Edirol MA-1EX Owner's Manual

Edirol MA-1EX Owner's Manual

Usb stereo speaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
Bedienungsanleitung
Mode d'emploi
Manuale d'uso
Manual del usuario
Left
Right
USB
Rear Panel
MD, DAT
Before using this unit, carefully read the sections entitled: "USING THE UNIT SAFELY" and "IMPORTANT
NOTES." These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your
new unit, Getting Started should be read in its entirety. The manual should be saved and kept on hand as a
convenient reference.
Copyright © 2005 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MA-1EX and is the answer not in the manual?

Questions and answers

Related Manuals for Edirol MA-1EX

Summary of Contents for Edirol MA-1EX

  • Page 1 Owner’s Manual Bedienungsanleitung Mode d’emploi Manuale d’uso Manual del usuario Left Right Rear Panel MD, DAT Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT NOTES.” These sections provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new unit, Getting Started should be read in its entirety.
  • Page 2 USING THE UNIT SAFELY Used for instructions intended to alert the user to the risk of death or severe injury should improperly. Used for instructions intended to alert the user to the risk of injury or material damage should the unit be used improperly.
  • Page 3 • Immediately turn the power off, and request servicing by your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page when: • If smoke or unusual odor occurs • Objects have fallen into, or liquid has been spilled onto the unit;...

  • Page 4: Important Notes

    IMPORTANT NOTES In addition to the items listed under “USING THE UNIT SAFELY” on page 2 and 3, please read and observe the following: Placement • Using the unit near power amplifiers (or other equipment containing large power transformers) may induce hum. To alleviate the problem, change the orientation of this unit;...

  • Page 5: Table Of Contents

    Conexión e instalación de los controladores Español ...22 Usuarios de Windows XP... 22 Usuarios de Mac OS X... 23 Troubleshooting ...24 Problems related to the USB driver... 24 Problems when using the MA-1EX ... 25 Deleting the USB Audio Device driver... 29 Specifications ...30...

  • Page 6: Getting Connected And Installing Drivers English

    * Exit all other applications of the Windows before you install the MA-1EX driver. * If you intend to connect the MA-1EX and other USB devices to your computer and use them simultaneously, disconnect all USB devices other than the MA-1EX from the USB connector before you install the driver.

  • Page 7: Windows Xp/2000 Users

    In order to install software in Windows XP/ 2000, you must log on as a user who has administrative privileges (e.g., Administrator). With the MA-1EX disconnected, start up Windows. Disconnect all USB cables except for a USB keyboard and USB mouse (if used).

  • Page 8: Windows 98 Users

    Getting Connected and Installing Drivers English Windows 98 users The driver necessary for using the MA-1EX with Windows 98 is provided on the Windows CD-ROM. Make sure that you have the Windows CD-ROM available. Some computers are sold with the contents of...
  • Page 9 When installation of the USB Composite Device driver is completed, a dialog box like the one shown here will appear. Click [Finish]. fig.05-27e_30 Next, the USB audio device will be detected automatically, and the “Add New Hardware Wizard” dialog box will appear.

  • Page 10: Settings And Checking (Windows)

    Getting Connected and Installing Drivers English Settings and checking (Windows) ■ Specifying the audio output destination Windows XP users Open the Sound, Speech, and Audio Devices Properties dialog box. 1.From the Windows start menu, choose Control Panel. 2.In “Pick a category,” click Sound, Speech, and Audio Devices.
  • Page 11 *1 If the CD playback volume does not change when you adjust this control, then change the WAVE volume. You will be able to use the MA-1EX at the • best audio quality if you set the Volume Control volume to the maximum setting.
  • Page 12 Getting Connected and Installing Drivers English When playing audio CDs from the computer’s internal CD-ROM drive, or using the MA-1EX to play game music Windows XP/2000 users: Open the System Properties dialog box. Select Start | Settings | Control Panel, and in the Control Panel, double-click the System icon.

  • Page 13: Mac Os X Users

    • Exit your software before you disconnect the MA-1EX’s USB cable. • The MA-1EX will not operate in the Mac OS X Classic environment. You can not use it if the Classic environment is running.

  • Page 14: Mac Os 9 Users

    Wait for approximately five seconds. While you are waiting, the screen display will not change, but the MA-1EX is being detected. Do not touch the mouse or keyboard. In order to check that detection has been...
  • Page 15 MEMO...

  • Page 16: Herstellung Der Verbindung Und Installation Der Treiber Deutsch

    Um Software in Windows XP installieren zu können, müssen Sie sich als Benutzer mit Administrationsrechten (z. B. Administrator) anmelden. Starten Sie Windows, wobei das MA-1EX nicht angeschlossen ist. Entfernen Sie sämtliche USB-Kabel außer denen der USB-Tastatur und der USB-Maus (falls vorhanden).

  • Page 17: Mac Os X-Anwender

    1EX nicht ab, während das Softwareprogramm läuft. • Schließen Sie das Softwareprogramm bevor Sie das USB-Kabel des MA-1EX abziehen. • Der MA-1EX funktioniert nicht in der Mac OS X Classic Umgebung. Sie können MA-1EX nicht verwenden, wenn die Classic Umgebung läuft.

