User's Manual
Color Management LCD Monitor
Important
Please read PRECAUTIONS, this User's Manual, and the Setup Guide (separate volume) carefully to familiarize yourself
with safe and effective usage.
• Please refer to the Setup Guide for basic information ranging from connection of the monitor to a PC or external
device to using the monitor.
• The latest User's Manual is available for download from our web site:
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo ColorEdge CG2420
Summary of Contents for Eizo ColorEdge CG2420
- Page 1 User’s Manual Color Management LCD Monitor Important Please read PRECAUTIONS, this User’s Manual, and the Setup Guide (separate volume) carefully to familiarize yourself with safe and effective usage. • Please refer to the Setup Guide for basic information ranging from connection of the monitor to a PC or external device to using the monitor.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Notice For This Monitor
Notice for this monitor Notice for this monitor Aside from general purposes like creating documents, viewing multimedia content, this product is also suited to applications such as creations of images and graphics, and digital photo processing, where accurate color reproduction is a priority. This product has been adjusted specifically for use in the region to which it was originally shipped. -
Page 4: Cleaning
Notice for this monitor The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. -
Page 5: Table Of Contents
Contents Contents Notice for this monitor ................. 3 3-2. Setting Menu Functions ................19 ● Color ......................19 Cleaning .........................4 ● SelfCalibration ...................24 To use the monitor comfortably ................4 ● Signal Settings...................27 ● Preferences ....................30 Contents ......................5 ● Languages ....................33 Chapter 1 Introduction ................7 ●... - Page 6 Contents 6-6. Specifications ..................48 ● Dimensions ....................50 ● Main Default Settings ................52 ● Accessories ....................52 Chapter 7 Glossary ..................53 Appendix ..................... 55 Trademark ......................55 License ........................55 FCC Declaration of Conformity .................56 - 6 -...
-
Page 7: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 24.0″ widescreen ® • Wide color gamut display (Adobe RGB coverage: 99%) • Achieves contrast ratio of 1500:1 A high contrast ratio allows display of crisper black with reduced whiteness. - Page 8 Chapter 1 Introduction • Equipped with a USB Hub function that supports USB 3.0 Achieves high-speed data transfers of up to 5 Gbps, which enables transfers of large amounts of data to and from USB-connected devices in a short amount time. Also, the “CHARGE”...
-
Page 9: Controls And Functions
Chapter 1 Introduction 1-2. Controls and Functions ● Front Approx. 30° Setting menu 1. Built-in calibration sensor Executes calibration for an independent monitor. SelfCalibration function (page 24)) Attention • Do not touch the sensor as this will affect the measurement accuracy. 2. -
Page 10: Rear
Chapter 1 Introduction ● Rear 4. Main power switch Turns the main power on ( ) or off ( 5. Power connector Connects the power cord. 6. Input signal connectors Left: DVI-D connector / Center: HDMI connector / Right: DisplayPort connector 7. -
Page 11: Supported Resolutions
Chapter 1 Introduction 1-3. Supported Resolutions The monitor supports the following resolutions. ● When using digital signal input (DVI-D, DisplayPort, HDMI: PC signal) Resolution Vertical scan frequency 640 x 480 60 Hz 720 x 400 70 Hz 800 x 600 60 Hz 1024 x 768 60 Hz... -
Page 12: When Using Digital Signal Input (Hdmi: Video Signal )
Chapter 1 Introduction ● When using digital signal input (HDMI: Video signal Vertical scan frequency Resolution 24Hz 25Hz 30Hz 50Hz 60Hz 640 x 480 √ 720 × 480 (480i) √ 720 × 480 (480p) √ 720 × 576 (576i) √ 720 ×... -
Page 13: Changing The Pc Display Settings
Chapter 1 Introduction 1-4. Changing the PC Display Settings If the screen is not properly displayed after connecting the monitor to a PC, follow the procedure below to change the PC display settings. ● Windows 10 1. Right-click anywhere on the desktop except for on icons to display the menu. 2. -
Page 14: Macos
Chapter 1 Introduction ● macOS 1. Select “System Preferences” from the Apple menu. 2. When the “System Preferences” panel is displayed, click “Displays”. 3. If there are multiple monitors including the notebook PC screen connected to the computer, open the “Arrangement” tab and confirm that “Mirror displays” is not selected. -
Page 15: Chapter 2 Basic Adjustments/Settings
