  • Page 2: Safety Symbols

    Indicates a prohibited action. Indicates to ground for safety. Copyright© 2004 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.EIZO NANAO CORPORATION is under no obligation to hold...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PRECAUTIONS ........... 4 1.

  • Page 4: Precautions

    English PRECAUTIONS IMPORTANT! This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below).
  • Page 5 WARNING Keep small objects or liquids away from the unit. Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet may result in fire, electric shock, or equipment damage. If an object or liquid falls/spills into the cabinet, unplug the unit immediately.
  • Page 6 English WARNING The equipment must be connected to a grounded main outlet. Not doing so may cause in fire or electric shock. Use the correct voltage. The unit is designed for use with a specific voltage only. Connection to another voltage than specified in this User’s Manual may cause fire, electric shock, or equipment damage.
  • Page 7 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit firmly with both hands ensuring the panel faces outward before lifting.

  • Page 8: Lcd Panel

    English LCD Panel When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may occur inside and outside the monitor. In that case, do not turn the monitor on and wait until dew condensation disappears, otherwise it may cause some damages to it.

  • Page 9: Introduction

    INTRODUCTION Thank you very much for choosing an EIZO Color Monitor. 1-1. Features Dual inputs compliant (DVI-I x 2 connecters) DVI (p. 43) Digital input (TMDS (p. 44)) compliant [Horizontal scanning frequency] Analog: 30 - 82 kHz [Vertical scanning frequency] [Resolution] Supports to sRGB (p.

  • Page 10: Controls & Connectors

    English 1-3. Controls & Connectors Front Control Panel ScreenManager Input Signal Selection Button Mode Button* Auto Adjustment Button Enter Button Control Buttons* Power Button Power Indicator* Blue Yellow Flashing yellow (2 times for each) *1 Directly pressing the mode button allows you to switch a color mode between “Custom” and “sRGB”.
  • Page 11 Rear Bottom Security Lock Slot* (10) Height Adjustable Stand (Detachable)* (11) Power Connector (12) DVI-I Input Connector (SIGNAL 1) (13) DVI-I Input Connector (SIGNAL 2) (14) USB Port (1 Upstream) (15) USB Port (2 Downstream) *5 Allows for connection of a security cable. This lock supports Kensington’s MicroSaver se- curity system.

  • Page 12: Cable Connection

    English CABLE CONNECTION 2-1. Before Connecting Before connecting your monitor to the PC, change the display screen settings (resolution (p. 44) and frequency) in accordance with the charts below. NOTE When your computer and display support VESA DDC, the suitable resolution and the refresh rate are set by just plugging your display into the computer without any manual settings.

  • Page 13: Connecting The Signal Cable

    2-2. Connecting the Signal Cable NOTE Be sure that the power switches of both the PC and the monitor are OFF. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC. After connecting, secure the connection with the screw-in fasteners.
  • Page 14 English Plug the power cord into the power connector on the rear of the monitor. Lead the power cord and signal cable into the cable holder at rear of the monitor. NOTE The cables are recommended to lead with slight sag for the smooth motion of the stand and the Portrait/Landscape display.
  • Page 15 Turn on the monitor's Power Button and then turn on the PC's power. The monitor's power indicator will light up (blue). If an image does not appear, refer to the “7. TROUBLESHOOTING” (p. 36) for advice. Whenever finished, turn off the PC and the monitor. NOTE When turning on the monitor, the kind of the input signal (Signal1 or 2/Analog or Digital) is displayed for a few seconds on the right top corner of the screen.

  • Page 16: Connecting Two Pcs To The Monitor

    English 2-3. Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the Signal 1 and the Signal 2 on the back of the monitor. Connecting Examples Ex.1 Digital Ex.2 Analog D-Sub mini 15 pin Ex.3 Digital 2.
  • Page 17 Selecting the Active Input The Input Signal Selection Button on the control panel can be used to select either SIGNAL 1 or SIGNAL 2 as the active input at any time. Every time the button is pressed, the input changes. When switching the signal, the kind of the input signal (Signal1 or 2/Analog or Digital) is displayed for a few seconds on the right top corner of the screen.

  • Page 18: Screenmanager

    English SCREENMANAGER 3-1. How to use the ScreenManager Entering the ScreenManager Press the Enter Button once to display the main menu of the ScreenManager. Making Adjustments and Settings Select the desired sub menu icon using the Control buttons and press the Enter Button.

