Cheetah 36XL Family:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ST336705LW/LC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ST318405LW/LC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ST39205LW/LC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Manual, Volume 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seagate ST318405LW/LC
Summary of Contents for Seagate ST318405LW/LC
- Page 1 ..........ST318405LW/LC .
- Page 3 ..........ST318405LW/LC .
- Page 4 Seagate Technology LLC. Other product names are registered trademarks or trademarks of their owners. Seagate reserves the right to change, without notice, product offerings or specifications. No part of this publica- tion may be reproduced in any form without written permission of Seagate Technology LLC.
-
Page 5: Revision Status Summary Sheet
Revision status summary sheet Revision Date Rev. A 12/11/2000 Rev. B 02/27/2001 Rev. C 05/24/2001 Rev. D 07/30/2001 Rev. E 10/09/2001 Notice. Product Manual 75789517 is Volume 1 of a two-volume document with the SCSI interface information in the SCSI Interface Product Manual, Volume 2, part number 75789509. If you need the SCSI interface information, order the SCSI Interface Product Manual, Volume 2, part number 75789509. -
Page 7: Table Of Contents
Scope ................1 Applicable standards and reference documentation. - Page 8 Seagate Technology support services........
-
Page 9: List Of Figures
Figure 1. Cheetah 36XL family drive (ST336705LC shown) ........1 Figure 2. -
Page 11: Scope
The SCSI Interface Product Manual , part num- ber 75789509, describes general SCSI interface characteristics of this and other families of Seagate drives. The SCSI Interface Product Manual references information from the documents listed in Section 2.3. - Page 12 Cheetah 36XL Product Manual, Rev. E...
-
Page 13: Applicable Standards And Reference Documentation
Mounting by bottom holes must meet the requirements of Section 8.4. Standards The Cheetah 36XL family complies with Seagate standards as noted in the appropriate sections of this Manual and the Seagate SCSI Interface Product Manual , part number 75789509. -
Page 14: Reference Documents
• EUT name (model numbers): ST336705LC, ST336705LW, ST318405LW, ST318405LC, ST39205LC, ST39205LW. • Certificate number: E-H011-01-0340(B), E-H011-01-0341(B), E-H011-01-0347(B), E-H011-01-0344(B), E-H011-01-0346(B), E-H011-01-0345(B) respectively. • Trade name or applicant: Seagate Technology International • Manufacturing start date: 01/2001 • Manufacturer/nationality: Singapore Taiwanese BSMI If this model has two Chinese words meaning “EMC certification” followed by an eight digit identification num-... -
Page 15: General Description
(Volume 1), which defines the product performance char- acteristics of the Cheetah 36XL family of drives, and the SCSI Interface Product Manual , part number 75789509, which describes the general interface characteristics of this and other families of Seagate SCSI drives. -
Page 16: Figure 2. Cheetah 36Xl Family Drive
Cheetah 36XL Product Manual, Rev. E An automatic shipping lock prevents potential damage to the heads and discs that results from movement dur- ing shipping and handling. The shipping lock automatically disengages when power is applied to the drive and the head load process begins. -
Page 17: Standard Features
Standard features The Cheetah 36XL family has the following standard features: • Integrated Ultra160 SCSI controller • Multimode SCSI drivers and receivers—single-ended (SE) and low voltage differential (LVD) • 16 bit I/O data bus • Asynchronous and synchronous data transfer protocol •... -
Page 18: Formatted Capacities
Formatted capacities Formatted capacity depends on the number of spare reallocation sectors reserved and the number of bytes per sector. The following table shows the standard OEM model read capacities data. Total LBAs = read capacity data (shown below) +1. Formatted (data block size 512 bytes/sector) [1]... -
Page 19: Performance Characteristics