Chapter 2 Basic Adjustments/Settings Chapter 2 Basic Adjustments/Settings This chapter describes the basic functions that can be adjusted and set by touching the switches on the front of the monitor. For advanced adjustment and setting procedures using the Setting menu, see “Chapter 3 Advanced Adjustments/Settings”... -
Page 16: Switching Input Signals
Chapter 2 Basic Adjustments/Settings 2-2. Switching Input Signals When a monitor has multiple signal inputs, the signal to display on-screen can be changed. When the input signal is switched, the connector name of the displayed signal appears at the bottom right of the screen. - 16 -... -
Page 17: Switching The Display Mode (Color Mode)
Chapter 2 Basic Adjustments/Settings 2-3. Switching the display mode (color mode) This function allows easy selection of a display mode according to monitor application. ● Display Modes Color Mode Purpose Standard Mode Adjust color using the Color Management Software “ColorNavigator 7” or the monitor’s Setting menu. Custom Select for configuring color settings according to your preference. -
Page 18: Chapter 3 Advanced Adjustments/Settings
Chapter 3 Advanced Adjustments/Settings Chapter 3 Advanced Adjustments/Settings This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For the basic adjustment/setting functions using the switches on the front of the monitor, see “Chapter 2 Basic Adjustments/Settings” (page 15). -
Page 19: Setting Menu Functions
Chapter 3 Advanced Adjustments/Settings 3-2. Setting Menu Functions ● Color The setting details differ depending on the color mode selected. When the color mode is Standard Mode (Custom / Adobe RGB / sRGB) ® Each color mode setting status can be adjusted according to personal preference. Attention •... - Page 20 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Temperature Native The color temperature can be adjusted. • When you select “Native”, the original color of 4000 K to 10000 K The color temperature is used to express the hue of “White” or the monitor (Gain: 100% for each RGB) is dis- ®...
- Page 21 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Advanced Set- Clipping The method of displaying colors outside the monitor’s displayable • The diagrams on the left are conceptual tings range within the color gamut specified in accordance with “Color diagrams, and do not display the actual color Gamut”...
- Page 22 Chapter 3 Advanced Adjustments/Settings When the color mode is Advanced Mode (CAL mode: CAL1 / CAL2 / CAL3) You can set the calibration targets, and check the calibration results, for SelfCalibration. (SelfCalibration is a function that automatically operates a calibration sensor built in to the monitor to periodically calibrate the monitor. For more information, “SelfCalibration”...
- Page 23 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Target Brightness 30 cd/m Set the brightness that will be used as a calibration target for 200 cd/m SelfCalibration. White White(x) / White(y) 0.2400 to 0.4500 Set the White Point that will be used as a calibration target for •...
-
Page 24: Selfcalibration
Chapter 3 Advanced Adjustments/Settings ● SelfCalibration This product is equipped with a built-in calibration sensor. By setting the calibration targets and execution schedule in advance, the calibration sensor automatically operates and regularly calibrates the monitor. This automatic calibration function is called “SelfCalibration”. The adjustment content of SelfCalibration differs depending on the color mode that is executed. - Page 25 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Execute SelfCalibration can be executed manually regardless of the • After selecting “Execute”, warming schedule. up (after the power to the monitor is switched on, the monitor requires a certain period of time until the display becomes stable) may be executed before the built-in calibra- tion sensor comes out.
- Page 26 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Settings Schedule Frequency Daily Select the SelfCalibration execution cycle. Weekly Monthly Quarterly Biannually Annually Usage Time Timing Jan/Apr/Jul/Oct When the execution cycle is “Quarterly”, “Biannually”, Feb/May/Aug/Nov “Annually”, or “Usage Time”, select the timing for executing Mar/Jun/Sep/Dec SelfCalibration.
-
Page 27: Signal Settings
Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Settings Clock Adjustment Set the monitor date and time. • When the clock has not been set, the schedule will not be applied. • If the main power supply is discon- nected for an extended period of time, the clock may need resetting. - Page 28 Chapter 3 Advanced Adjustments/Settings Input Signal (The setting range of each function differs depending Adjustable on the input signal.) Function Description Note range √: Settable -: Not settable DisplayPort HDMI Picture Expansion √ √ √ Auto The screen size of the monitor display can be changed. •...
