CAUTION
Ensure that proper airflow is maintained in the processor voltage regulator circuit. Failure to do
so may result in damage to the voltage regulator circuit. The processor voltage regulator area
(item A in Figure 28) can reach a temperature of up to 85
Figure 28 shows the locations of the localized high temperature zones.
78
D
Item Description
A Processor voltage regulator area
B Processor
C Intel 82915P MCH
D Intel 82801FB ICH6
Figure 28. Localized High Temperature Zones
o
C in an open chassis.
C
A
B
OM17063
