- Page 1 APPLICATION REVISIONS NEXT ASSY FINAL ASSY DESCRIPTION DATE APPROVED – PRODUCTION RELEASE/E.O. 30144 10/6/94 D. Goodale E.O. 36743, Revised and Redrawn 2/13/02 D. Goodale Specification 4 x 40 Daystar Nova LCD Module with Parallel Data Input Option and Fiber Optic Backlight Model 03875–21–0114 SHEET REVISION STATUS...
-
Page 2: Table Of Contents
Table of Contents Paragraph Title Page GENERAL INFORMATION..........................5 1.1 Introduction..............................5 1.2 Application ..............................5 1.3 Description ..............................5 LOGICAL STRUCTURE AND FUNCTION ....................5 2.1 LCD Module..............................5 2.1.1 Signal Description..........................6 2.2 LCD Controller ..............................7 2.2.1 Instruction Register (IR).........................7 2.2.2 Data Register (DR)..........................7 2.2.3 Busy Flag ...............................7 2.2.4 Address Counter (AC) ...........................7 2.2.5 Display Data RAM (DD RAM) ........................7 2.2.6 Character Generator ROM (CG ROM) ....................8... - Page 3 Table of Contents Paragraph Title Page 7.3 Standard Operation.............................21 INSTALLATION NOTE ..........................21 ACCESSORIES............................21 10.0 OUTLINE and installation characteristics ....................22 SIZE CODE IDENT NO. Industrial Electronic Engineers, Inc. S03875–21–0114 05464 Van Nuys, California Scale: NONE Rev A Sheet 3...
- Page 4 List of Figures Figure Title Page Figure 1 Module Block Diagram ...........................6 Figure 2 LCD Controller Block Diagram ......................7 Figure 3 Correspondence Between Character Codes and Character Patterns ..........8 Figure 4 Relationship Between CG RAM Address, Character Codes (DD RAM) and Character Patterns (CG RAM Data)............................9 Figure 5 LCD Controller Instruction Set......................10...
-
Page 5: General Information
For applications where the display is remotely located up to 50 feet from the host processor, the serial data input option should be used. The serial model is described in IEE specification S3875–21–0214. Description The Daystar Nova module is a self–contained 1/16 multiplexed unit. A simple parallel interface is provided and can be configured as either 4 or 8 bits. -
Page 6: 2.1.1 Signal Description
LCD Display FO Backlight 8" Flying Leads LCD Row Drivers and LCD Column Drivers Shift Registers and Shift Registers LCD Controllers Temperature Compensation RS R/W (+5V) Figure 1 Module Block Diagram 2.1.1 Signal Description Signal Name Number Of Lines Input/Output Connected MPU1/MPU2 MPU1/MPU2... -
Page 7: Lcd Controller
LCD Controller The LCD Controller includes all of the circuitry necessary to take parallel input data and create the necessary control functions and characters. The block diagram of the controller is shown in Figure 2 below. The remaining subparagraphs of Section 2 describe the major function blocks. Address Timing Generation Counter (AC) -
Page 8: Character Generator Rom (Cg Rom)
Cursor or Display Shift instructions). 2.2.6 Character Generator ROM (CG ROM) The CG ROM generates character patterns of 5 X 7 dots from 8 bit character codes. The 192 5 X 7 dot matrix characters are illustrated in Figure 3. Figure 3 Correspondence Between Character Codes and Character Patterns SIZE... -
Page 9: Character Generator Ram (Cg Ram)
Note: Addresses 00h through 0Fh are reserved for CG RAM Addressing. Addresses 10h through 1Fh and 80h through 9Fh are not used. 2.2.7 Character Generator RAM (CG RAM) The CG RAM allows the user to define 8 types of 5 X 7 character patterns. Figure 4 shows the relationship between CG RAM addresses and data patterns (Refer to Set CG RAM Address and Write to CG or DD RAM instructions). -
Page 10: Operation
OPERATION Instruction Set Instruction Code Description Execution R/W DB Time (Max) Clear Display Clears entire display and sets DD RAM to 0 1.64 ms Sets DD RAN counter to 0. If the display has been shifted, characters are returned to their initial Return Home 1.64 ms positions. -
Page 11: Power Up Instructions Sequence
