Page 1: Cover
Please read PRECAUTIONS, this User’s Manual and Setup Guide (separate volume) carefully to familiarize yourself with safe and effective usage. • How to Setup Please read the Setup Guide (separate volume) • The latest User's Manual is available for download from our site: http://www.eizo.com... - Page 2 Product specifications may vary depending on the region. Confirm the specifications in the manual written in the language of the region of purchase. Copyright© 2008 EIZO NANAO CORPORATION All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION.
-
Page 3: Notice For This Monitor
Notice for this monitor • Aside from creating documents, viewing multimedia content, and other general purposes, this product is also suited to applications such as graphics creation and digital photo processing, where accurate color reproduction is a priority. • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. -
Page 4: Cleaning
Cleaning NOTE • Never use thinner, benzene, alcohol, abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. [LCD Panel] • T he LCD surface can be cleaned with a soft cloth, such as cotton or lens paper. • I f necessary, stubborn stains can be removed by using the provided ScreenCleaner, or moistening part of a cloth with water to enhance its cleaning power. [Cabinet] • T o remove stains, wipe the cabinet with a soft, lightly moistened cloth using a mild detergent. Do not spray wax or cleaner directly into the cabinet. (For details, refer to the manual of the PC.) To use the monitor comfortably • A n excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to the environmental conditions. • S taring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour. -
Page 5: Table Of Contents
3-1. Setting Power Saving ..20 Analog Input ... 20 Digital Input ..20 3-2. Using Off Timer ... 21 3-3. Locking Button Operation ... 21 3-4. Setting Power Indicator ... 22 3-5. Changing Orientation ..22 3-6. Setting EIZO Logo Display ... 22 4.Troubleshooting ... 23 5. Reference ... 26 5-1. Attaching an Arm ..26 5-2. Connecting Two PCs to the Monitor ..27 5-3. Utilizing USB (Universal Serial Bus) ..28 5-4. Setting Range of Frequency ..29 5-5. -
Page 6: Introduction
1. Introduction Thank you very much for choosing an EIZO Color Monitor. 1-1. Features • 2 4.1" wide format LCD • W ide color gamut of 97% of Adobe RGB • Applicable to HDCP • Applicable to DisplayPort (8-bit only, audio unsupported) • Dual inputs compliant (DVI-I x 1 and DisplayPort x 1) • [Horizontal scanning frequency] Analog: 24 - 130 kHz Digital: 26 - 78 kHz [Vertical scanning frequency] Analog: 47.5 - 120Hz Digital: 23.75 - 63Hz (VGA TEXT: 69 - 71Hz) [Resolution] 1920 dots x 1200 lines • Frame Synchronous mode supported (23.75 - 31.5Hz, 47.5 - 63Hz) • The Portrait/Landscape display capability (rotate 90 degrees clockwise) • The provided "ColorNavigator" calibration software enables you to calibrate monitor characteristics and generate ICC profiles (for Windows) and Apple ColorSync profiles (for Macintosh) (refer to "1-3. Utility Disk" on page 8) • Color Vision Deficiency Simulation Software "UniColor Pro" supported (This software can be downloaded from http://www.eizo.com) • Smoothing function incorporated for the adjustment of an enlarged image • FineContrast modes, to select the most suitable mode for screen display (refer to "2-3. Adjusting Color" on page 16) • H eight adjustable stand • Auto EcoView function incorporate • Attaching the "Adjustment Certificate" to describe the grayscale and uniformity characteristics of the monitor individually • Monitor hood attached Tips • T his monitor supports the Portrait/Landscape display. This function allows you to change the orientation of the Adjustment menu when using the monitor screen in vertical display position. -
Page 7: Controls And Functions
Used to adjust the height and angle of the monitor screen. Stand Complies with Kensington’s MicroSaver security system. Security lock slot Cable holder Covers the monitor cables. ® *ScreenManager is an EIZO’s nickname of the Adjustment menu. (page Off: Power off (page (page (page (page (page... -
Page 8: Utility Disk
1-. Utility Disk An "EIZO LCD Utility Disk" (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the software programs. Disk contents and software overview The disk includes software programs for adjustment and User’s Manual. Refer to "Readme.txt" or the "read me" file on the disk for software startup procedures or file access procedures. Item A “Readme.txt” or “read me” file ColorNavigator An application software for calibrating monitor characteristics and generating ICC profiles (for Windows) and Apple ColorSync profiles (for Macintosh). (A PC must be connected to the monitor with the supplied USB cable.) Refer to the descriotion later. -
