Left View - Gateway NV42 Series Service Manual

Left View

Icon
Kensington™ lock
slot
Ventilation fan
Monitor port
Ethernet jack
USB port
Microphone jack
Headphone jack
HDMI HDMI out jack
(optional)
6
Item
Secure your notebook to an object by connecting a
Kensington cable lock to this slot.
Helps cool internal components.
Warning: Do not work with the notebook resting on your lap. If
the air vents are blocked, the notebook may become hot
enough to harm your skin.
Caution: Do not block or insert objects into these slots. If
these slots are blocked, your notebook may overheat resulting
in unexpected shutdown or permanent damage to the
notebook.
Caution: Provide adequate space around your notebook so
air vents are not obstructed. Do not use the notebook on a
bed, sofa, rug, or other similar surface.
Plug an analog VGA monitor or projector into this port.
Plug an Ethernet network cable into this jack. Plug the other
end of the cable into a cable modem, DSL modem, or an
Ethernet network jack.
Plug USB devices (such as a diskette drive, flash drive, printer,
scanner, camera, keyboard, or mouse) into this port.
Plug a microphone into this jack.
Plug amplified speakers or headphones into this jack. The
built-in speakers are turned off when speakers or headphones
are plugged into this jacks.
• Headphone with SPDIF support
Plug an HDMI device, such as a high definition television, into
this optional jack.
Description
Chapter 1