Performance characteristics Internal drive characteristics (transparent to user) ST336705 Drive capacity 36.704 Read/write heads Bytes/track 241,128 Bytes/surface 4,577.5 Tracks/surface (total) 19,036 Tracks/inch 24,406 Peak bits/inch 381.28 Internal data rate 320-490 Disc rotational speed 10,022 Average rotational latency 2.99 SCSI performance characteristics (visible to user) The values given in Section 4.2.1 apply to all models of the Cheetah 36XL family unless otherwise specified. -
Page 20: Start/Stop Time
SCSI interface data transfer rates (asynchronous): Maximum instantaneous 8 bit wide Maximum instantaneous 16 bit wide Synchronous formatted transfer rates: In SCSI Wide (16 bit) Sustainable data transfer rates: Minimum Average Maximum Sector Sizes: Default 512 byte user data blocks Variable 512 to 4,096 bytes per sector in even number of bytes per sector. -
Page 21: Cache Operation
enabled and disabled independently via the Mode Select command. However, in actual operation the prefetch feature overlaps cache operation somewhat as is noted in Section 4.5.1 and 4.5.2. All default cache and prefetch Mode parameter values (Mode Page 08h) for standard OEM versions of this drive family are given in Tables 7 and 8. -
Page 22: Prefetch Operation
RCD. When a write command is issued, if RCD=0, the cache is first checked to see if any logical blocks that are to be written are already stored in the cache from a previous read or write command. If there are, the respective cache segments are cleared. - Page 23 The base cache buffer configuration for desktop or server environments needs to be set correctly by the host system. This involves setting the PM bit in Mode Page 0, Byte 2, as well as the number of cache buffer seg- ments in Mode Page 8, Byte 13.
- Page 24 Cheetah 36XL Product Manual, Rev. E...
-
Page 25: Reliability Specifications
Reliability specifications The following reliability specifications assume correct host/drive operational interface, including all interface timings, power supply voltages, environmental requirements and drive mounting constraints (see Section 8.4). Seek Errors Read Error Rates [1] Recovered Data Unrecovered Data Miscorrected Data MTBF Service Life Preventive Maintenance Note. -
Page 26: Reliability And Service
error (15h) is reported with a Medium error (3h) or Hardware error (4h) reported in the Sense Key. This is an unrecoverable seek error. Unrecoverable seek errors are classified as failures for MTBF calculations. Refer to the SCSI Interface Product Manual, part number 75789509, for Request Sense information. Reliability and service You can enhance the reliability of Cheetah 36XL disc drives by ensuring that the drive receives adequate cool- ing. -
Page 27: S.m.a.r.t
Case 4 - Current I/O process allowed during insertion or removal, except on the device being changed Seagate Cheetah 36XL disc drives support all four hot plugging cases. Provision shall be made by the system such that a device being inserted makes power and ground connections prior to the connection of any device signal contact to the bus. -
Page 28: Drive Self Test (Dst)
The process of measuring off-line attributes and saving data can be forced by the RTZ command. Forcing S.M.A.R.T. will reset the timer so that the next scheduled interrupt will be two hours. The drive can be interrogated by the host to determine the time remaining before the next scheduled measure- ment and data logging process will occur. -
Page 29: Dst Failure Definition
DST. It is the responsibility of the host application to determine the “not ready” cause. While not technically part of DST, a Not Ready condition also qualifies the drive to be returned to Seagate as a failed drive. -
Page 30: Product Warranty
Seagate’s option and at no charge to customer, if returned by customer at cus- tomer’s expense to Seagate’s designated facility in accordance with Seagate’s warranty procedure. Seagate will pay for transporting the repair or replacement item to customer. - Page 31 Cheetah 36XL Product Manual, Rev. E Seagate repair centers may refuse receipt of components improperly packaged or obviously damaged in tran- sit. Contact your Authorized Seagate Distributor to purchase additional boxes. Seagate recommends shipping by an air-ride carrier experienced in handling computer equipment.
- Page 32 Cheetah 36XL Product Manual, Rev. E...