  • Page 19: Screenmanager Adjustments And Settings

    Color Mode Management Brightness (Custom)* Contrast Temperature Saturation Gain Reset Power Manager DVI DMPM VESA DPMS EIZO MPMS Sub menu 4-1. Screen Adjustment (p. 23) 4-3. Color Adjustment (p. 29) ** 4-4. Power-save Setup (p. 31) English Reference 3. ScreenManager...
  • Page 20 English Main menu Others Screen Size Border Intensity Input Priority Off Timer Beep Menu Settings Orientation Power Indicator Reset Information Information Language English, German, French, Spanish, Italian, Swedish and Japanese *1 The above table shows the sub menus when the “Custom” mode is selected (see page 29). *2 Due to the inspection on the factory, the usage time may not be “0 hour”...

  • Page 21: Useful Functions

    3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Unlocked function [How To lock] Switch off the monitor's power by the power button on the control panel. Press on the Auto adjustment button while switching on the monitor's power. [How To unlock] Switch off the monitor's power by the power button on the control panel.

  • Page 22: Eizo Logo Appearing Function

    Select “Disable”. EIZO Logo Appearing Function When switching on the Power Button on the control panel, the EIZO logo is displayed for a while. If you desire to display or undisplay this logo, use this function. (Default is logo appearing.)

  • Page 23: Adjustment

    ADJUSTMENT 4-1. Screen Adjustment NOTE Allow the LCD monitor to stabilize for at least 20 minutes before making image adjustments. The monitor displays the digital input image correctly based on its pre- setting data. Analog Input Screen adjustments for the LCD monitor should be used in suppressing screen flickering and also for adjusting the screen to its proper position.
  • Page 24 Run the “Screen adjustment program”. Having read the “Readme.txt” file, run the “Screen Adjustment Program” in the enclosed EIZO LCD Utility Disk. Step by step, adjustment is provided by the wizard guide (If using the Windows, the program can be directly run from the menu screen of the CD-ROM.) .
  • Page 25 Horizontal flickering, blurring or bars appear on the screen. → Use the <Phase> (p. 44) adjustment. Select the <Phase> and eliminate the horizontal flickering, blurring or bars by using the right and left buttons. NOTE Horizontal bars may not completely disappear from the screen depending on the PC.
  • Page 26 English Screen image is smaller or larger than the actual screen images. → Adjustment is needed when the input signal resolution and the resolution now being displayed are different. Select <Resolution> and confirm if the resolution now being displayed is the same as the input resolution.

  • Page 27: Displaying Low Resolutions

    4-2. Displaying Low Resolutions The lower resolutions are enlarged to full screen automatically. Using the <Screen Size> function in the <Others> menu enables to change the screen size. Enlarge the screen size when displaying a low resolution. → Select the <Screen Size>. Select the <Screen Size>...
  • Page 28 English Set the brightness of the black area surrounding the displayed image. → Set the <Border Intensity>. In the <Enlarge> mode or <Full Screen> mode, the outer area (border) is usually black. Select <Border Intensity> in the <Others> menu and adjust by using the right and left buttons.

  • Page 29: Color Adjustment

    4-3. Color Adjustment Color adjustments are provided in ScreenManager <Color Management> menu. To customize monitor color, select <Custom> through the <Color Mode>. To configure monitor color to sRGB standard, select <sRGB> through the <Color Mode>. Color mode can also be switched to other if pressing Mode button of the control panel.
  • Page 30 English Menu Function Descriptions Saturation To change the saturation NOTE Using <Saturation> adjustment may not obtain proper tone reproduction. To change the flesh color, etc. -20 ~ 20 NOTE Using <Hue> adjustment may not obtain proper tone reproduction. Gain To change each color (red, green and blue) NOTE The values shown in the percentage are available only as a reference...

  • Page 31: Power-Save Setup

    Analog Input This monitor complies with the <VESA DPMS> (p. 44) standard and adopts a power saving method, <EIZO MPMS> (p. 43), which works with a blank screen (totally black screen) like “Blank Screen” ScreenSaver software. To use the PC's Power Saving System (VESA DPMS ) [Procedure] Set the PC's power saving settings.

  • Page 32: Digital Input

    English To set the Power Save with ScreenSaver (EIZO MPMS) Software. [Procedure] Set the PC's appropriate ScreenSaver settings or blank the screen (totally black screen). Select “EIZO MPMS” in the <PowerManager> menu. [Power Saving System] Operation Blank the screen (ScreenSaver or Macintosh Energy Saver) [Power Resumption Procedure] Operate the mouse or keyboard to return to a normal screen.

