Cheetah 9LP Family:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ST39102LW/LC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ST34502LW/LC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Manual, Volume 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST39102LC - Cheetah 9.1 GB Hard Drive and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Seagate ST39102LC - Cheetah 9.1 GB Hard Drive

  • Page 1 ..........Cheetah 9LP Family: .
  • Page 3 ..........Cheetah 9LP Family: .
  • Page 4 Seagate, Seagate Technology, and the Seagate logo are registered trademarks of Seagate Technology, Inc. Cheetah, SeaFAX, SeaFONE, SeaBOARD, and SeaTDD are either trademarks or registered trade- marks of Seagate Technology, Inc. or one of its subsidiaries. All other trademarks or registered trade- marks are the property of their respective owners.
  • Page 5 Revision status summary sheet Revision Date Writer/Engineer Sheets Affected Rev. A 04/16/98 L. Newman/J. Nowitzke 1/1, v thru viii, 1-82 Rev. B 07/13/98 L. Newman/J. Nowitzke Adds ST34502 models. Changes on pages 8, 43, 45, 51, 52, 59, 63, and 64. Rev.
  • Page 7: Table Of Contents

    Cheetah 9LP Product Manual, Rev. C Contents Scope ................1 Applicable standards and reference documentation.
  • Page 8 Seagate Technology support services........
  • Page 9 Cheetah 9LP Product Manual, Rev. C List of Figures Figure 1. Cheetah 9LP family drive (ST39102LW shown) ........1 Figure 2.
  • Page 11: Scope

    Cheetah 9LP Product Manual, Rev. C Scope This manual describes Seagate Technology®, Inc. Cheetah 9LP™ disc drives. Cheetah 9LP drives support the small computer system interface (SCSI) as described in the ANSI SCSI, SCSI-2, and SCSI-3 (Fast-20 and Fast-40) interface specifications to the extent described in this manual. The SCSI Interface Product Manual (part number 77738479) describes general SCSI interface characteristics of this and other families of Seagate drives.
  • Page 13: Applicable Standards And Reference Documentation

    Mounting by bottom holes must meet the requirements of Section 8.4. Standards The Cheetah 9LP family complies with Seagate standards as noted in the appropriate sections of this Manual and the Seagate SCSI Interface Product Manual , part number 77738479 (Vol. 2).
  • Page 14: Reference Documents

    T10/1142D Rev. 14 SPI-2 (SCSI-3 Parallel Interface version 2) SFF-8046 Specification for 80-pin connector for SCSI disk drives Package Test Specification Seagate P/N 30190-001 (under 100 lb.) Package Test Specification Seagate P/N 30191-001 (over 100 lb.) Specification, Acoustic Test Requirements, and Procedures Seagate P/N 30553-001 In case of conflict between this document and any referenced document, this document takes precedence.
  • Page 15: General Description

    Cheetah 9LP family of drives, and the SCSI Interface Product Manual (volume 2), part number 77738479, which describes the general interface characteristics of this and other families of Seagate SCSI drives. The drive’s interface supports multiple initiators, disconnect/reconnect, self-configuring host software, and automatic features that relieve the host from the necessity of knowing the physical characteristics of the targets (logical block addressing is used).
  • Page 16: Figure 2. Cheetah 9Lp Family Drive

    Cheetah 9LP Product Manual, Rev. C Figure 2. Cheetah 9LP family drive...
  • Page 17: Standard Features

    Cheetah 9LP Product Manual, Rev. C Standard features The Cheetah 9LP family has the following standard features: • Integrated Ultra/Ultra2 SCSI controller • Multimode SCSI drivers and receivers—single-ended (SE) and low voltage differential (LVD) • 16 bit I/O data bus •...
  • Page 18: Unformatted And Formatted Capacities

    Cheetah 9LP Product Manual, Rev. C Unformatted and formatted capacities Formatted capacity depends on the number of spare reallocation sectors reserved and the number of bytes per sector. The following table shows the standard OEM model capacities: Formatted data block size 512 bytes/sector [1] Unformatted ST39102...
  • Page 19: Performance Characteristics

