Printing guide
Get the most from the printer by properly loading the trays and properly setting the types and sizes of media.
Loading the standard or optional 550‑sheet tray
The printer has one standard 550‑sheet tray (Tray 1) and may have up to three optional 550‑sheet trays. All 550‑sheet trays
support the same paper sizes and types.
CAUTION—POTENTIAL INJURY: To reduce the risk of equipment instability, load each paper drawer or tray separately.
Keep all other drawers or trays closed until needed.
1
Pull the tray completely out.
Notes:
•
Do not remove trays while a job prints or while Busy appears on the printer display. Doing so may cause a jam.
•
The standard 550‑sheet tray (Tray 1) does not automatically detect the paper size.
2
Squeeze and slide the width guide to the correct position for the paper size you are loading.
Notes:
•
Use the paper size indicators at the bottom of the tray to help position the length and width guides.
•
Incorrect positioning of the width guide can cause paper jams.
Printing guide
Page 1 of 4
Advertisement
Table of Contents
Related Manuals for Lexmark C746
Summary of Contents for Lexmark C746
- Page 1 Printing guide Page 1 of 4 Printing guide Get the most from the printer by properly loading the trays and properly setting the types and sizes of media. Loading the standard or optional 550‑sheet tray The printer has one standard 550‑sheet tray (Tray 1) and may have up to three optional 550‑sheet trays. All 550‑sheet trays support the same paper sizes and types.
- Page 2 Printing guide Page 2 of 4 Squeeze and slide the length guide to the correct position for the paper size you are loading. Notes: • For some paper sizes like letter, legal, and A4, squeeze and slide the length guide backward to accommodate their length.
- Page 3 Printing guide Page 3 of 4 Load the paper stack with the recommended printable side faceup. Notes: • When loading preprinted letterhead for one‑sided printing, place the header faceup toward the front of the tray. • When loading preprinted letterhead for two‑sided printing, place the header facedown toward the rear of the tray. One‑sided printing Two‑sided printing Note: Make sure paper does not exceed the maximum fill indicator located on the left side of the tray.
-
Page 4: Setting The Paper Size And Type
Printing guide Page 4 of 4 Setting the paper size and type From the printer control panel, navigate to: > Settings > > Paper Menu > > Paper Size/Type > Press the up or down arrow button to select the paper tray or feeder, and then press Press the up or down arrow button to select the paper size, and then press Press the up or down arrow button to select the paper type, and then press to change the settings.
