Page 1: User Manual
P4i45PE+ User Manual Version 1.0 Published November 2003 Copyright©2003 ASRock INC. All rights reserved. -
Page 2: Copyright Notice
ASRock. ASRock assumes no responsibility for any errors or omissions that may appear in this manual. With respect to the contents of this manual, ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warran- ties or conditions of merchantability or fitness for a particular purpose. -
Page 3: Table Of Contents
4.2 Support CD Information ..........23 4.2.1 Running Support CD ..........23 4.2.2 Drivers Menu ............23 4.2.3 Utilities Menu ............23 4.2.4 ASRock “PC-DIY Live Demo” Program ....23 4.2.5 Contact Information ..........23 Appendix ............24 1. Advanced BIOS Setup Menu ........... 24 2. -
Page 4: Introduction
In case any modifications of this manual occur, the updated version will be available on ASRock website without further notice. You may find the latest memory and CPU support lists on ASRock website as well. ASRock website http://www.asrock.com 1.1 Package Contents... -
Page 5: Specifications
Audio: 5.1 channels AC’97 Audio PCI LAN: Speed: 802.3u (10/100 Ethernet), supports Wake-On-LAN Hardware Monitor: CPU temperature sensing (ASRock U-COP); Chassis temperature sensing; CPU overheat shutdown to protect CPU life (ASRock U-COP)(see CAUTION 3); CPU fan tachometer; Chassis fan tachometer;... - Page 6 Microsoft Windows 98 SE / ME / 2000 / XP compliant P4i45PE+ motherboard may be fine tuned to support higher CPU bus frequencies on certain condition (over-clocking mode). Please refer to the NOTE on page 7 for the details. About the setting of “Hyper Threading Technology”, please check page 24.
- Page 7 P4i45PE+ may be fine tuned to support higher CPU front side bus frequencies on certain condition at over-clocking mode. Please refer to the tables below for the details. CPU FSB Configuration Note P4i45PE+ 800 MHz 1. Set the “FSB” jumper to “800” mode (see page 14).
-
Page 8: Motherboard Layout
PS/2 Keyboard CPU_FAN1 COM1 USB 2.0 Ports USB 2.0 Ports Line out Intel Line Line in 845PE Chipset Mic in AUX1 P4i45PE+ AUDIO1 1.5V_AGP1 AUDIO CODEC PCI 1 FSB800 5.1CH DDR400 USB2.0 Intel ICH4 PCI 2 PCI 3 CMOS SATA... -
Page 9: Asrock I/O
1.4 ASRock I/O Parallel Port Line Out (Lime) RJ-45 Port USB 2.0 Ports Game Port Serial Port (COM1) Microphone (Pink) PS/2 Keyboard Port (Purple) Line In (Light Blue) PS/2 Mouse Port (Green) -
Page 10: Installation
Chapter 2 Installation P4i45PE+ is an ATX form factor (12.0-in x 7.0-in, 30.5 cm x 17.8 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to en- sure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. -
Page 11: Cpu Installation
2.3 CPU Installation Step 1. Unlock the socket by lifting the lever up to a 90° angle. Step 2. Position the CPU directly above the socket such that its marked corner matches the base of the socket lever. Step 3. Carefully insert the CPU into the socket until it fits in place. -
Page 12: Installation Of Memory Modules (Dimm)
2.5 Installation of Memory Modules (DIMM) P4i45PE+ motherboard provides two 184-pin DDR (Double Data Rate) DIMM slots. Please make sure to disconnect power supply before adding or removing DIMMs or the system components. Step 1. Unlock a DIMM slot by pressing the retaining clips outward. -
Page 13: Expansion Slots (Pci And Agp Slots)
PCI slots are used to install expansion cards that have the 32-bit PCI interface. AGP slot: The AGP slot is used to install a graphics card. The ASRock AGP slot has a special locking mechanism which can securely fasten the graphics card inserted. -
Page 14: Jumpers Setup
2.8 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short”. If no jumper cap is placed on pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”... -
Page 15: Connectors
2.9 Connectors Connectors are NOT jumpers. DO NOT place jumper caps over these connectors. Connector Figure Description FDD connector (33-pin FLOPPY1) FLOPPY1 Pin1 (see p.8 item 14) the red-striped side to Pin1 Note: Make sure the red-striped side of the cable is plugged into Pin1 side of the connector. - Page 16 SATA HDD power cable to the power power supply power connector connector of the power supply. USB 2.0 Connector ASRock I/O provides you 4 USB_PWR default USB 2.0 ports on the rear (9-pin USB45) DUMMY panel. If the rear USB ports are (see p.8 item 18)
-
Page 17: Serial Ata (Sata) Hard Disks Installation
Chassis Fan Connector Please connect a chassis fan +12V cable to this connector and (3-pin CHA_FAN1) CHA_FAN_SPEED match the black wire to the (see p.8 item 12) ground pin. CPU Fan Connector Please connect a CPU fan cable CPU_FAN_SPEED +12V to this connector and match (3-pin CPU_FAN1) the black wire to the ground pin. -
Page 18: Making An Sata Driver Diskette