    Cheetah 9LP Product Manual, Rev. C Performance characteristics Internal drive characteristics (transparent to user) ST39102 ST34502 Drive capacity 9.10 4.55 GByte (formatted, rounded off values) Read/write heads Bytes/track 104,840–159,008 104,840–159,008 Bytes (average, rounded off values) Bytes/surface Mbytes (unformatted, rounded off values) Tracks/surface (total) 6,962 6,962...
  • Page 20: Start/Stop Time

    Cheetah 9LP Product Manual, Rev. C Sector Sizes: Default 512 byte user data blocks Variable 180 to 4,096 bytes per sector in even number of bytes per sector. If n (number of bytes per sector) is odd, then n-1 will be used. Read/write consecutive sectors on a track Flaw reallocation performance impact (for flaws reallocated at format time using Negligible...
  • Page 21: Caching Write Data

    Cheetah 9LP Product Manual, Rev. C number 77738479), data requested by the host with a Read command is retrieved from the buffer (if it is there), before any disc access is initiated. If cache operation is not enabled, the buffer (still segmented with required number of segments) is still used, but only as circular buffer segments during disc medium read operations (disregarding Prefetch operation for the moment).
  • Page 22: Prefetch Operation

    Cheetah 9LP Product Manual, Rev. C The Synchronize Cache command may be used to force the drive to write all cached write data to the medium. Upon completion of a Synchronize Cache command, all data received from previous write commands will have been written to the medium.
  • Page 23: Reliability Specifications

    Cheetah 9LP Product Manual, Rev. C Reliability specifications The following reliability specifications assume correct host/drive operational interface, including all interface timings, power supply voltages, environmental requirements and drive mounting constraints (see Section 8.4). Seek Errors Less than 10 in 10 seeks Read Error Rates [1] Recovered Data...
  • Page 24: Reliability And Service

    Cheetah 9LP Product Manual, Rev. C unrecoverable seek error. Unrecoverable seek errors are classified as failures for MTBF calculations. Refer to Section 5.1.1.2 of the SCSI Interface Product Manual, part number 77738479, for Request Sense information. Reliability and service You can enhance the reliability of Cheetah 9LP disc drives by ensuring that the drive receives adequate cool- ing.
  • Page 25: Preventive Maintenance

    Case 4 - Current I/O process allowed during insertion or removal, except on the device being changed Seagate Cheetah 9LP disc drives support all four hot plugging cases. Provision shall be made by the system such that a device being inserted makes power and ground connections prior to the connection of any device signal contact to the bus.
  • Page 26: S.m.a.r.t

    Cheetah 9LP Product Manual, Rev. C 5.2.8 S.M.A.R.T. S.M.A.R.T. is an acronym for Self-Monitoring Analysis and Reporting Technology. This technology is intended to recognize conditions that indicate a drive failure and is designed to provide sufficient warning of a failure to allow data back-up before an actual failure occurs.
  • Page 27: Product Warranty

    Seagate’s option and at no charge to customer, if returned by customer at cus- tomer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. Seagate will pay for transporting the repair or replacement item to customer.
  • Page 29: Physical/Electrical Specifications

    Cheetah 9LP Product Manual, Rev. C Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the Cheetah 9LP drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown in the following table. Values indicated apply at the drive power connector.
  • Page 30: Conducted Noise Immunity

    Cheetah 9LP Product Manual, Rev. C 3. Where power is provided to multiple drives from a common supply, careful consideration for individual drive power requirements should be noted. Where multiple units are powered on simultaneously, the peak start- ing current must be available to each device. 4.
  • Page 31: Figure 3. Typical Cheetah 9Lp Family Drive +12 V Current Profile

    Cheetah 9LP Product Manual, Rev. C +12 Volt Current during spindle start – Typical Amperes Peak AC Peak DC Min. AC T0 T1 Seconds Figure 3. Typical Cheetah 9LP family drive +12 V current profile...
  • Page 32: Power Dissipation

