Overview
MENU
The Menu Button provides a page-sensitive menu structure. Each page has specific
menu options that control, search, navigate, or display page-sensitive items.

MAP PANE CONTROLS

The Map Pane has a number of buttons that control the Base Map, Map Overlays,
centering the map, and splitting the screen.
Control
Maps and
Layers
Center on
Route
Center on
Aircraft
Split-Screen
16
Map Page Menu
Icon
Opens Base Map and Map Overlay menu
location. Highlighted in blue when selected
Selects full screen map or partial map with
Map Pane Controls
Garmin Pilot for iOS User's Guide
Description
Centers the entire route in Map Pane.
Highlighted in blue when selected
Centers the Map Pane on the current
Widgets, Panel, Charts, Active NavLog,
SafeTaxi, or Traffic