  • Page 33: Making Use Of Usb (Universal Serial Bus)

    PC equipped with USB ports or another USB hub connected to the USB compliant Windows 98/Me/2000/XP // Mac OS 8.5.1 or later EIZO USB Cable (MD-C93 enclosed) NOTE The USB hub function may not work properly depending on the PC, OS or peripherals.
  • Page 34 English After connecting the USB cable, the USB function can be set up automatically. After setting up, the monitor's USB hub is available for connecting USB compliant peripherals to the downstream ports of the monitor. Connecting Examples 5. MAKING USE OF USB (Universal Serial Bus) Upstream Ports Upstream port: Connect the USB compliant PC...

  • Page 35: Attaching An Arm

    ATTACHING AN ARM The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm or stand to the LCD monitor. NOTE If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting.

  • Page 36: Troubleshooting

    English TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. No picture problems → See No.1 ~ No.2 Imaging problems → See No.3 ~ No.13 Other problems → See No.14 ~ No.17 USB problems → See No.18 ~ No.19...
  • Page 37 Problems Display position is incorrect. Screen image is smaller or larger than the actual screen images. Vertical bars of distortion appear. Horizontal bars of distortion appear. Letters and lines appear blurred. Distortion appears like the figure below. The screen is too bright or too dark.

  • Page 38: 38 7. Troubleshooting

    Check the downstream ports by connecting the peripherals to other downstream ports. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) Try executing the following method. Restarting the PC - Restarting the PC...

  • Page 39: Cleaning

    CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel.

  • Page 40: Specifications

    English SPECIFICATIONS LCD Panel Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Dot Clock (Max.) Display Colors Display Area Power Supply Power Consumption Input Connector Analog Input Signal (Sync) Analog Input Signal (Video) Input Signal (Digital) Signal registration Plug & Play Dimensions Dimensions (without stand) Weight...

  • Page 41: Default Settings

    USB port Communication Speed Power Supply Certifications and Standards 100-120 VAC 200-240 VAC *1 Applicable to gray color version only. *2 Applicable to black color version only Default settings Brightness Smoothing Color Mode PowerManager Screen Size Input Priority Off Timer Menu Settings Beep Language...

  • Page 42: Pin Assignment

    English Dimensions Pin Assignment DVI-I Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Signal TMDS Data 2- TMDS Data 2+ TMDS Data 2/4 Shield DDC Clock (SCL) DDC Data (SDA) Analog Vertical Sync...

  • Page 43: Glossary

    (EIZO Monitor PowerManager Signaling) EIZO MPMS, “EIZO Monitor PowerManager Signaling” also enables power saving on the monitor side. EIZO MPMS recognizes video signals from the PC when the PC is in a power saving mode and reduces energy consumption of the monitor.
  • Page 44 Computer monitors generally give best performance at high temperature settings. 5,000K: Often used in printing industry. 6,500K: Good for video-image display. 9,300K: Default setting for your EIZO monitor. TMDS (Transition Minimized Differential Signaling) A signal transition method for the digital interface...

  • Page 45: Appendix/Anhang/Annexe

    APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique Based on the signal diagram shown below 25 factory presets have been registered in the monitor's microprocessor. Der integrierte Mikroprozessor des Monitors unterstützt 25 werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme).
  • Page 46 Mode VESA 600 @ 85 Hz VESA 1024 768 @ 60 Hz VESA 1024 768 @ 70 Hz VESA 1024 768 @ 75 Hz VESA 1024 768 @ 85 Hz VESA 1152 864 @ 75 Hz 1152 900 @ 66 Hz 1152 900 @ 76 Hz VESA...
  • Page 47 Congratulations! The display you have just purchased carries the TCO'03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
  • Page 48 Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 49 Environmental Requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.

  • Page 50: Fcc Declaration Of Conformity

    Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (enclosed) This Class B digital apparatus complies with Canadian ICES-003.
  • Page 51 Hinweis zur Ergonomie : Dieser Monitor erfüllt die Anforderungen an die Ergonomie nach EK1-ITB 2000 mit dem Videosignal, 1280 Punkte × 1024 Zeilen, RGB analog, 0,7 Vp-p und mindestens 75,0 Hz Bildwiederholfrequenz, non interlaced. Weiterhin wird aus ergonomischen Gründen empfohlen, die Grundfarbe Blau nicht auf dunklem Untergrund zu verwenden (schlechte Erkennbarkeit, Augenbelastung bei zu geringem Zeichenkontrast.) Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen.
  • Page 52 Vous trouvez tous les renseignements pour le sujet de recyclage sur la page WEB de I’UNION DE BRAN CHE SWICO. http://www.swico.ch Recycling Information for customers in USA: All recycling information is placed in the EIZO Nanao Technologies, Inc’s website. http://www.eizo.com/contact/index.html Återvinnings information för kunder i Sverige: All information om återvinning finns på Eizo Nordics hemsida:...