    Cheetah 9LP Product Manual, Rev. C Power dissipation ST39102 For drives using single-ended interface circuits, typical operating random read power dissipation is 13.4 watts (46 BTUs per hour) of DC power average at nominal voltages. Typical power dissipation under idle conditions is 11.1 watts (38 BTUs per hour).
  • Page 33: Relative Humidity

    Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. HDA Temp.
  • Page 34: Effective Altitude (Sea Level)

    36 in (914 mm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or...
  • Page 35: Figure 5. Recommended Mounting

    Cheetah 9LP Product Manual, Rev. C Figure 5. Recommended mounting...
  • Page 36: Air Cleanliness

    There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive.
  • Page 37: Mechanical Specifications

    Cheetah 9LP Product Manual, Rev. C Mechanical specifications The following nominal dimensions are exclusive of the decorative front panel accessory. However, dimensions of the front panel are shown in figure below. Refer to Figures 6 and 7 for detailed mounting configuration dimensions.
  • Page 38: Figure 7. St39102Lc And St34502Lc Mounting Configuration Dimensions

    Cheetah 9LP Product Manual, Rev. C Notes: Mounting holes are 6-32 UNC 2B, three -Z- -X- on each side and four on the bottom. Max screw penetration into side of drive is 0.15 in. (3.81 mm). Max screw tightening torque is 6.0 in-lb (3.32 nm) with minimum full thread engagement of 0.12 in.
  • Page 39: Defect And Error Management

    Cheetah 9LP Product Manual, Rev. C Defect and error management The drive, as delivered, complies with this specification. The read error rate and specified storage capacity are not dependent upon use of defect management routines by the host (initiator). Defect and error management in the SCSI system involves the drive internal defect/error management and SCSI systems error considerations (errors in communications between Initiator and the drive).
  • Page 40: Scsi Systems Errors

    Cheetah 9LP Product Manual, Rev. C Table 4: Read and write retry count maximum recovery times [1] Read retry Maximum recovery time per Write retry Maximum recovery time per count [1] LBA (cumulative, msec) count LBA (cumulative, msec) 65.7 35.8 77.6 53.7 89.6...
  • Page 41: Installation

    J2, J5-Auxiliary and J6. Suggested part number for the jumpers used on J2 is Molex 52747-0211 (Seagate part number 77679052). A bag with the two jumper plug types is shipped with the standard OEM drives.
  • Page 42: Figure 8. J6 Jumper Header

    Cheetah 9LP Product Manual, Rev. C Drive Front Jumper Plug (enlarged to show detail) Pin 1 Reserved A 2 A 1 A 0 SCSI ID = 0 (default) SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5 SCSI ID = 6...
  • Page 43: Figure 9. J5 Jumper Header (On Lw Models Only)

    Cheetah 9LP Product Manual, Rev. C Drive HDA (rear view, PCB facing downward) [1] [2] Pin 1 +5V Ground Pin 1 J1-DC Power 68 Pin SCSI ID = 0 (default) SCSI I/O Connector SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5...
  • Page 44: Notes For Figures 8, 9, And 10

    Cheetah 9LP Product Manual, Rev. C Pin 1 Jumper Positions Force single-ended bus mode Delay Motor Start Enable Remote Motor Start Write Protect Parity Disable Reserved Additional notes on these (applies to “LW” model only; Term. Power to SCSI Bus functions in section 8.1.2.
  • Page 45: Function Description

    Cheetah 9LP Product Manual, Rev. C 8.1.2 Function description jumper installation Jumper function description Forces drive to use single-ended I/O drivers/receivers only. Drive can operate on the interface in low voltage differential mode or single-ended, depend- ing on the voltage state of the I/O “DIFFSNS” line. Default is SE jumper not installed. Spindle starts immediately after power up - Default setting.
  • Page 46: Drive Orientation

    Cheetah 9LP Product Manual, Rev. C Drive orientation The balanced rotary arm actuator design of the drive allows it to be mounted in any orientation. All drive perfor- mance characterization, however, has been done with the drive in horizontal (discs level) and vertical (drive on its side) orientations, and these are the two preferred mounting orientations.
  • Page 47: Drive Mounting