- Page 29 Chapter 3 Advanced Adjustments/Settings Input Signal (The setting range of each function differs depending Adjustable on the input signal.) Function Description Note range √: Settable -: Not settable DisplayPort HDMI Input Range √ √ √ Auto Depending on the external device, the black and white levels Full in the video signal output to the monitor may be restricted.
-
Page 30: Preferences
Chapter 3 Advanced Adjustments/Settings ● Preferences The monitor’s settings can be configured to suit the usage environment or personal preference. Function Adjustable range Description Note Auto Input Detection When this function is set to “On”, the monitor automatically rec- • When the main power is turned on/off, the ognizes the connector through which signals are input, so that signal is detected automatically regardless of the screen can be displayed. - Page 31 Refer to the User’s Manual of the graphics board for details. Also, visit the EIZO website (www.eizoglobal.com). • When using the monitor in a portrait position,...
- Page 32 Chapter 3 Advanced Adjustments/Settings Function Adjustable range Description Note Power Save This function allows you to set the monitor to the power saving • At the time of shifting to power saving mode, mode, depending on the state of an external device connected a message that indicates the transition is to it.
-
Page 33: Languages
Chapter 3 Advanced Adjustments/Settings ● Languages The display language for menus and messages can be selected. Adjustable range English, Deutsch, Français, Español, Italiano, Svenska, Japanese, Simplified Chinese, Traditional Chinese ● Information You can check the monitor information (model name, serial number, firmware version, usage time, ColorNavigator license status, resolution, input signal, etc.). Example: - 33 -... -
Page 34: Chapter 4 Administrator Settings
Chapter 4 Administrator Settings Chapter 4 Administrator Settings This chapter describes how to configure monitor operation using the “Administrator Settings” menu. This menu is for administrators. Configuration on this menu is not required for normal monitor use. 4-1. Basic Operation of the “Administrator Settings” menu Menu display Settings 1. -
Page 35: Administrator Settings" Menu Functions
Description Note On-Screen Logo When the monitor is turned on, the EIZO logo appears on the screen. When this function is set to “Off”, the EIZO logo does not appear. Key Lock In order to prevent changes to settings, the operation switches on the Menu front of the monitor can be locked. -
Page 36: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Chapter 5 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. 5-1. No picture Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. -
Page 37: Imaging Problems
“Color” (page 19)). (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) 2. Afterimages appear • Afterimages are particular to LCD monitors. Avoid displaying the same image for a long time. -
Page 38: Other Problems
• If the peripheral devices work correctly when the PC and peripheral devices are connected directly, contact your local EIZO representative. • Check whether the PC and OS are USB compliant. (For USB compliance of the respective devices, consult their manu- facturers.) -
Page 39: Built-In Calibration Sensor And Selfcalibration Problems
• Calibration may have failed. Ensure that the built-in calibration sensor is not exposed to strong light such as direct sunlight, and then execute SelfCalibration again. 0030 • The built-in calibration sensor may have failed. Contact your local EIZO representative. 0034 • Measurement failed. Execute SelfCalibration again. -
Page 40: Chapter 6 Reference
Chapter 6 Reference Chapter 6 Reference 6-1. Removing the Stand The stand section of this product can be removed. Attention • Do not move the removed stand up and down. Doing so may result in injury or equipment damage. • The monitor and stand are heavy. Dropping them may result in injury or equipment damage. To prevent damaging the panel surface, lay the monitor with its panel surface facing down on a soft cloth spread on a stable surface. -
Page 41: Attaching The Optional Arm
Chapter 6 Reference 6-2. Attaching the Optional Arm An optional arm (or an optional stand) can be attached by removing the stand section. Please refer to our web site for the corresponding optional arm (or optional stand). www.eizoglobal.com Attention • When attaching an arm or stand, follow the instructions of their User's Manual. •... - Page 42 Chapter 6 Reference Attaching the Optional Arm (or Optional Stand) Attach the arm or stand to the monitor. Use the VESA mounting screws supplied with this product when attaching the arm or stand. - 42 -...
