Mirror Function ____________________________________________________________________ 3-6 3.4.2 Enlarging or Reducing your Original ____________________________________________________ 3-7 3.4.3 Auto Zooming your Original __________________________________________________________ 3-8 3.4.4 Changing your Copy Density __________________________________________________________ 3-9 3.4.5 Changing Color Intensity ____________________________________________________________ 3-10 3.4.6 Choosing your Copy Quantity ________________________________________________________ 3-17 3.4.7 Enhancing your Copy Quality ________________________________________________________ 3-18 3.4.8 Photo Copy, Text Copy, or Auto Copy Modes ___________________________________________ 3-19...

  • Page 7: Introduction

    INTRODUCTION Figure 1-1 shows how the DS600C is packed. Please check all the items against Figure 1-1. If there are any parts missing or damaged, please contact 1 (800) OKI-DATA (800-654-3282). Installation/User's Guide Power Adapter Shipping Foam DS600C Main SUnit...

  • Page 8: Ds600C Installation

    2. DS600C INSTALLATION PRECAUTIONS Ÿ Keep the DS600C out of direct sunlight. Direct exposure to the sun or excessive heat may cause damage to the unit. Ÿ Do not install the DS600C in a humid or dusty location. Ÿ Be sure to use a 115 vac 60 hz. AC power source. Ÿ...

  • Page 9: Unlocking The Ds600C

    2.2 UNLOCKING THE DS600C To protect the scanning head from damage during shipment, the DS600C is designed with a lock switch beneath the main unit. Therefore, before using the DS600C, you MUST unlock the DS600C by moving the lock switch to the USE position (See Figure 2-1.) #1.

  • Page 10: Connecting The Ds600C And Okicolor 8 Printer As A Convenience Copier

    2.3 CONNECTING THE DS600C AND OKICOLOR 8 PRINTER AS A CONVENIENCE COPIER Connect the unit as shown below. This configuration provides copying capability only. NOTE: The cable included with the DS600C Copier is not required in this configuration. An IEEE-1284 bi-directional parallel cable (maximum length 10 feet) is required.

  • Page 11: Connecting The Ds600C So You Can Also Print To The Okicolor 8

    2.4 CONNECTING THE DS600C SO YOU CAN ALSO PRINT TO THE OKICOLOR 8 Connect the unit as shown below. This configuration provides copying and printing capability. NOTE: An IEEE-1284 bi-directional parallel cable (maximum length 10 feet) is required. 1. DS600C main unit 2.

  • Page 12: Document Placement

    DOCUMENT PLACEMENT As shown in Figure 2-4, place the document on the glass face (text) down. 1. Document Cover 2. Home Position Mark 3. Document 4. Document Glass 5. Control Panel...

  • Page 13: Operating The Ds600C Copier

    3. OPERATING THE DS600C COPIER THE DS600C CONTROL PANEL (Scan Function is not supported) Figure 3.1 Control Panel...
  • Page 14 Copy(Color): Press to start a color copy. Refer to Figure 3.1 on Page 3-1 Copy(B/W): Press to start a black-and-white copy Power/Copy LED: The LED indicator turns green when power is on and flashes during copying. All Clear: Clear your current settings and return to the default settings. Auto/Text/Photo: Selects the type of original - Photo or Text.
  • Page 15 12. Message Display window: Display current settings. Refer to Figure 3.1 on Page 3-1 13. Light/Dark: Lighten or darken your image. Increase level of brightness or darkness by the ( ) button. Decrease level of brightness or darkness by the ( ) button.

  • Page 16: Before Making Copies

    3.2 BEFORE MAKING COPIES The DS600C supports three paper sizes; A4, letter, and legal. Select the paper size that matches the printer's paper supply to ensure smooth operations. To check or select paper size, Press the Paper Size button. The Message Window displays “Size:A4 *”...

  • Page 17: Making Simple Copies

    3.3 MAKING SIMPLE COPIES The Operating Steps: 1. Place your original face down on the document glass. 2. Press the Copy button. The Message window displays “Copy… ” and the Ready LED is flashing. 3. Within a few seconds, the copying is done. The Message window then displays “1 Copy @100%” and the Ready LED is now ON until the next task.

  • Page 18: Using The Copier Features

    3.4 USING THE COPIER FEATURES 3.4.1 MIRROR FUNCTION This function allows you to horizontally flip the copied image as if the image were reflected in a mirror. The Operating Steps Place your document face-down on the document glass. Keep on pressing Menu button until the message “Mirror: off” appears. Press the button to get the message, “Mirror: on”.