    (F) is applied to the fourth point. Note. Before mounting the drive in any kind of 3.5-inch to 5.25-inch adapter frame, verify with Seagate Tech- nology that the drive can meet the shock and vibration specifications given herein while mounted in such an adapter frame.
  • Page 49: Interface Requirements

    No attempt is made to describe all of the minute details of conditions and constraints that must be considered by designers when designing a system in which this family of drives can properly operate. Seagate declares that the drives operate in accordance with the appropriate ANSI Standards referenced in various places herein, with exceptions as noted herein or in the Seagate SCSI Interface Product Manual , part number 77738479.
  • Page 50: Scsi Interface Commands Supported

    Cheetah 9LP Product Manual, Rev. C SCSI interface commands supported Table 6 following lists the SCSI interface commands that are supported in the SCSI-2, and SCSI-3 modes of the drive. Cheetah 9LP Family drives can be changed back and forth between SCSI-1 and SCSI-2/SCSI-3 modes using the Change Definition Command.
  • Page 51 Cheetah 9LP Product Manual, Rev. C Table 6: Commands supported by Cheetah 9LP family drive (Continued) Command Supported by Command name code SCSI-2/3 Error recovery page (01h) Format page (03h) Information exceptions control page (1Ch) Notch and Partition Page (0Ch) Power condition page (1Ah) Rigid disc drive geometry page (04h) Unit attention page (00h)
  • Page 52 Cheetah 9LP Product Manual, Rev. C Table 6: Commands supported by Cheetah 9LP family drive (Continued) Command Supported by Command name code SCSI-2/3 Test unit ready Verify BYTCHK bit Write Write and verify DPO bit Write buffer (modes 0, 2, supported) Firmware download option (modes 5, 7 supported) [3] Write extended DPO bit...
  • Page 53: Inquiry Vital Product Data

    Cheetah 9LP Product Manual, Rev. C Table 7 lists the Standard Inquiry command data that the drive should return to the initiator per the format given in the SCSI Interface Product Manual, part number 77738479, Section 5.1.1.3. Table 7: Cheetah 9LP family drive Standard Inquiry data Bytes Data (HEX) 0-15...
  • Page 54: Mode Sense Data

    Cheetah 9LP Product Manual, Rev. C 9.3.2 Mode Sense data The Mode Sense command provides a means for the drive to report its operating parameters to the initiator. The drive maintains four sets of Mode parameters, Default values, Saved values, Current values and Change- able values.
  • Page 55 Cheetah 9LP Product Manual, Rev. C The following tables list the values of the data bytes returned by the drive in response to the Mode Sense com- mand pages for SCSI-2/SCSI-3 implementation (see the SCSI Interface Product Manual , part number 77738479).
  • Page 56 Cheetah 9LP Product Manual, Rev. C Table 9: Mode sense data, ST34502 values (SCSI-2/3 implementation) Bytes 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Mode 9F 00 10 08 00 87 A2 5C 00 00 02 00 Sense...
  • Page 57: Scsi Bus Conditions And Miscellaneous Features Supported

    Cheetah 9LP Product Manual, Rev. C SCSI bus conditions and miscellaneous features supported Asynchronous SCSI bus conditions supported by the drive are listed below. These conditions cause the SCSI device to perform certain actions and can alter the SCSI bus phase sequence. Other miscellaneous operating features supported are also listed here.
  • Page 58: Synchronous Data Transfer

    Details of the physical, electrical and logical characteristics are given in sections following, while the SCSI operational aspects of Seagate drive interfaces are given in the SCSI Interface Product Manual , part number 77738479. 9.6.1...
  • Page 59: Figure 12. St39102Lw And St34502Lw Drive Physical Interface (68-Pin J1 Scsi I/O Connector)

    Cheetah 9LP Product Manual, Rev. C Power +12V +12V ret + 5V ret + 5V Pin 1 Pin 1A J1-DC Power J1-DC Power Pin 1P Pin 1A Pin 1 68 Pin SCSI I/O Connector Figure 12. ST39102LW and ST34502LW drive physical interface (68-pin J1 SCSI I/O connector) 80-pin SCSI I/O Connector...
  • Page 60: Scsi Interface Physical Description