-
Page 33: Physical/Electrical Specifications
Physical/electrical specifications This section provides information relating to the physical and electrical characteristics of the Cheetah 36XL drive. AC power requirements None. DC power requirements The voltage and current requirements for a single drive are shown in the following table. Values indicated apply at the drive power connector. -
Page 34: Conducted Noise Immunity
6.2.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a band from DC to 10 MHz. Maximum allowed noise values given below are peak to peak measurements and apply at the drive power con- nector. -
Page 35: Figure 3. Typical St336705 Drive +12 V Current Profile
+12 Volt Current during spindle start – Typical Amperes Figure 3. Typical ST336705 drive +12 V current profile +5 Volt Current during spindle start – Typical Amperes Figure 4. Typical ST318405 drive +12 V current profile AC Envelope Nominal (average) DC curve Seconds AC Envelope Nominal (average) DC curve... -
Page 36: Figure 5. Typical St39205 Drive +12 V Current Profile
+12 Volt Current during spindle start – Typical Amperes Figure 5. Typical ST39205 drive +12 V current profile +5 Volt Current during spindle start – Typical Amperes Figure 6. Typical ST336705 drive +5 V current profile AC Envelope Nominal (average) DC curve Seconds AC Envelope Nominal (average) DC curve... -
Page 37: Figure 7. Typicalst318405 Drive +5 V Current Profile
+12 Volt Current during spindle start – Typical Amperes Figure 7. TypicalST318405 drive +5 V current profile +5 Volt Current during spindle start – Typical Amperes Figure 8. TypicalST39205 drive +5 V current profile AC Envelope Seconds AC Envelope Nominal (average) DC curve Seconds Nominal (average) DC curve... -
Page 38: Power Dissipation
Power dissipation ST336705 For drives using single-ended interface circuits, typical power dissipation under idle conditions is 9.6 watts (32.8 BTUs per hour). For drives using low voltage differential interface circuits, typical power dissipation under idle conditions is 9.6 watts (32.8 BTUs per hour). To obtain operating power for typical random read operations, refer to the following two I/O rate curves (see Figures 9). -
Page 39: Figure 10. St318405 Dc Current And Power Vs. Input/Output Operations Per Second
ST318405 For drives using single-ended interface circuits, typical power dissipation under idle conditions is 8.0 watts (27.3 BTUs per hour). For drives using low voltage differential interface circuits, typical power dissipation under idle conditions is 8.0 watts (27.3 BTUs per hour). To obtain operating power for typical random read operations, refer to the following two I/O rate curves (see Figures 10). -
Page 40: Environmental Limits
ST39205 For drives using single-ended interface circuits, typical power dissipation under idle conditions is 7.5 watts (25.6 BTUs per hour). For drives using low voltage differential interface circuits, typical power dissipation under idle conditions is 7.5 watts (25.6 BTUs per hour). To obtain operating power for typical random read operations, refer to the following two I/O rate curves (see Figures 10). -
Page 41: Relative Humidity
Location of HDA Temperature Check Point b. Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. 6.4.2 Relative humidity The values below assume that no condensation on the drive occurs. - Page 42 >600 cu in (>9,800 cu cm) Drives packaged in single or multipacks with a gross weight of 20 pounds (8.95 kg) or less by Seagate for general freight shipment shall withstand a drop test from 48 inches (1,070 mm) against a concrete floor or equivalent.
