Hunter 28743 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 4
x 2
x 5
x 1
x 4
x 18
x 7
Allen
x 1
Wrench
x 3
Wire
x 4
Connector
x 3
3" Wood Screw
Flat Washer
Hanger
1.5" Wood Screw
Bracket
Assembly
Canopy Screw
Setscrew
Mounting Isolator
Decorative
Screw
Blade
Assembly
Blade Mounting
Screw
Screw, Switch
Housing Assembly
Switch
Screw,
Housing
Machine, 6-32
Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #

Parts List

Asm. Dwg. #
Finish
Item Name Qnty
Hanging System Kit 1
Ceiling Plate
Canopy
Canopy Trim Ring
Setscrew
Canopy Screw
Wood Screw
Flat Washer
Mounting Isolator
Hanger Ball / Downrod Assembly 1
Wire Clamp 1
Blade Iron Set 2
Allen Wrench 1
Screw, Decorative 18
Blade Set 1
Blade Iron Screw 7
Hardware Kit 1
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Switch Housing, Upper 1
Switch Housing, Lower 1
Remote Control Transmitter 1
Hunter Fan Company • 7130 Goodlett Farms Pkwy. #400 • Memphis, TN 38016 • www.hunterfan.com • 98000-02-109 01-17-2012 •
28743
G2025-01
Satin Metal
Part #
G2304-22
88170-19
G0092-01
G2029-01
64801-01
G2019-01
G1880-42
63755-06
G2025-00-860
G2023-01
G2024-01
G2071-01
2012
©