Power Up Instructions Sequence Upon power up, the Daystar Nova module is set to a default mode of operation. Under some power up circumstances, the default mode may be improperly set. Consequently, the following instructions should always be executed in the host systems initialization routine. Step Operation Function Set for 8 bits... -
Page 12: Instructions Affecting Custom Characters
MPU1 MPU2 * = Cursor Figure 8 Display Shift Right from Initial Conditions MPU1 MPU2 * = Cursor # = Last Character Entered Figure 9 Load Character with S=1, I/D=0 from Initial Conditions MPU1 MPU2 * = Cursor # = Last Character Entered Figure 10 Load Character with S=1, I/D=1 from Initial Conditions Instructions Affecting Custom Characters... -
Page 13: Electrical Characteristics
Electrical Characteristics (V = 5V ±10%) Item Symbol Condition Unit Input "High" Voltage Input "Low" Voltage –0.3 Output "High" Voltage (TTL) = 0.205 mA – Output "Low" Voltage (TTL) = 1.200 mA – Output "High" Voltage (CMOS) = 0.040 mA 0.9 V –... -
Page 14: Figure 11 Interface Timing (Write)
t t t t t t t t t t t t Valid Data – DB Figure 11 Interface Timing (Write) – DB Valid Data Figure 12 Interface Timing (Read) SIZE CODE IDENT NO. Industrial Electronic Engineers, Inc. S03875–21–0114 05464 Van Nuys, California Scale: NONE Rev A... -
Page 15: Timing Sequence For 8 Bit Parallel Interface
Timing Sequence for 8 Bit Parallel Interface Figure 13 illustrates the typical Busy Flag check sequence for an 8 bit data interface. Internal Internal Operation Data Busy Busy IR 7 Busy Instruction Busy Flag Busy Flag Busy Flag Instruction Write Check Check Check... -
Page 16: Connector Pin Assignments (P1)
Connector Pin Assignments (P1) Pin No. Function (Factory Set–up Test Point) BIAS N/C * (Viewing Angle Adjustment) (Read = Logic 1) (Pin Removed) Ground Enable (E1) Ground Ground Ground Ground Ground Ground (+5V – Parallel with Pin 24) (+5V – Parallel with Pin 22) When the display module includes the serial data input option, Pin 3 is internally connected to provide signal E2 as an output to a second display module. -
Page 17: Environmental Characteristics
ENVIRONMENTAL CHARACTERISTICS Operating Temperature: –30 to +80°C Humidity: (@ 40ºC) 95% RH (non–condensing) Humidity ( 40 C): Absolute humidity must be lower the humidity of 95% RH at 40 C Vibration: 10g at 10 to 400Hz (3 axes) Shock: 10g (all axes) Non–Operating Temperature: –40°C to +85°C... -
Page 18: Figure 15 Definition Of Vertical Viewing Angle
Normal = +90º –X = –90º –Y Figure 15 Definition of Vertical Viewing Angle Definition of Horizontal Viewing Angle–top Viewing Display (for Bottom Viewing Displays = –20° Typically) Normal = +20º – –X = –90º = +90º –Y Figure 16 Definition of Horizontal Viewing Angle Display contrast ratio is given by: Where: B... -
Page 19: Viewing Angle Adjustment
Brightness Curve for Selected Segment Brightness Curve for Non–selected Segment Setpoint Driving Voltage Figure 17 Definition of Contrast Ratio (CR) Definition of optical response. 10% ON 90% ON Excitation Figure 18 Definition of Optical Response Viewing Angle Adjustment The factory preadjusts the viewing angle of the display by setting the LCD bias voltage to 10.2 Volts using the on–board potentiometer. -
Page 20: Fiber Optic Backlight
FIBER OPTIC BACKLIGHT FO Backlight Description The module contains a light emitting flat panel constructed of plastic optical fibers which convey the light from a separately located light source. The panel is heat free, has indefinitely long life and has good brightness uniformity. -
Page 21: Standard Operation
Standard Operation Lamp Color Temperature: 2900 – 3100 K Display Luminance: 3.0 – 4.5 ft–L Luminance Uniformity: AVG 30% Operating Temperature: –30 to +80 C Storage Temperature: –40 to +85 C INSTALLATION NOTE To protect the front polarizer from accidental damage it is highly recommended that the LCD be mounted behind a clear glass or polycarbonate window material. -
Page 22: Outline And Installation Characteristics
10.0 OUTLINE AND INSTALLATION CHARACTERISTICS Figure 20 03875–21–0114 Outline Drawing SIZE CODE IDENT NO. Industrial Electronic Engineers, Inc. S03875–21–0114 05464 Van Nuys, California Scale: NONE Rev A Sheet 22...