-
Page 43: Figure 13. Recommended Mounting
Cheetah 36XL Product Manual, Rev. E Figure 13. Recommended mounting... -
Page 44: Vibration
There will not be any discrete tones more than 10 dB above the masking noise on typical drives when mea- sured according to Seagate specification 30553-001. There will not be any tones more than 24 dB above the masking noise on any drive. -
Page 45: Mechanical Specifications
Mechanical specifications The following nominal dimensions are exclusive of the decorative front panel accessory. However, dimensions of the front panel are shown in figure below. Refer to Figures 14 and 15 for detailed mounting configuration dimensions. See Section 8.4, “Drive mounting.” Height: 1.000 in Width:... -
Page 46: Figure 15. Lc Mounting Configuration Dimensions
Figure 15. LC mounting configuration dimensions Notes: Mounting holes are 6-32 UNC 2B, three -Z- -X- on each side and four on the bottom. Max screw penetration into side of drive is 0.15 in. (3.81 mm). Max screw tightening torque is 6.0 in-lb (3.32 nm) with minimum full thread engagement of 0.12 in. -
Page 47: Defect And Error Management
Defect and error management The drive, as delivered, complies with this specification. The read error rate and specified storage capacity are not dependent upon use of defect management routines by the host (initiator). Defect and error management in the SCSI system involves the drive internal defect/error management and SCSI systems error considerations (errors in communications between Initiator and the drive). -
Page 48: Scsi Systems Errors
Table 3: Read and write retry count maximum recovery times [1] Read retry Maximum recovery time per count [1] LBA (cumulative, msec) 11 (default) 1569 These values are subject to change. Setting these retry counts to a value below the default setting could result in an increased unrecovered error rate which may exceed the value given in this product manual. -
Page 49: Installation
• Installation instructions are provided by host system documentation or with any additionally purchased drive installation software. If necessary see Section 10 for Seagate support services telephone numbers. • Do not remove the manufacturer’s installed labels from the drive and do not cover with additional labels, as the manufacturer labels contain information required when servicing the product. -
Page 50: Figure 16. J6 Jumper Header
Drive Front Jumper Plug (enlarged to show detail) SCSI ID = 0 SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5 SCSI ID = 6 SCSI ID = 7 SCSI ID = 8 SCSI ID = 9 SCSI ID = 10... -
Page 51: Figure 17. J5 Jumper Header (On Lw Model Only)
Drive HDA (rear view, PCB facing downward) 68 Pin SCSI I/O Connector Figure 17. J5 jumper header (on LW model only) Pin 1 Ground Pin 1 SCSI ID = 0 (default) SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5 SCSI ID = 6... -
Page 52: Notes For Figures 16, 17, And 18
Additional notes on these functions in section 8.1.2. Jumper Plug (enlarged to show detail) Figure 18. J2 option select header 8.1.1 Notes for figures 16, 17, and 18. Notes explaining the functions of the various jumpers on jumper header connectors J2, J5, and J6 are given here and in Section 8.1.2. -
Page 53: Function Description
8.1.2 Function description jumper installation Jumper function description Forces drive to use single-ended I/O drivers/receivers only. Drive can operate on the interface in low voltage differential mode or single-ended, depend- ing on the voltage state of the I/O “DIFFSNS” line. Default is SE jumper not installed. Spindle starts immediately after power up - Default setting. -
Page 54: Drive Orientation
(F) is applied to the fourth point. Note. Before mounting the drive in any kind of 3.5-inch to 5.25-inch adapter frame, verify with Seagate Tech- nology that the drive can meet the shock and vibration specifications given herein while mounted in such an adapter frame. -
Page 55: Interface Requirements
No attempt is made to describe all of the minute details of conditions and constraints that must be considered by designers when designing a system in which this family of drives can properly operate. Seagate declares that the drives operate in accordance with the appropriate ANSI Standards referenced in various places herein, with exceptions as noted herein or in the Seagate SCSI Interface Product Manual , part number 75789509. -
Page 56: Scsi Interface Commands Supported
SCSI interface commands supported Table 5 following lists the SCSI interface commands that are supported by the drive. Cheetah 36XL Family drives can be changed back and forth between SCSI-1, SCSI-2, and SCSI-3 (Ultra160) modes using the Change Definition Command. OEM standard drives are shipped set to operate in Ultra160 mode. Table 5: Commands supported by Cheetah 36XL family drive Command name... - Page 57 Table 5: Commands supported by Cheetah 36XL family drive (Continued) Command name Mode sense Caching parameters page (08h) Control mode page (0Ah) Disconnect/reconnect (02h) Error recovery page (01h) Format page (03h) Information exceptions control page (1Ch) Notch and Partition Page (0Ch) Power condition page (1Ah) Rigid disc drive geometry page (04h) Unit attention page (00h)
- Page 58 Table 5: Commands supported by Cheetah 36XL family drive (Continued) Command name Supported diagnostics pages (00h) Translate page (40h) Set limits Start unit/stop unit (spindle ceases rotating) (1Ch) Synchronize cache Test unit ready Verify BYTCHK bit Write Write and verify DPO bit Write buffer (modes 0, 2, supported) Firmware download option...
