Barracuda 18LP Installation Guide, Rev. B Preface This manual contains information for users of the Seagate® Barracuda 18LP SCSI disc drives. It provides support services, performance specifications, and initial setup information. Addi- tional information is available in the Barracuda 18LP Product Manual (part number 77767526).
Barracuda 18LP Installation Guide, Rev. B remember that you and the drive electronics must all be grounded to avoid potentially damaging static discharges. • Turn off the power before removing or installing the DC power cable. • Do not remove any circuit boards from the drive. •...
Page 5
As a component, this drive is designed to be installed and oper- ated in accordance with UL1950, EN60950, CAN/CSA C22.2 950-95, and VDE0805. Seagate takes all reasonable steps to ensure that its products are certifiable to currently accepted standards. Typical applica- tions of these disc drives include customer packaging and sub- system design.
This unit is a component part and as such is not meant to com- ply with FCC or similar national requirements as a stand-alone unit. Engineering radiated emissions test results are available through the Seagate Safety Department to assist the subsystem designer. Wichtige Sicherheitshinweise Vorsicht.
Page 7
Barracuda 18LP Installation Guide, Rev. B Beachten Sie in jedem Fall die folgenden Warn-und Vorsicht- shinweise: • Beachten Sie alle Warn- und Vorsichtshinweise in diesem Handbuch. • Treffen Sie beim Betrieb, bei der Installation oder bei der Entfernung der Einheit angemessene Sicherheitsvorkehrun- gen.
Page 8
Als Teilkomponente ist dieses Laufwerk für die Installation und den Betrieb in Übereinstimmung mit UL 1950, EN60950, CAN/ CSA C22.2 950-95 und VDE0805 vorgesehen. Seagate ist ständig bemüht, die Zulassungsfähigkeit von Seagate-Produkten im Rahmen der gegenwärtig geltenden Standards zu gewährleisten. Zu den typischen Anwendungen dieser Festplattenwerke zählen Systemeinbau durch den...
• Printer • External modem • Mouse Although the test system with this Seagate model complies to the directives/standard(s), we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide CE Marking and C-...
Page 10
Barracuda 18LP Installation Guide, Rev. B Electromagnetic compliance for the European Union If this model has the CE Marking it complies with the European Union requirements of the Electromagnetic Compatibility Direc- tive 89/336/EEC of 03 May 1989 as amended by Directive 92/31/ EEC of 28 April 1992 and Directive 93/68/EEC of 22 July 1993.
SeaBOARD is a computer bulletin board system that contains information about Seagate disc and tape drive products and is available 24 hours daily. Set your communications software to eight data bits, no parity and one stop bit (8-N-1). This service is available worldwide.
If you need additional help, you can talk to a Seagate technical support specialist. Before calling, note your system configuration and drive model number (ST ####).
Page 13
Barracuda 18LP Installation Guide, Rev. B Customer Service (CSO) Warranty Repair Seagate offers worldwide customer support for Seagate drives. Seagate direct OEM, Distribution and System Integrator custom- ers should contact their Seagate service center representative for warranty information. Other customers should contact their place of purchase.
Page 14
Barracuda 18LP Installation Guide, Rev. B Warranty Repair 1-800-468-3472 FAX: +1-405-949-6740 Mexico and Latin America +1-405-949-7758 FAX: +1-405-949-6738 Authorized Service Centers Brazil MA Informatica +55-21-516-6649 FAX: +55-21-516-5280 Canada Memofix +1-905-660-4936 FAX: +1-905-660-4951 Adtech +1-905-812-8099 or FAX: +1-905-812-7807 1-800-624-9857 European Support Services For European customer support, dial the toll-free number for your specific country for presales support, technical support, SeaFAX and warranty repair.
Barracuda 18LP Installation Guide, Rev. B General description Barracuda 18LP SCSI disc drives are high-speed, random- access digital-data storage devices. The drive is a component for installation in an enclosure designed for the drive. This is often a rack within the system or an external enclosure designed to house one or more disc drives or other peripheral units.
Page 18
Barracuda 18LP Installation Guide, Rev. B Table 1. Drive characteristics Interface UltraSCSI [1] Capacity Formatted [2] Max. data blocks [2] ST39175 9.1 Gbyte [2] 10F59C7h [2] ST318275 18.2 Gbyte [2] 21EB38Fh [2] Recording Cylinders (user) 11,721 Read/write data heads ST39175 ST318275 Access time [3] Average read...
Page 19
Barracuda 18LP Installation Guide, Rev. B Table 2. DC power requirements (Amps), multimode (SE/LVD) ST39175LW/LC ST318275LW/LC Voltage +12V +12V Regulation [5] ±5% ±5%[2] ±5% ±5%[2] Avg. idle current DCX [1] 0.75 0.35 0.75 Max. starting current (peak DC) [3] 1.05 (peak AC) [3] —...
Page 20
Barracuda 18LP Installation Guide, Rev. B [5] See “Conducted noise immunity” in the Barracuda 18LP Product Manual. The specified voltage tolerance is inclusive of ripple, noise, and transient response. [6] Operating condition is defined as random seek read opera- tions with a block count of 64. General Notes from Table 2.