- Page 43 Chapter 6 Reference Attaching the original stand To prevent damaging the panel surface, lay the monitor with its panel surface facing down on a soft cloth spread on a stable surface. Remove the fixing screws on the optional arm (or optional stand), and detach the optional arm (or optional stand). Attach the original stand.
-
Page 44: Attaching/Detaching Cable Holder
Chapter 6 Reference 6-3. Attaching/Detaching Cable Holder A cable holder is supplied with this product. Use the cable holder to organize the cables connected to the monitor. Attachment procedure Pass the cables through the cable holder. Close the cable holder. While holding the cable holder closed, insert it into the stand. - Page 45 Chapter 6 Reference Note • The cable holder can be inserted either perpendicular or parallel to the stand. Change the orientation of the cable holder in line with the direction of the cables. Detachment procedure Close the cable holder. While holding the cable holder closed, pull it from the stand. - 45 -...
-
Page 46: Connecting Multiple External Devices
Chapter 6 Reference 6-4. Connecting Multiple External Devices The product allows you to connect multiple external devices and switch between them for display. Connection Note examples • The input signal changes each time the operation switch ( ) on the front of the monitor is touched. -
Page 47: Making Use Of Usb (Universal Serial Bus)
• A PC equipped with a USB port • Windows 10 / Windows 8.1 / Windows 8 / Windows 7, or Mac OS X 10.7.5 or later • EIZO USB cable (UU200SS (USB 3.0)) Attention • This monitor may not work depending on the used PC, OS or peripheral devices. For USB compatibility of peripheral devices, contact their manufactures. -
Page 48: Specifications
Chapter 6 Reference 6-6. Specifications LCD Panel Type IPS (Anti-Glare) Backlight Wide color gamut LED Size 61 cm (24.0inch) Resolution 1920 dots × 1200 lines Display Size (H × V) 518.4 mm × 324.0 mm Pixel Pitch 0.270mm×0.270mm Display Colors Approx. - Page 49 Chapter 6 Reference Physical Dimensions Min. height: 554.4 mm × 396 mm × 245 mm (W × H × D) (Tilt: 0˚) Specifications Max. height: 554.4 mm × 558 mm × 265 mm (W × H × D) (Tilt: 35˚) Dimensions (Without Stand) 554.4 mm ×...
-
Page 50: Dimensions
Chapter 6 Reference ● Dimensions Unit: mm 344° 341.5 554.4 519.8 (227.2) (227.2) VESA 122.6 62.7 - 50 -... - Page 51 Chapter 6 Reference Unit: mm 572.4 - 51 -...
-
Page 52: Main Default Settings
Chapter 6 Reference ● Main Default Settings Color Mode Custom Picture Expansion DVI input Aspect Ratio DisplayPort input Aspect Ratio HDMI input Aspect Ratio (When “Auto” is enabled: Auto) Input Color Format DisplayPort input Auto HDMI input RGB (When “Auto” is enabled: Auto) Input Range DVI input Full... -
Page 53: Chapter 7 Glossary
Chapter 7 Glossary Chapter 7 Glossary Adobe ® This is a definition of the practical RGB color space proposed by Adobe Systems in 1998. The color reproduction range (color gamut) is broader than sRGB, and is highly adaptable to such fields as printing etc. Color Space YUV and RGB, etc. - Page 54 Chapter 7 Glossary HDCP (High-bandwidth Digital Content Protection) Digital signal coding system developed to copy-protect the digital contents, such as video, music, etc. This helps to transmit the digital contents safely by coding the digital contents sent via the DVI or HDMI connector on the output side and decoding them on the input side.
-
Page 55: Appendix
Apple, macOS, Mac OS, OS X, Macintosh and ColorSync are registered trademarks of Apple Inc. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. -
Page 56: Fcc Declaration Of Conformity
Trade name: EIZO Model: ColorEdge CG2420 is in conformity with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 57: Canadian Notice
Appendix Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord - Shielded Signal Cable (enclosed) Canadian Notice This Class B digital apparatus complies with Canadian ICES-003. - Page 58 03V25549B1 UM-CG2420 Copyright © 2016-2019 EIZO Corporation. All rights reserved. 2nd Edition-May, 2019...