-
Page 59: Inquiry Vital Product Data
Table 6 lists the Standard Inquiry command data that the drive should return to the initiator per the format given in the SCSI Interface Product Manual, part number 75789509, Inquiry command section. Table 6: Cheetah 36XL family drive Standard Inquiry data Bytes Data (HEX) 0-15... - Page 60 Current values are volatile values currently being used by the drive to control its operation. A Mode Select com- mand can be used to change these values (only those that are changeable). Originally, they are installed from saved or default values after a power on reset, hard reset, or Bus Device Reset message. Changeable values form a bit mask, stored in nonvolatile memory, that dictates which of the current values and saved values can be changed by a Mode Select command.
- Page 61 Table 7: Mode sense data, ST336705 values Bytes 00 01 02 03 04 05 06 07 08 09 10 11 12 Mode Sense Data 00 A2 00 10 00 00 00 08 04 45 DC CA 00 Mode <------------------------------Mode Page Headers and Parameter Data Bytes----------------------------> Page 01 SAV 81 0A C0 0B F0 00 00 00 0F 00 FF FF...
- Page 62 Cheetah 36XL Product Manual, Rev. E mode), the SCSI firmware is performance optimized for desktop applications. The firmware default condi- tion for the PM bit is set to one for Desktop mode. During the manufacturing process, the Saved value of the PM bit remains set to the firmware default condition (one) for drives with the LW interface.
- Page 63 Table 8: Mode sense data, ST318405 values Bytes 03 04 05 06 07 08 09 10 11 12 Mode Sense Data 10 00 00 00 08 02 22 EE 56 00 Mode <------------------------------Mode Page Headers and Parameter Data Bytes----------------------------> Page 01 SAV 0B F0 00 00 00 0F 00 FF FF 01 DEF...
- Page 64 Cheetah 36XL Product Manual, Rev. E mode), the SCSI firmware is performance optimized for desktop applications. The firmware default condi- tion for the PM bit is set to one for Desktop mode. During the manufacturing process, the Saved value of the PM bit remains set to the firmware default condition (one) for drives with the LW interface.
- Page 65 Table 9: Mode sense data, ST39205 values Bytes 03 04 05 06 07 08 09 10 11 12 Mode Sense Data 10 00 00 00 08 01 11 77 2B 00 Mode <------------------------------Mode Page Headers and Parameter Data Bytes----------------------------> Page 01 SAV 0B F0 00 00 00 0F 00 FF FF 01 DEF...
- Page 66 Cheetah 36XL Product Manual, Rev. E mode), the SCSI firmware is performance optimized for desktop applications. The firmware default condi- tion for the PM bit is set to one for Desktop mode. During the manufacturing process, the Saved value of the PM bit remains set to the firmware default condition (one) for drives with the LW interface.