Barracuda 18LP Installation Guide, Rev. B Initial setup information The general information beginning on this page applies to all of the Barracuda 18LP drive models. After reading the general information topics, refer to the appropriate drive-specific section listed below for additional information about configuring and installing your particular model.
Page 22
Barracuda 18LP Installation Guide, Rev. B SCSI ID jumpers Each device on the SCSI chain must have a unique SCSI ID. The host system’s SCSI controller usually uses the ID that has the highest priority interrupt in the SCSI I/O system. This is always ID7.
Page 23
Barracuda 18LP Installation Guide, Rev. B the case, change the ID so that each device on the SCSI chain has its own unique ID. Also check your system or controller user’s manual to ensure that you have not violated its SCSI ID numbering recommendations.
Barracuda 18LP Installation Guide, Rev. B For information about how to terminate your drive, refer to the appropriate drive-specific section. Internal SCSI cable Internal Internal Controller SCSI device SCSI device Terminate Internal SCSI cable External SCSI cable Internal Internal External External Controller SCSI device...
Page 25
Barracuda 18LP Installation Guide, Rev. B This drive must not be operated with that kind of control- ler. This drive can operate with older SE controllers, how- ever. • “LW” and “LC” models use SCSI multimode I/O circuits. Multi- mode circuits operate either in single-ended mode or low volt- age differential mode.
Page 26
Barracuda 18LP Installation Guide, Rev. B Table 4a. Cable characteristics for single-ended I/O circuits Maximum distance between terminators (meters) [1] [3] Number of attached SCSI devices Fast-5 Fast-10 Fast-20 Fast-40 1 to 4 maximum capacitance (25 pF) SCSI devices 5 to 8 maximum capacitance (25 pF) SCSI devices 9 to 16 maximum capacitance (25 pF) SCSI devices...
Page 27
Barracuda 18LP Installation Guide, Rev. B Table 4b. Cable characteristics for differential I/O circuits Maximum distance between terminators (meters) [1] [3] Interconnect Fast-5 Fast-10 Fast-20 Fast-40 Point-to-point interconnect (2 devices) 25 [2] Daisy-chain interconnect (up to 16 devices) [4] [1] For environments where all elements of the bus (cables, device inter- faces, environmental noise and other parameters) are controlled to be better than minimally required, it may be possible to extend the path length and device count.
Page 28
Barracuda 18LP Installation Guide, Rev. B Power Cable Figure 3a. Sixty-eight pin connection to “LW” model drive...
Page 29
Barracuda 18LP Installation Guide, Rev. B “LW” Model Note. Do not mix drives operating Drive single-ended with drives operating differential on the daisy chain. Terminator 2 through X SCSI devices [4] Pin 1 (check your adapter for Pin 1 location) SCSI ID 1 SCSI ID 7 [5] SCSI ID 0...
Page 30
Barracuda 18LP Installation Guide, Rev. B Note. This drive model plugs directly into a backplane connec- tor and therefore uses no cables. Figure 3c. Drive model “LC” with single 80-pin I/O and power connector...
Page 31
Barracuda 18LP Installation Guide, Rev. B Providing adequate cooling The enclosure design must ensure adequate cooling for the drive. The maximum ambient air temperature around the drive should not exceed 50 C. However, to achieve maximum reliabil- ity, the ambient temperature should be about 15 C below this value most of the time.
Barracuda 18LP Installation Guide, Rev. B Kühlung des Systems Die Gehäusekonstruktion muß eine ausreichende Kühlung des Laufwerkes gewährleisten. Die Umgebungstemperatur darf max- imal 50 C betragen. Die Produkthandbuch Barracuda 18LP (Dokument 77767526) enthalten Anweisungen zur Beurteilung der Luftstromkonstruk- tion. Die Beurteilung muß sicherstellen, daß sich die Gehäuse- t e m p e r a t u r b e s t i m m t e r k r i t i s c h e r Ko m p o n e n t e n b e i Laufwerkbetrieb innerhalb zugelassener Grenzen hält.
Page 33
Barracuda 18LP Installation Guide, Rev. B Above unit Under unit Note. Air flows in the direction shown (front to back) or in reverse direction (back to front) Above unit Note. Air flows in the direction shown or Under unit in reverse direction (side to side) Figure 4.
Barracuda 18LP Installation Guide, Rev. B Mounting the drive and connecting cables Do not touch the connector pins or any components on the con- trol board without observing static-discharge precautions. Always handle the drive by the frame only. The drive may be mounted in any orientation (horizontally, verti- cally, and any combination thereof);...
Page 35
Barracuda 18LP Installation Guide, Rev. B Befestigen Sie das Laufwerk mit vier 6-32-UNC-Schrauben am Gehäuse des Host-Systems. Die beiden Seiten des Laufwerkes sind mit jeweils zwei Befestigungslöchern versehen, die Unterseite des Laufwerkes weist vier weitere Befestigungslöcher auf. Gemessen von der Außenfläche des Gehäuses dürfen die Schrauben maximal 3,81 mm in die Befestigungslöcher des Gehüuses hineinragen.
