  • Page 1 P5P43TD/USB3...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Welcome! ..................1-1 Package contents ................. 1-1 Special features ................1-1 1.3.1 Product highlights ............1-1 1.3.2 Innovative ASUS features ..........1-2 Before you proceed ..............1-4 Motherboard overview ..............1-5 1.5.1 Placement direction ............1-5 1.5.2 Screw holes ..............1-5 1.5.3...
  • Page 4 BIOS information Managing and updating your BIOS ..........2-1 2.1.1 ASUS Update utility ............2-1 2.1.2 ASUS EZ Flash 2 ............2-2 2.1.3 ASUS CrashFree BIOS 3 ..........2-3 BIOS setup program ..............2-4 2.2.1 BIOS menu screen ............2-5 2.2.2...
  • Page 5 Boot Device Priority ............2-20 2.7.2 Boot Settings Configuration .......... 2-21 2.7.3 Security ................. 2-21 Tools menu ................. 2-23 2.8.1 ASUS EZ Flash 2 ............2-23 2.8.2 Express Gate ..............2-23 2.8.3 AI NET 2................ 2-23 Exit menu ..................2-24...

  • Page 6: Notices

    Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://green.asus.com/english/REACH.htm. DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling.

  • Page 7: Safety Information

    Safety information Electrical safety • To prevent electric shock hazard, disconnect the power cable from the electric outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 8: Conventions Used In This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 9: P5P43Td/Usb3 Specifications Summary

    We recommend that you install the memory modules on the blue slots for better overclocking capability. ** Refer to www.asus.com or this user manual for the Memory QVL (Qualified Vendors Lists). *** When you install a total memory of 4GB capacity...
  • Page 10 ASUS Turbo Key features ASUS EPU-4 Engine Stack Cool 3 Anti-Surge Protection ASUS Express Gate ASUS CrashFree BIOS 3 ASUS EZ Flash 2 ASUS Q-Fan 2 ASUS AI NET 2 ASUS MyLogo 2 Rear panel ports 1 x PS/2 Mouse port...

  • Page 11: Chapter 1: Product Introduction

    ® The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards! Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

  • Page 12: Innovative Asus Features

    ASUS Turbo Key ASUS Turbo Key allows you to turn the PC power button into an overclocking button. After you easy setup, Turbo Key boosts performances without interrupting ongoing work or games, simply through pressing the button.

  • Page 13: Asus Express Gate

    ASUS EZ Flash 2 ASUS EZ Flash 2 is a utility that allows you to update the BIOS without using an OS-based utility. ASUS AI NET 2...

  • Page 14: Before You Proceed

    Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity.

  • Page 15: Motherboard Overview

    Screw holes Place six screws into the holes indicated by circles to secure the motherboard to the chassis. Do not overtighten the screws! Doing so can damage the motherboard. Place this side towards the rear of the chassis ASUS P5P43TD/USB3...

  • Page 16: Motherboard Layout

    1.5.3 Motherboard layout 1.5.4 Layout contents Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page CPU and chassis fan connectors (4-pin CPU_FAN, 1-21 System panel connector (20-8 pin PANEL) 1-25 3-pin CHA_FAN) ATX power connectors (24-pin EATXPWR, 4-pin 1-22 IDE connector (40-1 pin PRI_EIDE) 1-24 ATX12V) LGA775 CPU socket USB connectors (10-1 pin USB78, USB910,...

  • Page 17: Central Processing Unit (Cpu)

    Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA775 socket.
  • Page 18 Press the load lever with your thumb Retention tab (A), then move it to the left (B) until it is released from the retention tab. To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU. Load lever Lift the load lever in the direction of the PnP cap...
  • Page 19 To prevent contaminating the paste, DO NOT spread the paste with your finger directly. Close the load plate (A), then push the load lever (B) until it snaps into the retention tab. ASUS P5P43TD/USB3...

  • Page 20: Installing The Cpu Heatsink And Fan

    1.6.2 Installing the CPU heatsink and fan The Intel LGA775 processor requires a specially designed heatsink and fan assembly to ® ensure optimum thermal condition and performance. • When you buy a boxed Intel processor, the package includes the CPU fan and ®...