Page 9: Basic Operation And Functions
1-. Basic Operation and Functions Basic Operation Adjustment menu allows you to adjust screen performance though the main menu and select a FineContrast mode easily. FineContrast Menu Note • T he Adjustment menu and the FineContrast menu cannot be displayed at the same time. Entering the Adjustment menu Press once to display the main menu of the Adjustment menu. Making Adjustments and Settings 1. Select the desired sub menu icon using the sub menu, refer to the “Functions” (page 10)). 2. Use to select the desired setting icon and press . The setting menu appears. 3. Use to make all required adjustments and press save the settings. Exiting the Adjustment menu 1. To return to the main menu, select the <Return> icon 2. To exit the Adjustment menu, select the <Exit> icon Tips • D ouble clicking at any time also exits the Adjustment menu. ® Adjustment menu (ScreenManager Enter button Control buttons Mode button (Left, Down, Up, Right) -
Page 10: Functions
Functions The following table shows all the Adjustment menu's adjustment and setting menus. "*" indicates adjustments of analog input only. Main menu Screen Clock Phase Position Resolution Range Adjustment Smoothing Signal Filter Brightness Color (Custom) Temperature Gamma Saturation Gain 6 Colors Reset PowerManager Others Screen Size Border Intensity Input Signal Off Timer Menu Settings Auto EcoView Power Indicator Reset Information Information... -
Page 11: Adjusting Screen
. Adjusting Screen -1. Setting Screen Resolution Compatible Resolutions/Frequencies The monitor supports the following resolutions. Analog Input Resolution 640×480 640×480 720×400 800×600 832×624 1024×768 1152×864 1152×870 1280×960 1280×960 1280×1024 1600×1200 1680×1050* 1 *2 1920×1200* Digital Input (DVI/DisplayPort) Resolution 640×480 720×480 800×600 1024×768 1280×960 1600×1200 1680×1050* *1 *2 1920×1200 When displaying the wide format input signal, a graphics board in conformance with VESA CVT standard is required. -
Page 12: Setting Resolution
Setting Resolution Windows Vista 1. Right-click the mouse anywhere on the desktop except for icons. 2. From the displayed menu, click "Personalize". 3. On the "Personalization" window, click "Display Settings". 4. On the "Display Settings" dialog, select the "Monitor" tab and select desired resolution in the "Resolution" field. 5. Click the "OK" button. 6. When a confirmation dialog is displayed, click "Yes". Windows XP 1. Right-click the mouse anywhere on the desktop except for icons. 2. From the displayed menu, click "Properties". 3. When the "Display Properties" dialog is displayed, click the "Settings" tab and select desired resolution for "Screen resolution" under "Display". -
Page 13: Displaying Screen Correctly (Analog Input Only)
• It cannot work correctly using with some graphics cards. If the appropriate screen cannot be made by using If the appropriate screen can be made, proceed to 5. Range Adjustment . Prepare the display pattern for the analog display adjustment. Windows 1. Load the “EIZO LCD Utility Disk” to your PC. 2. Start the “Screen Adjustment Utility” from the startup menu. If it cannot be started, open the screen adjustment pattern files. Other than Windows Download the "Screen adjustment pattern files" from our site: http://www.eizo.com. Tips • For how to open and use the screen adjustment pattern files, refer to “Readme.txt” or the “read me” file. , adjust the screen through the following procedures. - Page 14 Perform the auto size adjustment again with the analog screen adjustment pattern displayed. 1. Display Pattern 1 in full screen on the monitor using the “Screen Adjustment Utility” or the screen adjustment pattern files. 2. Press . A message “Your setting will be lost, if you press again now” appears for five seconds. 3. Press again while the message is displayed. The Auto Adjustment function begins (showing a running status icon) to adjust flickering, screen position, and screen size automatically. Adjust by using <Screen> menu in the Adjustment menu (1)Vertical bars appear on the screen Use the <Clock> adjustment. Select the <Clock> and eliminate the vertical bars by using and of the Control buttons. Do not continuously press the Control buttons, as the adjustment value will change quickly and make it difficult to locate the most suitable adjustment point. If the horizontal flickering, blur or bars appear, proceed to <Phase> adjustment as follows. (2) Horizontal flickering, blurring or bars appear on the screen. Use the <Phase> adjustment. Select the <Phase> and eliminate the horizontal flickering, blurring or bars by using and buttons. Note • H orizontal bars may not completely disappear from the screen depending on the PC.
