1.7.4
Removing a DIMM
To remove a DIMM:
1.
Simultaneously press the retaining clips
outward to unlock the DIMM.
Support the DIMM lightly with
your fingers when pressing the
retaining clips. The DIMM might
get damaged when it flips out with
extra force.
2.
Remove the DIMM from the socket.
1-18
2
1
DDR3 DIMM notch
Chapter 1: Product introduction
1