SATA HDDs on your system, you will need to make an SATA driver diskette before you start the OS installation. STEP 1: Insert the ASRock Support CD into your optical drive to boot your system. (Do NOT insert any floppy diskette into the floppy drive at this moment!) STEP 2: During POST at the beginning of system boot-up, press <F11>... -
Page 19: Bios Setup
Chapter 3 BIOS Setup 3.1 BIOS Setup Utility This section explains how to configure your system using the BIOS Setup Utility. The BIOS FWH chip on the motherboard stores the BIOS Setup Utility. When you start up the computer, there is a chance for you to run the BIOS Setup. Press <F2> during the Power-On-Self-Test (POST) to enter the BIOS Setup Utility, otherwise, POST continues with its test routines. -
Page 20: Main Menu
16:07:40 Month: Jan - Dec Day: 01 - 31 Floppy Drives Year: 1980 - 2099 IDE Devices BIOS Version P4i45PE+ BIOS P2.30 Processor Type Pentium (R) 4 CPU Processor Speed 2400 MHz Cache Size 512 KB Microcode Update F24 / 18... - Page 21 TYPE To set the type of the IDE device, first, please select “IDE Devices” on Main menu and press <Enter> to get into the sub-menu. Then, select among “Primary IDE Master”, “Primary IDE Slave”, “Secondary IDE Master”, and “Secondary IDE Slave” to make configuration of its type. After making your selections on this sub-menu, press <ESC>...
-
Page 22: Advanced, Security, Power, Boot, And Exit Menus
[CD/DVD] This is used for IDE CD/DVD drives. [ARMD] This is used for IDE ARMD (ATAPI Removable Media Device), such as MO. Cylinders This is used to configure the number of cylinders. Refer to the drive documentation to determine the correct value. Heads This is used to configure the number of read/write heads. -
Page 23: Software Support
To see this demo program, you may run Microsoft Media Player to play the file. 4.2.5 Contact Information If you need to contact ASRock or want to know more about ASRock, welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. -
Page 24: Appendix
Appendix: Advanced BIOS Setup This section will introduce you the following BIOS Setup menus: “Advanced,” “Security,” “Power,” “Boot,” and “Exit.” 1. Advanced BIOS Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Main Advanced Power [ Setup Help ] Spread Spectrum Disabled Auto... - Page 25 Chipset Configuration AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Chipset Configuration [ Setup Help ] AGP Aperture Size 64MB <Enter> to select the ICH Delayed Transaction Disabled size of mapped memory for graphics data. USB Controller Enabled USB Device Legacy Support Disabled CPU Thermal Throttling Enabled...
- Page 26 Configure SDRAM Timing by SPD Select [Enabled] will configure the following 3 items by the contents in the SPD (Serial Presence Detect) device. SDRAM RAS# Precharge This controls the idle clocks after a precharge command is issued. SDRAM RAS# to CAS# Delay This controls the latency between the SDRAM active command and the read / write command.
- Page 27 Peripheral Configuration AMIBIOS SETUP UTILITY - VERSION 3.31a Advanced Peripheral Configuration [ Setup Help ] <Enter> to enable or disable the floppy Auto OnBoard FDC drive controller. OnBoard Serial Port Auto OnBoard Infrared Port Disabled OnBoard Parallel Port Auto Parallel Port Mode ECP + EPP EPP Version Parallel Port IRQ...
- Page 28 OnBoard IDE You may enable either the primary IDE channel or the secondary IDE channel. Or you may enable both the primary and the secondary IDE channels by selecting [Both]. Set to [Disabled] will disable the both. Configuration options: [Disabled], [Primary], [Secondary], [Both]. OnBoard LAN This allows you to enable or disable the on-board LAN feature.
-
Page 29: Security Setup Menu
2. Security Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Advanced Power Main [ Setup Help ] Clear Supervisor Password Is Clear User Password Is <Enter> to enable or disable the quick boot Set Supervisor Password [ Enter ] mode. -
Page 30: Power Setup Menu
3. Power Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Exit Advanced Security Power Boot Main [ Setup Help ] Suspend To RAM Disabled Repost Video on STR Resume Disabled <Enter> to select Restore on AC / Power Loss Power Off auto-detect or disable Ring-In Power On Disabled... -
Page 31: Boot Setup Menu
4. Boot Setup Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Boot Exit Advanced Security Power Main [ Setup Help ] Quick Boot Mode Enabled Boot Up Num-Lock <Enter> to enable or Boot To OS/2 disable the quick boot Boot From Network Disabled mode. -
Page 32: Exit Menu
5. Exit Menu AMIBIOS SETUP UTILITY - VERSION 3.31a Security Boot Exit Advanced Power Main [ Setup Help ] [ Enter ] Exit Saving Changes [ Enter ] Exit Discarding Changes Exits and saves the [ Enter ] Load Default Settings changes in CMOS RAM.