- Page 15 (3) The screen position is incorrect. Use the <Position> adjustment. The correct displayed position of the monitor is decided because the number and the position of the pixels are fixed. The <Position> adjustment moves the image to the correct position. Select <Position> and adjust the position by using , , and . If vertical bars of distortion appear after finishing the <Position> adjustment, return to <Clock> adjustment and repeat the previously explained adjustment procedure. ("Clock" => "Phase" => "Position") (4) Screen image is smaller or larger than the actual screen images. Use the <Resolution> adjustment. Adjustment is needed when the input signal resolution and the resolution now being displayed are different. Select <Resolution> and confirm if the resolution now being displayed is the same as the input resolution. If it is not, adjust the vertical resolution using and and adjust the horizontal resolution using and . Extra image is displayed due to excessive dots. A part of image is cut due to short dots. Adjust the output signal range (Dynamic Range) of the signal.
-
Page 16: Adjusting Color
-. Adjusting Color Simple Adjustment (Switching FineContrast Mode) This function allows you to select the best display mode for monitor brightness, etc. To Select FineContrast Mode Directly pressing allows you to select the best suited mode for screen display from 4 FineContrast modes; Custom, sRGB, EMU and CAL. Color settings each mode can be adjusted by using the <Color> menu of the Adjustment menu. Press to exit the menu. Tips • T he Adjustment menu and the FineContrast menu cannot be displayed at the same time. Mode button Enter button FineContrast Mode Selectable FineContrast modes are as follows. Mode Custom Available for the color settings according to your preference. sRGB Suitable for color matching with sRGB compatible peripherals. -
Page 17: Advanced Adjustments [Adjustment Menu]
Advanced Adjustments [Adjustment menu] Color settings of each FineContrast mode can be adjusted and saved by using the <Color> menu of the Adjustment menu. In the analog input, perform the "Range Adjustment" before making the color adjustments. During color adjustments, the FineContrast mode cannot be changed. Select the mode in advance by using Adjustment Items The adjustable items and displayed icons on the <Color> menu depend on the selected FineContrast mode. Regarding the adjustment items, refer to the “Adjustment Contents” on the next page. " √ ": Settable/Adjustable " - ": Fixed at the factory Icons Functions Brightness... - Page 18 Adjustment Contents Menu Brightness To set the brightness of the screen Tips • The values shown in the “%” are available only as reference. Temperature To set the color temperature Tips • The values shown in the Kelvin are available only as a reference tool. •...
-
Page 19: Displaying Lower Resolutions
-. Displaying Lower Resolutions The lower resolutions are enlarged to full screen automatically. Using the <Screen Size> function in the <Others> menu enables to change the screen size. Enlarge the screen size when displaying a low resolution. Select the <Screen Size>. Select the <Screen Size> in the <Others> menu and select the screen size by using and . Mode Full Enlarged Normal Example: Displaying 1280 x 1024 Full (Default Setting) (1920 × 1200) Smooth the blurred texts of the enlarged screen. Switch the <Smoothing> setting. Select the suitable level from 1 - 5 (Soft - Sharp). Select <Smoothing> in the <Screen> menu and adjust by using the right and left switches. Note • S moothing setting may not be required depending on the display resolution. (You cannot choose the smoothing icon.) Set the brightness of the black area surrounding the displayed image. Set the <Border Intensity>. In the "Enlarge" mode or "Full Screen" mode, the outer area (border) is usually black. Select <BorderIntensity> in the <Others> menu and adjust by using Displays the picture on the screen in full, irrespective of the picture's resolution. Since the verticalresolution and the horizontal resolution are enlarged at different rates, some images may appeardistorted. -
