4 x 40 Daystar Nova LCD Module
Parallel Data Input Option and EL Backlight
B
B
B
B
B
B
4
5
6
7
8
9
CONTRACT
R. January
DRAWN
CHECK
APPROVED
D. Goodale 3-19-93
APPROVED
DESCRIPTION
Specification
with
Model 03858–21–0105
B
B
B
B
B
10
11
12
13
14
REVISION STATUS
3–19–93
4 X 40 LCD MODULE WITH EL BACKLIGHT
SIZE
CODE IDENT NO.
05464
A
SCALE
REVISIONS
B
B
B
B
B
15
16
17
18
19
INDUSTRIAL ELECTRONIC ENGINEERS, INC.
VAN NUYS, CALIFORNIA
PARALLEL DATA INPUT
S03858–21–0105
SHEET
DATE
APPROVED
3/19/93
D. Goodale
6/3/93
D. Goodale
2/13/02
D. Goodale
B
B
B
B
B
20
21
22
23
24
1
OF
24
Advertisement
Table of Contents
Related Manuals for IEE 03858-21-0105
Summary of Contents for IEE 03858-21-0105
- Page 1 APPLICATION REVISIONS NEXT ASSY FINAL ASSY DESCRIPTION DATE APPROVED – PRODUCTION RELEASE/E.O. 29227 3/19/93 D. Goodale E.O. 29437 6/3/93 D. Goodale E.O. 36743, Revised and Redrawn 2/13/02 D. Goodale Specification 4 x 40 Daystar Nova LCD Module with Parallel Data Input Option and EL Backlight Model 03858–21–0105 SHEET REVISION STATUS...
-
Page 2: Table Of Contents
Table of Contents Paragraph Title Page GENERAL INFORMATION..........................5 1.1 Introduction..............................5 1.2 Application ..............................5 1.3 Description ..............................5 LOGICAL STRUCTURE AND FUNCTION ....................6 2.1 LCD Module..............................6 2.1.1 Signal Description..........................6 2.2 LCD Controller ..............................7 2.2.1 Instruction Register (IR).........................7 2.2.2 Data Register (DR)..........................7 2.2.3 Busy Flag ...............................7 2.2.4 Address Counter (AC) ...........................7 2.2.5 Display Data RAM (DD RAM) ........................7 2.2.6 Character Generator ROM (CG ROM) ....................8... - Page 3 Table of Contents Paragraph Title Page 7.3 Operation..............................11 7.3.1 Normal Operation..........................11 7.3.2 Brightness, Voltage and Frequency Characteristics................11 7.3.3 Intermittent Operation ..........................11 7.3.4 Square Waveform Operation.......................11 7.3.5 Operating Temperature ........................11 7.3.6 Operating Life............................11 7.4 Electromagnetic Interference (EMI) ......................11 7.5 DC–AC Inverter ............................11 INSTALLATION NOTE ..........................11 ACCESSORIES............................11 10.0 OUTLINE and installation characteristics ....................11...
- Page 4 List of Figures Figure Title Page Figure 1 Module Block Diagram ...........................6 Figure 2 LCD Controller Block Diagram ......................7 Figure 3 Correspondence Between Character Codes and Character Patterns ..........8 Figure 4 Relationship Between CG RAM Address, Character Codes (DD RAM) and Character Patterns (CG RAM Data)............................9 Figure 5 LCD Controller Instruction Set......................10...
-
Page 5: General Information
Super Bi–refringent Effect (SBE) liquid crystal cell used in this display. For applications where the display is remotely located up to 50 feet from the host processor, the serial data input option should be used. The serial model is described in IEE specification S3858–21–205. Description The Daystar Nova module is a self–contained 1/16 multiplexed unit. -
Page 6: Logical Structure And Function
LOGICAL STRUCTURE AND FUNCTION LCD Module Figure 1 illustrates the major components of the serial option Daystar Nova module. The module provides means for an external viewing angle adjustment potentiometer (V Adj.) at Pin 4, and connections for optional BIAS RESET and self–test switches at Pins 3 and 5. -
Page 7: Lcd Controller
LCD Controller The LCD Controller includes all of the circuitry necessary to take parallel input data and create the necessary control functions and characters. The block diagram of the controller is shown in Figure 2 below. The remaining subparagraphs of Section 2 describe the major function blocks. Address Timing Generation Counter (AC) -
Page 8: Character Generator Rom (Cg Rom)
2.2.6 Character Generator ROM (CG ROM) The CG ROM generates character patterns of 5 X 7 dots from 8 bit character codes. The 192 5 X 7 dot matrix characters are illustrated in Figure 3. Figure 3 Correspondence Between Character Codes and Character Patterns Note: Addresses 00h through 0Fh are reserved for CG RAM Addressing. -
Page 9: Character Generator Ram (Cg Ram)
2.2.7 Character Generator RAM (CG RAM) The CG RAM allows the user to define 8 types of 5 X 7 character patterns. Figure 4 shows the relationship between CG RAM addresses and data patterns (Refer to Set CG RAM Address and Write to CG or DD RAM instructions). -
Page 10: Operation
OPERATION Instruction Set Instruction Code Description Execution R/W DB Time (Max) Clear Display Clears entire display and sets DD RAM to 0 1.64 ms Sets DD RAN counter to 0. If the display has been shifted, characters are returned to their initial Return Home 1.64 ms positions. -
Page 11: Power Up Instructions Sequence
Power Up Instructions Sequence Upon power up, the Daystar Nova module is set to a default mode of operation. Under some power up circumstances, the default mode may be improperly set. Consequently, the following instructions should always be executed in the host systems initialization routine. Step Operation Function Set for 8 bits... -
Page 12: Instructions Affecting Custom Characters
MPU1 MPU2 * = Cursor Figure 8 Display Shift Right from Initial Conditions MPU1 MPU2 * = Cursor # = Last Character Entered Figure 9 Load Character with S=1, I/D=0 from Initial Conditions MPU1 MPU2 * = Cursor # = Last Character Entered Figure 10 Load Character with S=1, I/D=1 from Initial Conditions Instructions Affecting Custom Characters... -
Page 13: Electrical Characteristics
Electrical Characteristics (V = 5V ±10%) Item Symbol Condition Unit Input "High" Voltage Input "Low" Voltage –0.3 Output "High" Voltage (TTL) = 0.205 mA – Output "Low" Voltage (TTL) = 1.200 mA – Output "High" Voltage (CMOS) = 0.040 mA 0.9 V –... - Page 14 t t t t t t t t t t t t Valid Data – DB Figure 11 Interface Timing (Write) – DB Valid Data Figure 12 Interface Timing (Read) SIZE CODE IDENT NO. Industrial Electronic Engineers, Inc. S03858–21–0105 05464 Van Nuys, California Scale: NONE Sheet 14...