    Cheetah 9LP Product Manual, Rev. C 9.6.2 SCSI interface physical description The drive models described by this product manual support the physical interface requirements of the SCSI-3 Parallel Interface-2 (SPI-2) standards as defined in American National Standard document X3T10/1142D revi- sion 14, and operate compatibly at the interface with devices that support earlier SCSI-2 and SCSI-3 stan- dards.
  • Page 61: Mating Connectors

    Cheetah 9LP Product Manual, Rev. C To minimize discontinuances and signal reflections, cables of different impedances should not be used in the same bus. Implementations may require trade-offs in shielding effectiveness, cable length, number of loads and spacing, transfer rates, and cost to achieve satisfactory system operation. If shielded and unshielded cables are mixed within the same SCSI bus, the effect of impedance mismatch must be carefully considered.
  • Page 62: Figure 14. Scsi Daisy Chain Interface Cabling For Lw Drives

    Cheetah 9LP Product Manual, Rev. C Recommended mating 80-position PCBA mount connectors: Straight-in connector Hot plug version (with ground guide-pin) Seagate P/N: 77678703 Amp US P/N: 2-557103-1 787311-1 with polarization 94-0680-02-1 Amp US P/N: 2-557103-2 787311-2 without polarization 94-0680-02-2 Amp Japan P/N: 5-175475-9...
  • Page 63: Figure 15. Nonshielded 68 Pin Scsi Device Connector Used On Lw Drives

    Cheetah 9LP Product Manual, Rev. C 3.650 .005 .346 .270 . 1 55 1.650 .3937 .600 .050 .0787 .200 .022 .020 .047 (15.24) .519 (13.18) (5.08) .100 Pos. 1.816 (2.54) .315 .085 (46.13) Pos. Position 1 x 45 chamfer (8.00) (2.16) .315 .010...
  • Page 64: Figure 16. Nonshielded 80 Pin Scsi "Sca-2" Connector, Used On Lc Drives

    Cheetah 9LP Product Manual, Rev. C 7.00 (.276) 12.70 End View (.500) Grounding Pins 2.15 0.10 2 places 57.87 (2.278) –0.15 + .000 – .006 0.15 M Y M C L of Datum Y –Y– Front View Pin 1 62.15 0.15 (2.447) ( .005)
  • Page 65 Cheetah 9LP Product Manual, Rev. C Table 13: LW 68-conductor single-ended (SE) P cable signal/pin assignments [13] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Connector Signal contact contact Signal name [1] number [3] number [3] name [1] –DB12...
  • Page 66 Cheetah 9LP Product Manual, Rev. C Table 14: LW 68-conductor LVD P cable signal/pin assignments [13] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Connector Signal contact contact Signal name [1] number [3] number [3] name [1] +DB12...
  • Page 67 Cheetah 9LP Product Manual, Rev. C Table 15: LC 80-pin single-ended (SE) I/O connector pin assignments [13] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact Signal Contact name [1] number [3] number [3] name[1] 12 V CHARGE...
  • Page 68 Cheetah 9LP Product Manual, Rev. C Table 16: LC 80-pin single-ended (LVD) I/O connector pin assignments [13] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact Signal Contact name [1] number [3] number [3] name[1] 12 V CHARGE...
  • Page 69: Electrical Description

    Cheetah 9LP Product Manual, Rev. C Notes [ ] for Tables 13 through 16. See Section 9.6.4.1 for detailed electrical characteristics of these signals. The conductor number refers to the conductor position when using 0.025-inch (0.635 mm) centerline flat ribbon cable. Other cables types may be used to implement equivalent contact assignments. Connector contacts are on 0.050 inch (1.27 mm) centers.
  • Page 70: Figure 17. Lvd Output Signals

    Cheetah 9LP Product Manual, Rev. C Steady state Low level output voltage* = –.95 V = < V = < –1.55 V (signal negation/logic 0) Steady state High level output voltage* = –.95 V = < V = < 1.55 V (signal assertion/logic 1) Differential voltage = +0.6 V minimum with common-mode voltage ranges 0.700 V = <...
  • Page 71: Terminator Requirements