  • Page 21: Uninstalling The Cpu Heatsink And Fan

    To uninstall the CPU heatsink and fan: Disconnect the CPU fan cable from the connector on the motherboard. Rotate each fastener counterclockwise. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard. ASUS P5P43TD/USB3 1-11...

  • Page 22: System Memory

    Carefully remove the heatsink and fan assembly from the motherboard. Rotate each fastener clockwise to ensure correct orientation when reinstalling. System memory 1.7.1 Overview This motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory Modules (DIMM) sockets. A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched differently to prevent installation on a DDR2 DIMM socket.

  • Page 23: Memory Configurations

    KINGMAX FLGD45F-B8KG9-NAES 1024MB SS KINGMAX KFB8FNGXF-ANX- 9(1600-9-8-9-28) • • KINGMAX FLGE85F-B8KG9-NEES 2048MB DS KINGMAX KFB8FNGXF-ANX- 9(1600-9-8-9-28) • • • KINGSTON KHX12800D3LLK3/3GX(XMP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 1600-8-8-8-20 1.65 • • (continued on the next page) ASUS P5P43TD/USB3 1-13...
  • Page 24 DDR3-1600 (O.C.) MHz capability DIMM socket support Chip Vendor Part No. Size Chip No. Timing DIMM (BIOS) Voltage (Optional) Brand KINGSTON KHX12800D3K2/4G 4096MB(Kit of 2) DS N/A Heat-Sink Package 9(1333-9-9-9-24) • • OCZ3G1600LV3GK 3072MB(Kit of 3) SS N/A Heat-Sink Package 8-8-8(1066-7-7-7-20) 1.65 •...

  • Page 25: Ddr3-1333 Mhz Capability

    SAMSUNG M378B5273CH0-CH9 4096MB SAMSUNG K4B2G0846C • • • Super Talent W1333X2GB8(XMP) 1024MB • • • Transcend JM1333KLU-1G 1024MB Transcend TK243EDF3 • • • Transcend JM1333KLU-2G 2048MB Transcend TK243EAF3 • Transcend TS256MLK64V3U 2048MB Micron 9GF27D9KPT • • • ASUS P5P43TD/USB3 1-15...
  • Page 26 • B*: Supports one pair of modules inserted into either the blue or black slots as one pair of Dual-channel memory configuration. • C*: Supports four modules inserted into both the blue and black slots as two pairs of Dual-channel memory configuration. Visit the ASUS website at www.asus.com for the latest QVL. 1-16 Chapter 1: Product introduction...

  • Page 27: Installing A Dimm

    DIMM. Support the DIMM lightly with your fingers when pressing the retaining clips. The DIMM might get damaged when it flips out with extra force. DIMM notch Remove the DIMM from the socket. ASUS P5P43TD/USB3 1-17...

  • Page 28: Expansion Slots

    Expansion slots In the future, you may need to install expansion cards. The following sub-sections describe the slots and the expansion cards that they support. Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

  • Page 29: Jumpers

    • You do not need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the CPU Parameter Recall (C.P.R.) feature. Shut down and reboot the system, then the BIOS automatically resets parameter settings to default values. ASUS P5P43TD/USB3 1-19...

  • Page 30: Connectors

    1.10 Connectors 1.10.1 Rear panel connectors PS/2 Mouse port (green). This port is for a PS/2 mouse. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications. LAN port LED indications SPEED ACT/LINK...

  • Page 31: Internal Connectors

    Do not forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! Only the 4-pin CPU fan and chassis fan support the ASUS Q-FAN 2 feature. ASUS P5P43TD/USB3 1-21...
  • Page 32 ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. •...
  • Page 33 Front Panel Type item in the BIOS setup to [HD Audio]. If you want to connect an AC'97 front panel audio module to this connector, set the item to [AC97]. By default, this connector is set to [HD Audio]. See section 2.5.3 Onboard Devices Configuration for details. ASUS P5P43TD/USB3 1-23...
  • Page 34 IDE connector (40-1 pin PRI_EIDE) The onboard IDE connector is for the Ultra DMA 133/100/66 signal cable. There are three connectors on each Ultra DMA 133/100/66 signal cable: blue, black, and gray. Connect the blue connector to the motherboard’s IDE connector, then select one of the following modes to configure your device.