-
Page 15: Timing Sequence For 8 Bit Parallel Interface
Timing Sequence for 8 Bit Parallel Interface Figure 13 illustrates the typical Busy Flag check sequence for an 8 bit data interface. Internal Internal Operation Data Busy Busy IR 7 Busy Instruction Busy Flag Busy Flag Busy Flag Instruction Write Check Check Check... -
Page 16: Connector Pin Assignments (P1)
Connector Pin Assignments (P1) Pin No. Function (Factory Set–up Test Point) BIAS N/C * (Viewing Angle Adjustment) (Read = Logic 1) (Pin Removed) Ground Enable (E1) Ground Ground Ground Ground Ground Ground (+5V – Parallel with Pin 24) (+5V – Parallel with Pin 22) When the display module includes the serial data input option, Pin 3 is internally connected to provide signal E2 as an output to a second display module. -
Page 17: Environmental Characteristics
ENVIRONMENTAL CHARACTERISTICS Operating Temperature: –30 to +80°C (Backlight Off) –30 to +40ºC (Backlight On, See Paragraph 7.3.5) Humidity: (@ 40ºC) 95% RH (non–condensing) Humidity ( 40 C): Absolute humidity must be lower the humidity of 95% RH at 40 C Vibration: 10g at 10 to 400Hz (3 axes) Shock:... - Page 18 Normal = +90º –X = –90º –Y Figure 15 Definition of Vertical Viewing Angle Definition of Horizontal Viewing Angle–top Viewing Display (for Bottom Viewing Displays = –20° Typically) Normal = +20º – –X = –90º = +90º –Y Figure 16 Definition of Horizontal Viewing Angle Display contrast ratio is given by: Where: B...
-
Page 19: Viewing Angle Adjustment
Brightness Curve for Selected Segment Brightness Curve for Non–selected Segment Setpoint Driving Voltage Figure 17 Definition of Contrast Ratio (CR) Definition of optical response. 10% ON 90% ON Excitation Figure 18 Definition of Optical Response Viewing Angle Adjustment The factory preadjusts the viewing angle of the display by setting the LCD bias voltage to 10.2 Volts using the on–board potentiometer. -
Page 20: El Backlighting
EL BACKLIGHTING EL Backlight Description The module contains an AC EL backlight which enables the LCD to read under low lighting conditions. The EL lamp provides uniform lighting across the entire display surface. Since the lamp is a cold light source, no heat is added to the module during operation. -
Page 21: Intermittent Operation
7.3.2 Brightness, Voltage and Frequency Characteristics (Continued) 25ºC, 115 VRMS, Aviation Green Frequency (Hertz) Figure 20 Initial Brightness vs. Frequency 7.3.3 Intermittent Operation The EL backlight is intended for intermittent usage only. Continuous operation will result in greatly reduced life of the lamp. -
Page 22: Electromagnetic Interference (Emi)
7.5. The brightness values are measures of the lamp surface brightness. The transmitted light through the LCD is approximately 8% of the lamp surface brightness. 25ºC, Aviation Green Time (Hours, 000's) Figure 21 Brightness vs. Time Electromagnetic Interference (EMI) Electroluminescent lamps have been shown to radiate negligible interference through UHF when operated by quasi–sinusoidal waveforms. -
Page 23: Installation Note
INSTALLATION NOTE To protect the front polarizer from accidental damage it is highly recommended that the LCD be mounted behind a clear glass or polycarbonate window material. It is also recommended that an air gap of at least .030" to .050" minimum be provided between the window material and the surface of the LCD to prevent the transfer of static charges to the front surface of the LCD. -
Page 24: Outline And Installation Characteristics
10.0 OUTLINE AND INSTALLATION CHARACTERISTICS Figure 22 03858–21–0105 Outline Drawing SIZE CODE IDENT NO. Industrial Electronic Engineers, Inc. S03858–21–0105 05464 Van Nuys, California Scale: NONE Sheet 24...