    Cheetah 9LP Product Manual, Rev. C 9.7.1.1 Single-ended drivers/receivers The maximum total cable length allowed with drives using single-ended I/O driver and receiver circuits depends on several factors. Table 17 lists the maximum lengths allowed for different configurations of drive usage.
  • Page 72: Disc Drive Scsi Timing

    Cheetah 9LP Product Manual, Rev. C 9.10 Disc drive SCSI timing Table 18: Disc drive SCSI timing These values are not current Cheetah 9LP values, but are listed for information only. Waveform Waveform Description symbol [1] table [1] Typical timing Target Select Time (no Arbitration) <1 s Target Select Time (with Arbitration)
  • Page 73: Drive Activity Led

    Cheetah 9LP Product Manual, Rev. C Table 18: Disc drive SCSI timing (Continued) These values are not current Cheetah 9LP values, but are listed for information only. Waveform Waveform Description symbol [1] table [1] Typical timing Next CDB Byte Access (Byte 10 of 10) T23.10.10 4.5-4 0.12 s ±1 s...
  • Page 75: Seagate Technology Support Services

    Online services Using a modem, you can obtain troubleshooting tips, free utility programs, drive specifications and jumper set- tings for Seagate’s entire product line. You can also download software for installing and analyzing your drive. SeaNET You can obtain technical information about Seagate products over the Internet from Seagate’s World Wide Web home page (http://www.seagate.com) or Seagate’s ftp server (ftp://ftp.seagate.com).
  • Page 76 Cheetah 9LP Product Manual, Rev. C FAX services ® SeaFAX You can use a touch-tone telephone to access Seagate’s automated FAX system to receive technical support information by return FAX. This service is available 24 hours daily. Location Phone number...
  • Page 77 Cheetah 9LP Product Manual, Rev. C Customer service centers Seagate direct OEM, Distribution, and Systems Integrator customers should contact their Seagate service rep- resentative for warranty information. Other customers should contact their place of purchase. Seagate offers comprehensive customer support for all Seagate drives. These services are available worldwide.
  • Page 79 Cheetah 9LP Product Manual, Rev. C Index bytes/surface 9 bytes/track 9 Symbols cabinet cooling 36 +5 and +12 volt supplies 19 cable 48 Numerics cache 10 cache buffer 7 68 conductor connector 51 cache miss 11 68-pin connector 52 cache mode 10 80 conductor connector 51 cache operation 10 80 conductor interface 51...
  • Page 80 Cheetah 9LP Product Manual, Rev. C DC power 10 ECC correction capability 7 DC power carrying conductor 51 electrical characteristics 48 DC power connector 48 electromagnetic compatibility 3 DC power requirements 19 electromagnetic interference (EMI) 13 DC power source 51 electromagnetic susceptibility 26 dedicated landing zone 5 embedded servo 7...
  • Page 81 Cheetah 9LP Product Manual, Rev. C host 12 mating flat cable connector 51 host adapter 31 maximum current requirements 20 adapter/initiator 52 maximum operating current 19 host backplane wiring 50 maximum starting current 19 host equipment 37 ME jumper 35 DC power 51 mean time between failure.
  • Page 82 Cheetah 9LP Product Manual, Rev. C operator intervention 13 prefetch segmented cache control 10 option jumper 31 preventive maintenance 13 option jumper location 31 printed circuit board. See PCB option select header 48 PRML read channel electronics 5 option select jumper 31 product data page 43 options 8 programmable drive capacity 8...
  • Page 83 13 SCSI-1 mode 40 SCSI-2/SCSI-3 45 SCSI-2/SCSI-3 mode 40 technical support services 65 SE 59 temperature 10 Seagate support service 31 ambient 22 sector 11 case 22 sector interleave 9 gradient 22 sector size 8 non-operating 23...
  • Page 84 Cheetah 9LP Product Manual, Rev. C unrecoverable 13 write operation 11 write protect 35 write retry count 29 zoned bit recording (ZBR) 7...
  • Page 86 Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 83329240, Rev. C, Printed in USA...