Page 20: Setting Monitor
. Setting Monitor -1. Setting Power Saving The <PowerManager> menu in the Adjustment menu enables to set the power saving. Note • Do your part to conserve energy, turn off the monitor when you are finished using it. Turning off the main power switch or unplugging the power cord completely shuts off power supply to the monitor. • Devices connected to the USB port (upstream and downstream) work when the monitor is in power saving mode or when the power button of the monitor is Off. Therefore, power consumption of the monitor varies with connected devices even in the power saving mode. • When using ColorNavigator, turning of the power saving function is recommended. Analog Input This monitor complies with the "VESA DPMS". [Procedure] 1. Set the PC's power saving settings. 2. Select "On" from the <PowerManager> menu. [Power Saving System] STAND-BY Power saving SUSPEND [Power Resumption Procedure] Operate the mouse or keyboard to return to a normal screen. Digital Input • DVI: This monitor complies with the DVI DMPM standard. • DisplayPort: This monitor complies with the DisplayPort Standard V1.1a. [Procedure] 1. Set the PC's power saving settings. 2. Select "On" from the <PowerManager> menu. [Power Saving System] The monitor enters the power saving mode in five seconds in connection with the PC setting. -
Page 21: Using Off Timer
Monitor Advance Notice Power OFF • (Enter button) / Adjustments/settings using • (Mode button) • (Auto Adjustment button) • EIZO Logo display setup (page • (Input Signal Selection button) • (Power button) • (Adjustment Lock button) Power Indicator Blue Blue Flashing... -
Page 22: Setting Power Indicator
-. Changing Orientation This function allows you to change the orientation of the Adjustment menu when using the monitor screen in vertical display position. [Procedure] 1. Select <Orientation> in the Adjustment menu <Others> menu. 2. Select <Orientation> in the <Menu Settings> menu. 3. Select “Landscape” or “Portrait” with or . 4. Turn the monitor screen 90° in clockwise direction. Tips • F or using the monitor with “Portrait” position, the graphics board supporting portrait display is required. When using the monitor with "Portrait" position, the setting needs to be changed depending on the graphics board used in your PC. -. Setting EIZO Logo Display When switching on the power button on the front control panel, the EIZO logo is displayed for a while. If you desire to display or undisplay this logo, use this function. (Default is logo appearing.) [To undisplay] 1. Press to turn off the unit. 2. Press again while pressing . The EIZO logo does not appear on the screen. [To display] 1. Press to turn off the unit. 2. Press again while pressing . The EIZO logo appear on the screen. -
Page 23: Troubleshooting
.Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • N o-picture problems : See No.1 - No.2 • I maging problems : See No.3 - No.14 • O ther problems : See No.15 - No.18 • U SB problems : See No.19 Problems 1. No picture • Power indicator does not light. • Power indicator is lighting blue. • Power indicator is lighting orange. • Power indicator is flashing orange. 2. - Page 24 Problems • The message below shows that the input signal is out of the specified frequency range. (Such signal frequency is displayed in red.) Example: 3. Display position is incorrect. 4. Screen image displayed is smaller or larger than the actual screen image.
- Page 25 • Check that the USB cable is correctly connected. • Check the downstream ports by connecting the peripherals to other downstream ports. If the problem is solved by doing this, contact an EIZO dealer. (For details, refer to the manual of the PC.) • Reboot the PC •...