-
Page 67: Scsi Bus Conditions And Miscellaneous Features Supported
SCSI bus conditions and miscellaneous features supported Asynchronous SCSI bus conditions supported by the drive are listed below. These conditions cause the SCSI device to perform certain actions and can alter the SCSI bus phase sequence. Other miscellaneous operating features supported are also listed here. Refer to the SCSI Interface Product Manual, part number 75789509, for details. -
Page 68: Synchronous Data Transfer
Details of the physical, electrical and logical characteristics are given in sections following, while the SCSI operational aspects of Seagate drive interfaces are given in the SCSI Interface Product Manual , part number 75789509. 9.6.1... -
Page 69: Figure 19. Lw Model Drive Physical Interface (68-Pin J1 Scsi I/O Connector)
Pin 1 68 Pin SCSI I/O Connector Figure 19. LW model drive physical interface (68-pin J1 SCSI I/O connector) 80 Pin SCSI I/O and Power Connector Figure 20. LC model drive physical interface (80-pin J1 SCSI I/O connector) Power +12V +12V ret + 5V ret + 5V... -
Page 70: Scsi Interface Physical Description
9.6.2 SCSI interface physical description The drive models described by this product manual support the physical interface requirements of the Ultra160 SCSI Parallel Interface-3 (SPI-3) standards as defined in American National Standard document X3T10/1302D revision 14, and operate compatibly at the interface with devices that support earlier SCSI-2 and SCSI-3 stan- dards. -
Page 71: Mating Connectors
To minimize discontinuances and signal reflections, cables of different impedances should not be used in the same bus. Implementations may require trade-offs in shielding effectiveness, cable length, number of loads and spacing, transfer rates, and cost to achieve satisfactory system operation. If shielded and unshielded cables are mixed within the same SCSI bus, the effect of impedance mismatch must be carefully considered. -
Page 72: Figure 21. Scsi Daisy Chain Interface Cabling For Lw Drives
94-0680-02-1 Amp US P/N: 2-557103-2 94-0680-02-2 Amp Japan P/N: 5-175475-9 Right-angle to PCBA connectors Seagate P/N: 77678559 For additional information call Amp FAX service at 1-800-522-6752. “LW” Model Drive SCSI ID 1 SCSI ID 0 Closed end type 68-pin connector used. Terminators enabled. -
Page 73: Figure 22. Nonshielded 68 Pin Scsi Device Connector Used On Lw Drives
. 1 55 1.650 .050 .022 .100 (2.54) .050 .218 (1.27) (5.54) 1.650 (41.91) Pos. 68 .980 (24.89) Figure 22. Nonshielded 68 pin SCSI device connector used on LW drives 3.650±.005 .346 .3937 .0787 .020 .519 (13.18) 1.816 .315 (46.13) Position 1 (8.00) Pos. -
Page 74: Figure 23. Nonshielded 80 Pin Scsi "Sca-2" Connector, Used On Lc Drives
Pin 1 62.15 (2.447) Housing Contact 0.50 (.020) M Y M (.012) Pin 1 Pin 41 Figure 23. Nonshielded 80 pin SCSI “SCA-2” connector, used on LC drives Grounding Pins 57.87 (2.278) –0.15 + .000 – .006 0.15 M Y M C L of Datum Y –Y–... - Page 75 Table 13: LW 68-conductor single-ended (SE) P cable signal/pin assignments [11] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact name [1] number [3] TermPwr TermPwr Reserved Notes [ ]: See page following Table 16. Connector Cable conductor contact...
- Page 76 Table 14: LW 68-conductor LVD P cable signal/pin assignments [11] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact name [1] number [3] +DB12 +DB13 +DB14 +DB15 +DBP1 +DB0 +DB1 +DB2 +DB3 +DB4 +DB5 +DB6...
- Page 77 Table 15: LC 80-pin single-ended (SE) I/O connector pin assignments [11] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact name [1] number [3] 12 V CHARGE 12 V 12 V 12 V NC [10] NC [10] –DB11...
- Page 78 Table 16: LC 80-pin single-ended (LVD) I/O connector pin assignments [11] Note. A minus sign preceding a signal name indicates that signal is active low. Connector Signal contact name [1] number [3] 12 V CHARGE 12 V 12 V 12 V NC [10] NC [10] –DB11...