  • Page 18: Connexion Et Installation Des Pilotes Français

    MA-1EX à votre ordinateur et allumez-le (tournez le bouton VOLUME vers la droite). Le MA-1EX (Audio USB) est automatiquement détecté ; le pilote est lui aussi installé automatiquement. L’installation est terminée lorsque le message "Nouveau matériel détecté" a disparu de la barre des tâches.

  • Page 19: Mac Os X

    Il se peut que vous rencontriez des problèmes d'installation si le MA-1EX était connecté lorsque vous avez démarré votre Macintosh. Si cela se produit, débranchez le MA-1EX avant de démarrer votre ordinateur, puis connectez- Démarrez votre Macintosh avant de brancher le MA-1EX.

  • Page 20: Collegamenti E Installazione Dei Driver Italiano

    Per poter installare il software su Windows XP, è necessario essere collegati con un nome utente dotato di privilegi di tipo amministrativo, ad esempio Administrator. Dopo aver scollegato l'MA-1EX, avviare Windows. Scollegare tutti i cavi USB, ad eccezione della tastiera e del mouse USB, se utilizzati.

  • Page 21: Utenti Mac Os X

    In questo caso, accendere il Macintosh con l’MA-1EX scollegato, e collegarlo in seguito. Dopo aver scollegato l'MA-1EX, avviare il Macintosh. Scollegare tutti i cavi USB, ad eccezione della tastiera e del mouse USB, se utilizzati.

  • Page 22: Conexión E Instalación De Los Controladores Español

    1EX al ordenador, y encienda el MA-1EX (gire el mando VOLUME (volumen) hacia la derecha). El MA-1EX (audio USB) se detectará automáticamente, y el controlador se instalará. La instalación se ha completado cuando haya desparecido el mensaje junto a la barra de tareas que indica “Hardware nuevo...

  • Page 23: Usuarios De Mac Os X

    El contenido de la pantalla puede diferir, en función del sistema. Pueden producirse problemas de estabilidad si inicia el Macintosh con el MA-1EX conectado. Si ocurre esto, inicie el Macintosh con el MA- 1EX desconectado, y a continuación conecte el MA-1EX.

  • Page 24: Troubleshooting

    The power conservation mode of your computer may limit the power that is supplied to USB. Check the settings of your computer. In some cases, the MA-1EX cannot be used with a bus-powered hub (a hub that does not contain a power supply). Please use a self-powered hub (a hub that contains a power supply).

  • Page 25: Problems When Using The Ma-1Ex

    • Did you connect the MA-1EX to a different USB connector than the one you used when installing the driver? If your computer or USB hub has two or more USB connectors, and you connect the MA-1EX to a USB connector to which you have not previously connected it, this dialog box may appear even though you have already installed the driver.

  • Page 26: Sound Is Interrupted During Audio Playback

    Troubleshooting Sound is interrupted during audio playback • Graphic accelerators may cause noise to be heard during audio playback. Use the following procedure to set graphic acceleration to “None.” 1. In the Windows Control Panel, double-click Display to open the Display Properties dialog box, and click the Settings tab.
  • Page 27 • Make Windows XP/Windows 2000 settings to enable background processing. Windows XP users 1. Click the Windows start button, and from the menu that appears, select Control Panel. 2. In “Pick a category,” click “Performance and Maintenance.” 3. In “or pick a Control Panel icon,” click the System icon. 4.
  • Page 28 • Are you using a USB device in addition to the MA-1EX? Try switching off USB devices other than the MA-1EX. If you have connected the MA-1EX to an external USB hard disk, please connect the MA-1EX directly to a USB connector on the computer itself.

  • Page 29: Deleting The Usb Audio Device Driver

    Depending on your computer, some of the folder names may be different. 1. Use the USB cable to connect the MA-1EX to your computer. 2. Delete the USB Audio Device driver. Click the Windows Start button, and select Settings - Control Panel.

  • Page 30: Specifications

    Specifications MA-1EX: USB Stereo Speaker ■ Rated Power Output • 1.5 W (0.75 W + 0.75 W) ■ Speaker Units • 60 mm • 2-3/8 inches (Magnetically-Shielded) ■ Frequency Range • 100 Hz to 20 kHz ■ Controller • VOLUME Knob (with Power Switch) ■...

  • Page 31: Federal Communications Commission Radio Frequency Interference Statement

    Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. DECLARATION OF CONFORMITY Compliance Information Statement Model Name : MA-1EX Type of Equipment : USB Stereo Speaker Responsible Party : Roland Corporation U.S.
  • Page 32 Information When you need repair service, call your nearest EDIROL/Roland Service Center or authorized EDIROL/Roland distributor in your country as shown below. HONG KONG Parsons Music Ltd. 8th Floor, Railway Plaza, 39 EUROPE Chatham Road South, T.S.T, EDIROL (Europe) Ltd.