-
Page 26: Reference
. Reference -1. Attaching an Arm The LCD monitor can be used with an arm by removing the tilt stand and attaching the arm stand to the LCD monitor. Use an arm or stand of EIZO option. Note • W hen attaching an arm or stand, follow the instructions of their user’s manual. • W hen using another manufacturer’s arm or stand, confirm the following in advance and select one conforming to the VESA standard. - Hole spacing on the arm mounting: 100 mm x 100 mm - Thickness of plate: 2.6 mm - Strong enough to support weight of the monitor unit (except the stand) and attachments such as cables. • W hen using an arm or stand, attach it to meet the following tilt angles of the monitor. - Up 45 degrees, down 45 degrees (horizontal display, and vertical display rotated 90 degrees clockwise) • P lease connect cables after attaching an arm stand. • S ince the monitor and arm are so heavy, dropping them may result in injury or equipment damage. Setup Procedure Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down. Remove the tilt stand by loosening the screws. Unscrew the four screws securing the unit and the satand with the screwdriver. Attach an arm stand to the LCD monitor securely. Secure the monitor to the arm or stand using the screws specified in the user's manual of the arm or stand. -
Page 27: Connecting Two Pcs To The Monitor
-. Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-I connector and DisplayPort connector on the back of the monitor. Connection examples PC 1 Signal Cable (FD-C39 enclosed) (Ex.1) Digital DVI Signal Cable D-Sub (FD-C16 enclosed) (Ex.2) Analog mini 15 Selecting input signal Switch the input signal with . Input signal switches each time is pressed. When the signal is switched, the active signal type (DVI digital, DVI analog or DisplayPort) appears at the top right corner of the screen. Input Signal Selection button The monitor recognizes the connector through which PC signals are input. When either PC is turned off or enters the power-saving mode, the monitor automatically displays signals of another PC. -
Page 28: Utilizing Usb (Universal Serial Bus)
-. Utilizing USB (Universal Serial Bus) This monitor provides a hub which supports the USB standard. When connecting to a USB compliant PC or another hub, the monitor functions as a hub to which the USB compliant peripherals can be easily connected. Required system environment • PC equipped with USB ports or another USB hub connected to the USB compliant PC • Windows 2000/XP/Vista // Mac OS 9.2.2/Mac OS X 10.2 or later • USB Cable (MD-C93, enclosed) Note • The USB hub function may not work properly depending on the PC or peripherals. Please consult the manufacturer of each device about the USB support. • Using the USB Rev. 2.0 compatible PC or peripherals is recommended. • Devices connected to the USB port (upstream and downstream) work when the monitor is in power saving mode or when the power button of the monitor is Off. Therefore, power consumption of the monitor varies with connected devices even in the power saving mode. • When the main power switch is Off, device connected to the USB port will not operate. • The followings are procedures for the Windows 2000/XP/Vista and Mac OS. Connecting to the USB HUB Connect the monitor to the PC with the signal cable first, then turn on the PC. Connect the upstream port of the monitor to the downstream port of the USBcompliant PC or another hub by using the USB cable. After connecting the USB cable, the USB function can be set up automatically. After setting up, the monitor's USB hub is available for connecting USB compliantperipherals to the downstream ports of the monitor. Upstream Downstream... -
Page 29: Setting Range Of Frequency
-. Setting Range of Frequency Depending upon your operating environment, it may be necessary to set the frequency that corresponds to your graphics board. If you install it for the first time or change environment, set the monitor. NOTE • R efer to the manual of the graphics board. •These environment described below can be set regardless of whether or not the computer is running. How to set Press to turn off the unit. Press again while pressing Select the input signal using the center of the monitor. Use to select (or just confirm) the frequency that corresponds to your graphics board, and then press [Analog Input] Setting Normal Wide [Digital Input (DVI/DisplayPort)] Setting Normal Wide Restart the computer if the settings have been changed. in the <Signal Selection> menu at the Horizontal scanning frequency (kHz) 24~94 24~130 Horizontal scanning frequency (kHz) 31~76... -
Page 30: Specifications
-. Specifications LCD Panel Size Surface treatment Surface hardness Response Time Viewing Angle Dot Pitch Horizontal Scan Analog Frequency Digital Vertical Scan Analog Frequency Digital Resolution Dot Clock Analog (Max.) Digital Display Colors Recommended Brightness Display Area Power Supply Power Screen Display On Consumptionl... -
Page 31: Default Settings
