B15583/R0/204EN&205EN/U&C
8/6/06
Read and retain carefully for as long as the product is being used. It contains vital information
on the operation and installation. The leaflet should be regarded as part of the product.
If you are just installing the unit, the leaflet must be given to the householder. The leaflet is
to be given to any subsequent user.
1:54 PM
Page 1
BATTERY POWERED

CARBON MONOXIDE ALARM

Model Ei 204EN
Model Ei 205EN
Model Ei 205ENA
Model Ei 205CEN
INSTRUCTIONS
- STANDARD
- WITH MEMORY
- WITH MEMORY &
SEALED IN BATTERIES
- WITH MEMORY &
INTERCONNECT