  • Page 35: System Panel Connector

    ATX power button/soft-off button (2-pin PWRSW) This connector is for the system power button. • Reset button (2-pin RESET) This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power. ASUS P5P43TD/USB3 1-25...
  • Page 36 USB connectors (10-1 pin USB78, USB910, USB1112) These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed.

  • Page 37: Software Support

    Place the Support DVD to the optical drive. If Autorun is enabled in your computer, the DVD automatically displays the Specials screen which contains the unique feature of ASUS motherboard. Click Drivers, Utilities, Make Disk, Manual, and Contact tabs to display their respective menus.
  • Page 38 1-28 Chapter 1: Product introduction...

  • Page 39: Chapter 2: Bios Information

    BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility. 2.1.1 ASUS Update utility The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows environment. ®...

  • Page 40: Asus Ez Flash 2

    Follow the onscreen instructions to complete the updating process. 2.1.2 ASUS EZ Flash 2 The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS-based utility. Before you start using this utility, download the latest BIOS file from the ASUS website at www.asus.com.

  • Page 41: Asus Crashfree Bios 3

    2.1.3 ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a removable device that contains the updated BIOS file.

  • Page 42: Bios Setup Program

    • The BIOS setup screens in this chapter are for reference only. They may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. Chapter 2: BIOS information...

  • Page 43: Bios Menu Screen

    For configuring options for special functions. Exit For selecting the exit options and loading default settings. To select an item on the menu bar, press the right or left arrow key on the keyboard until the desired item is highlighted. ASUS P5P43TD/USB3...

  • Page 44: Navigation Keys

    2.2.3 Navigation keys At the bottom right corner of a menu screen are the navigation keys for that particular menu. Use the navigation keys to select items in the menu and change the settings. Some of the navigation keys differ from one screen to another. 2.2.4 Menu items The highlighted item on the menu bar displays the specific items for that menu.

  • Page 45: Main Menu

    SATA device type. Select [CDROM] if you are specifically configuring a CD-ROM drive. Select [ARMD] (ATAPI Removable Media Device) if your device is either a ZIP, LS-120, or MO drive. Configuration options: [Not Installed] [Auto] [CDROM] [ARMD] This item only appears in the SATA 1~4 menus. ASUS P5P43TD/USB3...

  • Page 46: Storage Configuration

    LBA/Large Mode [Auto] Enables or disables the LBA mode. Setting to [Auto] enables the LBA mode if the device supports this mode, and if the device was not previously formatted with LBA mode disabled. Configuration options: [Disabled] [Auto] Block (Multi-sector Transfer) M [Auto] Enables or disables data multi-sectors transfers.

  • Page 47: System Information

    CPU Margin Enhancement [Optimized] Memory Over Voltage [Auto] Chipset Over Voltage [Auto] VTT Over Voltage [Auto] CPU VCORE Over-Voltage [Auto] Select Screen Select Item Change Field General Help Save and Exit Exit v02.61 (C) Copyright 1985-2010, American Megatrends, Inc. ASUS P5P43TD/USB3...
  • Page 48 Ai Overclock Tuner [Auto] Allows selection of CPU overclocking options to achieve desired CPU internal frequency. Select either one of the preset overclocking configuration options: Manual - Allows you to individually set overclocking parameters. Auto - Loads the optimal settings for the system. X.M.P.
  • Page 49 Clocks] [100 DRAM Clocks] [110 DRAM Clocks] Writer Recovery Time [Auto] Read to Precharge Time [Auto] Configuration options: [Auto] [1 DRAM Clocks] [2 DRAM Clocks] [3 DRAM Clocks] [4 DRAM Clocks] ~ [13 DRAM Clocks] [14 DRAM Clocks] [15 DRAM Clocks] ASUS P5P43TD/USB3 2-11...
  • Page 50 READ to WRITE Delay (S/D) [Auto] WRITE to READ Delay (S) [Auto] WRITE to READ Delay (D) [Auto] READ to READ Delay (S) [Auto] READ to READ Delay (D) [Auto] WRITE to WRITE Delay (S) [Auto] WRITE to WRITE Delay (D) [Auto] Configuration options: [Auto] [1 DRAM Clocks] [2 DRAM Clocks] [3 DRAM Clocks] [4 DRAM Clocks] ~ [13 DRAM Clocks] [14 DRAM Clocks] [15 DRAM Clocks] WRITE to PRE Delay [Auto]...
  • Page 51 CPU VCORE Over-Voltage [Auto] Allows you to set the CPU Vcore over voltage. The values range from 0.01000V to 0.63000V with a 0.00625V interval. Use the <+> and <-> keys to adjust the value. Configuration options: [Auto] ASUS P5P43TD/USB3 2-13...