-
Page 79: Electrical Description
Notes [ ] for tables 13 through 16. See Section 9.6.4.1 for detailed electrical characteristics of these signals. The conductor number refers to the conductor position when using 0.025-inch (0.635 mm) centerline flat ribbon cable. Other cables types may be used to implement equivalent contact assignments. Connector contacts are on 0.050 inch (1.27 mm) centers. -
Page 80: Figure 24. Lvd Output Signals
Output characteristics Each signal (V ) driven by LVD interface drivers shall have the following output characteristics when measured at the disc drive connector: Steady state Low level output voltage* = –.95 V = < V Steady state High level output voltage* = –.95 V = < V Differential voltage = +0.6 V minimum with common-mode voltage ranges 0.700 V = <... -
Page 81: Single-Ended Drivers/Receivers
9.7.1.1 Single-ended drivers/receivers The maximum total cable length allowed with drives using single-ended I/O driver and receiver circuits depends on several factors. Table 17 lists the maximum lengths allowed for different configurations of drive usage. These values are from the SPI-3 document. All device I/O lines must have equal to or less than 25 pf capacitance to ground, measured at the beginning of the stub. -
Page 82: Disc Drive Scsi Timing
9.10 Disc drive SCSI timing Table 18: Disc drive SCSI timing Description Target Select Time (no Arbitration) Target Select Time (with Arbitration) Target Select to Command Target Select to MSG Out Identify MSG to Command Command to Status Command to Data (para. In) Command to Data (para. -
Page 83: Drive Activity Remote Led Signal Status
Table 18: Disc drive SCSI timing (Continued) Description Data In Byte Transfer (parameter) Data Out Byte Transfer (parameter) Next Data In Byte Access (parameter) Next Data Out Byte Access (parameter) Data In Byte Transfer (media) [2] Data Out Byte Transfer (media) [2] Next Data In Byte access (media [2] Next Data Out Byte access (media [2] MSG IN Byte Transfer... - Page 84 Cheetah 36XL Product Manual, Rev. E...
-
Page 85: Seagate Technology Support Services
FAX 24 hours daily. Presales Support Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system. Technical Support If you need help installing your drive, consult your dealer. Dealers are familiar with their unique system configu- rations and can help you with system conflicts and other technical issues. - Page 86 Customer Service (CSO) Warranty Service Seagate offers worldwide customer support for Seagate drives. Seagate direct OEM, Distribution and System Integrator customers should contact their Seagate service center representative for warranty information. Other customers should contact their place of purchase. Authorized Service Centers If you live outside the US, you can contact an Authorized Service Center for service.
- Page 87 Spain 900-98 31 24 Sweden 0 207 90 073 Switzerland 0 800-83 84 11 Turkey 00 800-31 92 91 40 United Kingdom 0 800-783 5177 Fax Services—All European Countries Presales/Technical Support/Warranty Service Africa/Middle East Support Services For presales, technical support, warranty service and FAX services in Africa and the Middle East, dial our European call center at +31-20-316-7222 from 8:30 Friday, or send a FAX to +31-20-653-3513.
- Page 88 Cheetah 36XL Product Manual, Rev. E...
- Page 89 Index Symbols +5 and +12 volt supplies 23 Numerics 68 conductor connector 61 68 pin connector 62 80 conductor connector 61 80 conductor interface 61 80 pin connector option 61 80 pin I/O connector 67, 68 AC power 23 access time 9 accessories 8 acoustics 34 activity indicator 69...
- Page 90 DC power requirements 23 DC power source 61 dedicated landing zone 5 default 42, 43 default mode parameter 39 default value 49, 50 defect/error management 37 delayed motor start option 23, 69 delayed start 43 depot repair 16 depot repair philosophy 16 diagnostics 24 differential I/O circuit 43 differentiating features 5...
- Page 91 host system 39 host system malfunction 15 host/drive operational interface 15 hot plug 7, 17 humidity 30, 31 I/O connector 60 identified defect 37 idle condition 28, 29, 30 Input characteristics 70 inquiry command 49 inquiry vital product data 49 installation 39 installation guide 4, 8 installation instructions 39...
- Page 92 orientation 10, 31, 44 out-of-plane deflection 44 out-of-plane distortion 44 Output characteristics 70 package size 32 package test specification 4 packaged 32 parity 43 parity checking 43 parity error 43 partition or logical drive 39 PCB 16, 42, 44 PCBA 39, 44, 49, 58, 60, 62 PCBA circuit run 60 PD jumper 43 peak bits/inch 9...
- Page 93 SCSI systems error management 38 SCSI Ultra160 implementation 50 SCSI Ultra160 interface 5 SE 69 Seagate support service 39 sector 11 sector interleave 9 sector size 8 sector sizes 10 seek error 15 seek positioning error 15 segment 11 segment number 11 self-contained 11 Self-Monitoring Analysis and Reporting Technology.
- Page 96 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 75789517, Rev. E, Printed in USA...