Weight with stand without stand Approx. 7.1 kg (15.7 lbs.) with hood Movable range Height adjustable stand Environment Temperature Conditions Humidity Pressure standard USB port Communication Speed Power Supply Downstream: 500 mA for each (max.) Default settings Brightness Smoothing Temperature FineContrast Mode PowerManager Screen Size... - Page 32 Dimensions 190(7.5) SWIVEL 566(22.3) 520.4(20.5) 399.5(15.7) 571(22.5) 398.5(15.7) 287.5(11.3) 233(9.2) 30.4(1.2) 230(9.1) 347.6(13.7) 236(9.3) 229(9.0) 151(5.9) 45.6 (1.8) uinit: mm (inch) 100(3.9) 233(9.2)
-
Page 33: Pin Assignment
Pin Assignment •DVI-I Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Pin No. Signal TMDS Data 2- TMDS Data 2+ TMDS Data2/4 Shield DDC Clock (SCL) DDC Data (SDA) Analog Vertical Sync TMDSData1-... -
Page 34: Glossary
-. Glossary Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. To convert the signal correctly, the LCD monitor needs to produce the same number clock pulse as the dot clock of the graphics system. When the clock pulse is not correctly set, some vertical bars of distortion are displayed on the screen. DisplayPort VESA provides the digital interface standard for the digital display device. DisplayPort can transfer the video signal up to 16 bits for each channel of RGB, and the audio signal too. (This monitor supports the 8-bit video signal only and not audio signal.) DVI (Digital Visual Interface) A digital flat panel interface. DVI can transmit digital data from the PC directly without loss with the signal transition method "TMDS". There are two kinds of DVI connectors. One is DVI-D connector for digital signal input only. The other is DVI-I connector for both digital and analog signal inputs. DVI DMPM (DVI Digital Monitor Power Management) The Power management system for the digital interface. The "Monitor ON" status (operation mode) and the "Active Off" status (power-saving mode) are indispensable for the DVI-DMPM as the monitor's power mode. - Page 35 Resolution The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. The display panel of this monitor consists of 1920 horizontal pixels and 1200 vertical pixels. At a resolution of 1920 x 1200 , images are displayed as a full screen(1:1). sRGB (Standard RGB) "International Standard for Red, Green, and Blue color space" A color space was defined with the aim of the color matching between applications and hardware devices, such as monitors, scanners, printers and digital cameras. As a standard default space, sRGB allows Internet users to closely match colors. Temperature Color Temperature is a method to measure the white color tone, generally indicated in degrees Kelvin. At high temperatures the white tone appears somewhat blue, while at lower temperatures it appears somewhat red. Computer monitors generally give best performance at high temperature settings. 5000 K: Slightly reddish white (usually used in print industry) 6500 K: White called daylight color (suited for web browsing) 9300 K: Slightly bluish white (usually used for television) TMDS (Transition Minimized Differential Signaling) A signal transition method for the digital interface. VESA DPMS (Video Electronics Standards Association - Display Power Management Signaling) The acronym VESA stands for "Video Electronics Standards Association", and DPMS stands for "Display Power Management Signaling". DPMS is a communication standard that PCs and graphics boards use to implement power savings on the monitor side.
-
Page 36: Appendix/Anhang/Annexe
. APPENDIX/ANHANG/ANNEXE Preset Timing Chart for Analog input Timing-Übersichten für Analog Eingang Synchronisation des Signaux pour Analog numerique NOTE • B ased on the signal diagram shown below factory presets have been registered in the monitor's microprocessor. • D er integrierte Mikroprozessor des Monitors unterstützt werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme). • S ignaux ont été enregistrés en usine dans le microprocesseur du moniteur, conformément au diagramme de synchronisation ci-dessous. Mode VGA 640×480@60Hz VGA TEXT 720×400@70Hz Macintosh 832×624@75Hz Macintosh 1280×960@75Hz VESA 640×480@72Hz VESA 640×480@75Hz VESA 640×480@85Hz... - Page 37 Mode VESA CVT 1920 × 1200@60Hz VESA CVT RB 1920×1200 60Hz Dot Clock Horizontal 193.25 MHz Vertical Horizontal 154.00 MHz Vertical Frequencies Sync Polarity Horizontal:kHz Vertical:Hz 74.56 Negative 59.89 Positive 74.04 Positive 59.95 Negative...
-
Page 38: About Tco'03
Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment. -
Page 39: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (Enclosed) This Class B digital apparatus complies with Canadian ICES-003. -
Page 40: Hinweis Zur Ergonomie
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß muß den nachfolgenden Anforderungen entsprechen: a) D er Standfuß muß eine ausreichende mechanische Stabilität zur Aufnahme des Gewichtes vom Bildschirmgerät und des spezifizierten Zubehörs besitzen. Das Gewicht des Bildschirmgerätes und des Zubehörs sind in der zugehörenden Bedienungsanleitung angegeben. b) D ie Befestigung des Standfusses muß derart erfolgen, daß die oberste Zeile der Bildschirmanzeige nicht höher als die Augenhöhe eines Benutzers in sitzender Position ist. c) I m Fall eines stehenden Benutzers muß die Befestigung des Bildschirmgerätes derart erfolgen, daß die Höhe der Bildschirmmitte über dem Boden zwischen 135 – 150 cm beträgt. d) D er Standfuß muß die Möglichkeit zur Neigung des Bildschirmgerätes besitzen (max. vorwärts: 5°, min. nach hinten ≥...