  • Page 19: Enlarging Or Reducing Your Original

    3.4.2 ENLARGING OR REDUCING YOUR ORIGINAL Like a normal copier, the DS600C also features auto enlargement/reduction function to resize your original. The Operating Steps: Place your document face-down on the document glass. Press the “Reduce/Enlarge” button, the Message Window displays “Ratio:100%”. Press the button to see more options.

  • Page 20: Auto Zooming Your Original

    3.4.3 AUTO ZOOMING YOUR ORIGINAL The Auto Zoom feature is used to resize your original without considering whether the magnification or reduction will be larger than the paper size programmed in the DS600C. The Operating Steps: Repeat the above Enlargement Step 1 & 2. Press the “Enlarge/Reduce”...

  • Page 21: Changing Your Copy Density

    3.4.4 CHANGING YOUR COPY DENSITY The Density Feature can compensate for an original that is too light or too dark. The Operating Steps: Place your original face down on the document glass. Press the “Lighter/Darker” button. The Message Window displays the default degree of darkness. 3.

  • Page 22: Changing Color Intensity

    3.4.5 CHANGING COLOR INTENSITY Color Intensity refers to the color saturation reproduced by the DS600C . There are times when the color saturation of the original image is not desired. The Color Intensity feature helps you to attain the desired color saturation.

  • Page 23: Choosing Your Copy Quantity

    3.4.6 CHOOSING YOUR COPY QUANTITY The Operating Steps: Place your original face-down on the document glass . The default copy count is 1. If you need to make 3 copies, for example, press the “Copy Count” button until the Message Window displays “2 copy @100%”. 3.

  • Page 24: Enhancing Your Copy Quality

    3.4.7 ENHANCING YOUR COPY QUALITY The Quality Mode feature can improve your copy quality particularly when your original contains photographs. Quality mode allows your printout to reveal more image details. The Operating Steps: Place your document face-down on the document glass. Press the “Normal/Quality”...

  • Page 25: Photo Copy, Text Copy, Or Auto Copy Modes

    3.4.8 PHOTO COPY, TEXT COPY, OR AUTO COPY MODES If the original consists of photo images only or photo images with a little text, select the Photo Mode. The Text Mode improves the quality of a "text heavy" copy. However, if the amount of photo images is almost the same as the amount of text in the original document, select Auto Mode to get the best copy.

  • Page 26: Making Copies Of A 3D Object

    3.4.9 MAKING COPIES OF A 3D OBJECT The DS600C can significantly improve copy reproduction and makes amazingly clear copies of 3D objects. The Operating Steps: Place your 3D object on the document glass. Be careful not to scratch the glass! Press the “Normal/Quality”...

  • Page 27: Automatic Power Saving Mode

    3.4.10 AUTOMATIC POWER SAVING MODE The DS600C features automatic power saving eliminating the need to unplug the power cable. If you have not used the DS600C over an hour, it automatically enters Power Saving Mode. The Message Window will display “Power Saving… ” and the READY LED will flash. To return to the READY Status, press any of the buttons on the Control Panel.

  • Page 28: Technical Support

    4. TECHNICAL SUPPORT Technical support for the DS600C Copier is provided by the Oki Data Customer Support Center. Before you contact us, please have the following information available so we can provide a quick solution: Ÿ DS600C serial & revision number (located on the bottom of the Digital Scan Copier), Ÿ...

  • Page 29: Specifications

    SPECIFICATIONS Copier Specifications Copy Resolution Normal: 300dpi x 300dpi / 360dpi x 360dpi Quality: 600dpi x 600dpi / 720dpi x 720dpi Copy Area Max. 8.5 inches x 14.0 inches (Legal size) Copy Features Zooming from 25%~400% Auto Zooming Auto Photo - Text Separation Printer Interface IEEE 1284 (bi-directional) ECP/SPP...

  • Page 30: Limited Warranty

    You will receive the exchange Avision DS -600 Copier Flatbed Unit the next business day, or no later than the second business day. Return the original Avision DS -600 Copier Flatbed Unit to Oki Data by using the same packaging materials you received with the exchange Avision DS -600 Copier Flatbed Unit.
  • Page 31 Additional information on obtaining service under this Limited Warranty is available by contacting the Oki Data dealer from whom the product was purchased, by contacting Oki Data directly at 1-800-OKI-DATA (U.S. and Canada, English only) or at 1-856-222-5276 (Spanish only), or by contacting one of the service locations listed below.
  • Page 32 Part Number 59331802...