Page 36
Barracuda 18LP Installation Guide, Rev. B the DC power connector. To connect the DC power cable to the drive, simply insert the cable end into the drive’s DC power connector. Schließen Sie das SCSI-Kabel an den SCSI-Steckverbinder des Laufwerkes an. Das Kabel darf nicht gedehnt oder gedrückt werden und es darf den Luftstrom zur Kühlung des Systems nicht behindern.
Page 37
Barracuda 18LP Installation Guide, Rev. B J1-Auxiliary Pin 1 Pin 1A J1-DC Power Power +12V +12V ret + 5V ret + 5V Gleichstrom +12V +12V Rückleitung + 5V Rückleitung + 5V Power Cable Figure 5. DC power connector Abbildung 5. Gleichstromanschluß Note.
Page 38
Barracuda 18LP Installation Guide, Rev. B (electrically isolating) method of mounting the drive in the host system. This may increase radiated emissions and is the system designer’s responsibility. Hinweis: Die Signalerde auf der Stromregelungskarte (PCB) und der Kopf- und Festplatteneinheit (HDA) sind in diesem Laufwerk miteinander verbunden und können nicht getrennt werden.
Page 39
Barracuda 18LP Installation Guide, Rev. B Notes: Mounting holes three on each side, 6-32 UNC. Max screw length into side of drive 0.15 in. (3.81 mm). Screw tightening torque 6.0 in-lb (.675 NM) max with minimum thread engagement of 0.12 in. (3.05 mm). Mounting holes four on bottom, 6-32 UNC.
Page 40
Note. Seagate is not responsible for lost user data. Turn on DC power. Boot the system from a system floppy disc or from a previ- ously installed hard disc drive if there is one.
Page 41
Barracuda 18LP Installation Guide, Rev. B • DOS. Set the drive type in CMOS to “ Zero,” “None,” or “ No hard drive installed .” Use FDISK.EXE and FORMAT.EXE. Sys- tems that have operating system Windows 95 release 950B or later do not need to partition the drive.
Barracuda 18LP Installation Guide, Rev. B LW drives Setting the SCSI ID jumpers Use the J6 jumper block to set the SCSI ID (Figure 7). To change the SCSI ID, install jumpers on the appropriate pins as shown in the illustration. Optional connections to switching circuits in host equipment are provided on J1 auxiliary to set the SCSI ID (see Figure 8).
Page 43
Barracuda 18LP Installation Guide, Rev. B LW drives Drive Front Jumper Plug (enlarged to show detail) Pin 1 Reserved A 2 A 1 A 0 SCSI ID = 0 (default) SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5 SCSI ID = 6...
Page 44
Barracuda 18LP Installation Guide, Rev. B LW drives 68 Pin SCSI I/O Drive Connector Ground J1-DC Power Pin 1 Pin 1 Rear 3P2P (default) SCSI ID = 0 SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5 SCSI ID = 6...
Page 45
Barracuda 18LP Installation Guide, Rev. B LW drives Other applicable jumper options Other option jumpers are available as illustrated in Figures 9 and Drive with Pin 1 HDA up, PCB down, viewed Pin 1 from front Reserved Delay Motor Start option (valid only if the Enable Motor Start jumper is not connected)
Page 46
Barracuda 18LP Installation Guide, Rev. B LW drives Pin 1 Jumper Positions A jumper here forces single-ended I/O operation. [2] No jumper allows host to select either (default) single-ended or LVD operation. Term. Power to SCSI Bus (default) Host adapter or other device provides term.
Barracuda 18LP Installation Guide, Rev. B LC drives Setting the SCSI ID jumpers WC/DC drives section The SCSI ID for “LC” model drives is normally set over the SCSI bus by the host system using connector contacts 39 (ID0), 40 (ID2), 79 (ID1), and 80 (ID3).
Page 48
Barracuda 18LP Installation Guide, Rev. B LC drives Pin 1 Jumper Delay Motor Start option Positions The host system has complete control over (default) motor start functions. Do not install a jumper on these pins. Enable Motor Start option The host system has complete control over (default) motor start functions.
Page 49
Barracuda 18LP Installation Guide, Rev. B LC drives Single-ended/low-voltage-differential selection The SE jumper, when installed on J2, forces the drive I/O circuits and all other devices on the SCSI bus to operate in the single- ended (SE) mode. When the SE jumper is not on, the SCSI I/O can operate in either single-ended or low-voltage differential (LVD) mode, depending on which mode the host device has selected using the “DIFFSNS”...
Page 50
Barracuda 18LP Installation Guide, Rev. B LC drives Pin 1 Jumper Single-Ended I/O Positions A SE jumper here forces single-ended I/O operation. No jumper allows host to select either (default) single-ended or LVD operation. Drive Front J2 Jumper Plug (enlarged to show detail) [1] Jumper position names shown here are not marked on the PCB.
Page 52
Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, CA 95066-4544, USA Publication Number: 77767527, Rev. B, Printed in USA...
