Table 17 lists the back panel connectors identified in Figure 17.
NOTE
The back panel audio line out connector is designed to power headphones or amplified speakers
only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output.
Table 17.
Back Panel Connectors Shown in Figure 17
Item/Callout
from Figure 17
Description
A
PS/2 mouse port (Green)
B
PS/2 keyboard port (Purple)
C
Parallel port (Burgundy)
D
Serial port A (Teal)
E
Audio line in/Retasking Port C (Light blue)
F
Audio line out/Retasking Port D (Lime Green)
G
Mic in/Retasking Port B (Pink)
H
IEEE-1394a (optional)
I
USB ports (two)
J
LAN
K
USB ports (two)
Technical Reference
59
