Receiving Air-To-Air targets from aircraft transmitting
ADS-B out on either UAT or 1090 data link. Virtual
TIS-B, you will typically receive TIS-B coverage within a
minimum of 3 NM (+/- 1000') of your current position.
Performance may vary between ground stations.
Receiving Air-To-Air targets from aircraft transmitting
ADS-B out on either UAT or 1090 data link. With
degraded TIS-B. You may see traffic targets, but cannot
be certain you are receiving all targets around your
current position
Not receiving Air-To-Air targets from aircraft
transmitting ADS-B out on either UAT or 1090 data
link. Virtual TIS-B, you will typically receive TIS-B
coverage within a minimum of 3 NM (+/- 1000') of
your current position. Performance may vary between
ground stations.

TRAFFIC DESCRIPTION

ADS-B traffic operation is similar to other traffic systems, but ADS-B adds additional
symbology. The symbols used to display ADS-B traffic are shown in the table below. The
traffic identifier and altitude are displayed below the traffic symbol. A small up or down
arrow next to the traffic symbol indicates that the traffic is climbing or descending at
a rate of at least 500 feet per minute. The vector line that extends beyond the point of
the traffic arrow is just further indication of the aircraft's track.
Symbol
116
System Status
Traffic Modes
Non-threat, non-directional airborne traffic
Directional airborne Traffic with track vector. Points in the direction of the
aircraft track.
Non-directional airborne Proximity Advisory (PA). Proximity Advisories are
issued for any traffic within 6 nautical miles and +/- 1,200'.
Garmin Pilot for iOS User's Guide
Traffic Icon
Description