  • Page 52: Advanced Menu

    Advanced menu The Advanced menu items allow you to change the settings for the CPU and other system devices. Take caution when changing the settings of the Advanced menu items. Incorrect field values can cause the system to malfunction. BIOS SETUP UTILITY Main Ai Tweaker Advanced...

  • Page 53: Chipset

    Configuration options: [Disabled] [Enabled] JMB368 IDE BOOT ROM [Enabled] Allows you to enable or disable the JMB368 IDE Boot ROM. This item appears only when the JMB368 IDE item is set to Enabled. Configuration options: [Disabled] [Enabled] ASUS P5P43TD/USB3 2-15...

  • Page 54: Usb Configuration

    Onboard LAN [Enabled] Allows you to enable or disable the onboard LAN controller. Configuration options: [Enabled] [Disabled] LAN Option ROM [Disabled] Allows you to enable or disable the boot ROM in the onboard LAN controller. This item appears only when the Onboard LAN item is set to Enabled. Configuration options: [Disabled] [Enabled] Serial Port1 Address [3F8/IRQ4] Allows you to select the Serial Port1 base address.

  • Page 55: Pci Pnp

    When set to [No], BIOS configures all the devices in the system. When set to [Yes] and if you install a Plug and Play operating system, the operating system configures the Plug and Play devices not required for boot. Configuration options: [No] [Yes] ASUS P5P43TD/USB3 2-17...

  • Page 56: Power Menu

    Power menu The Power menu items allow you to change the settings for the Advanced Power Management (APM). Select an item then press <Enter> to display the configuration options. BIOS SETUP UTILITY Main Ai Tweaker Advanced Power Boot Tools Exit Select the ACPI state Suspend Mode [Auto]...

  • Page 57: Hardware Monitor

    CPU temperature. Sets this item to [Silent Mode] to minimize the fan speed for quiet CPU fan operation, or [Performance Mode] to achieve maximum CPU fan speed. Configuration options: [Optimal] [Silent Mode] [Performance Mode] ASUS P5P43TD/USB3 2-19...

  • Page 58: Anti Surge Support

    Configuration options: [Removable Dev] [Hard Drive] [ATAPI CD-ROM] [Disabled] • To select the boot device during system startup, press <F8> when ASUS Logo appears. • To access Windows OS in Safe Mode, do any of the following: ®...

  • Page 59: Boot Settings Configuration

    POST items. Configuration options: [Disabled] [Enabled] Full Screen Logo [Enabled] This allows you to enable or disable the full screen logo display feature. Configuration options: [Disabled] [Enabled] Set this item to [Enabled] to use the ASUS MyLogo2 feature. ™ AddOn ROM Display Mode [Force BIOS] Sets the display mode for option ROM.

  • Page 60: Change User Password

    If you forget your BIOS password, you can clear it by erasing the CMOS Real Time Clock (RTC) RAM. See section 1.9 Jumpers for information on how to erase the RTC RAM. After you have set a supervisor password, the other items appear to allow you to change other security settings.

  • Page 61: Tools Menu

    2.8.1 ASUS EZ Flash 2 Allows you to run ASUS EZ Flash 2. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice. See section 2.1.2 for details.

  • Page 62: Exit Menu

    Exit menu The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. BIOS SETUP UTILITY Main Ai Tweaker Advanced Power Boot Tools Exit Exit Options Exit system setup...

  • Page 63: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site usa.asus.com Technical Support Telephone +1-812-282-2787 Support fax +1-812-284-0883 Online support support.asus.com ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany +49-2102-959911 Web site www.asus.de Online contact www.asus.de/sales Technical Support Telephone (Component) +49-1805-010923*...
