Technical Specifications

Bus type
CPU
Memory
Interrupt request levels
I/O base addresses (hex)
Shared memory range
DSPs
Dimensions
Data transfer rate
Plug&Play
Power safe mode
External interface
Performance
Power requirements
Environmental requirements
• Operating temperature: 15 degrees C to 70 degrees C
• Operating humidity: 10 to 85% (non-condensing)
• Barometric operating pressure: 86 to 106 kPascals
• Maximum tolerance in power supply variation: -5% to +5%
Diva Server T1/PRI
Diva Server Voice T1/PRI
PCI (3,3/5 V)
32 Bit RISC CPU, 180 MHz
8 MB SDRAM
Allocated by PCI BIOS.
Allocated by PCI BIOS.
8 MB
Diva Server T1/PRI:
either 2, 4, 8, or 24 ADSPs 2185L according to model
Diva Server Voice T1/PRI:
either 4, 8, or 24 ADSPs 2185L according to model
T1/PRI: half size PCI
T1/PRI-4M, T1/PRI-8M, T1/PRI-24M: full size PCI
23 x 64 kbps B-channel
1 x 64 kbps D-channel (PRI)
or
24 x 56 kbps (channelized T1)
yes
yes
Female RJ-45 (PRI)
Primary rate interface (up to 24 channels @ 64 kbps each)
channelized T1 interface (up to 24 channels @ 56 kbps each)
T1/PRI-24M:
1,7 A @ +5 V typ.
