Owner's Manual
Bedienungsanleitung
Mode d'emploi
Manuale d'uso

Manual del usuario

Thank you for purchasing the EDIROL Bi-Amp Monitor DM-5.
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3-p. 4), and "IMPORTANT
NOTES" (p. 4-p. 5). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a good
grasp of every feature provided by your new unit, this manual should be read in its
entirety. The manual should be saved and kept on hand as a convenient reference.

Main Features

In Pursuit of High Sound Quality
The DM-5 powered monitor uses a two-way, bi-amplifier design to achieve high sound quality.
The monitor features a 120-mm LF Driver and a 19-mm soft-dome HF Driver as speakers. The
amplification includes 30-watt and 20-watt amplifiers designed to achieve high sound quality.

Digital Input

In addition to XLR and TRS phone analog input, the DM-5 is provided with digital input connectors
(coaxial and optical) that support 96 kHz sample rate and 24-bit digital audio.
Digitally input signals are reproduced faithfully through 24-bit D/A conversion, thus preventing
noise or a drop in sound quality.
You can use the monitors with a wide variety of equipment and applications through selective use of
the analog and digital settings.
Contents
USING THE UNIT SAFELY................................................................3
IMPORTANT NOTES .........................................................................4
Function and Connection ................................................................6
Funktion und Anschlüsse................................................................8
Fonction et Connection..................................................................10
Funzionamento e Connessione.....................................................12
Función y conexión ........................................................................14
Reference ........................................................................................16
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DM-5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Edirol DM-5

Summary of Contents for Edirol DM-5

  • Page 1: Table Of Contents

    30-watt and 20-watt amplifiers designed to achieve high sound quality. Digital Input In addition to XLR and TRS phone analog input, the DM-5 is provided with digital input connectors (coaxial and optical) that support 96 kHz sample rate and 24-bit digital audio.

  • Page 2: Important Safety Instructions

    CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.

  • Page 3: Using The Unit Safely

    • Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland/ EDIROL Service Center, or an authorized Roland/ EDIROL distributor, as listed on the “Infor- mation”...

  • Page 4: Important Notes

    • Before using the unit in a foreign country, consult with your retailer, the nearest Roland/EDIROL Service Center, or an authorized Roland/EDIROL distributor, as listed on the “Information” page.

  • Page 5: Maintenance

    (including padding) that it came in, if possible. Otherwise, you will need to use equivalent packaging materials. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.

  • Page 6: Function And Connection

    Function and Connection Front fig.03.e 1. HF Driver * Do not touch the diaphragm. 2. LF Driver * Do not touch the speaker cone. 3. Bass-reflex Ducts These are conduits for rich, bass-range reproduction. 4. Power Indicator Lights when power is on. 5.

  • Page 7: Precautions When Connecting And Turning On The Power

    (with digital signals). Choose the setting appropriate for your setup. * With the DM-5, there is no difference between L and R. When using the digital input connectors of two DM-5 monitors for stereo sound, the digital signal can be input to either L or R.

  • Page 8: Funktion Und Anschlüsse

    Schaltet zwischen Optical und Coaxial um. Wählen Sie hier den Anschluss des Eingangssignals. Assign-Schalter Hier legen Sie die Stereo-Position des Digitalsignals fest. Sie haben bei der Verwendung von zwei DM-5-Moni-toren die Wahl zwischen Right (rechts), L+R (links + rechts) und Left (links).
  • Page 9 Stellen Sie den „Assign“-Schalter für ein digitales Eingangssignal nach Bedarf auf „L“ oder „R“. 11. Power-Schalter Mit diesem Schalter schalten Sie die DM-5 ein oder aus. 12. Netzbuchse Hier schließen Sie das mitgelieferte Stromkabel an. Stecken Sie es fest in die Buchse, damit es sich nicht unbeabsichtigterweise lösen kann.

  • Page 10: Fonction Et Connection

    Cet interrupteur détermine l’entrée Coaxiale ou Optique. Sélectionnez le connecteur utilisé pour le signal d’entrée. Interrupteur Assign Détermine la position stéréo du signal numérique. Il permet de sélectionner Droite (Right), Gauche + Droite (L+R) ou Gauche (Left) en utilisant deux DM-5 en stéréo (en numérique).

  • Page 11: Interrupteur Power

    Sélectionnez le réglage approprié. * Avec les DM-5, il n’y a pas de différence entre la gauche et la droite. En utilisant les entrées numériques sur deux DM-5 pour la stéréo, le signal numérique peut être entré soit à droite soit à...

  • Page 12: Funzionamento E Connessione

    Funzionamento e Connessione Anteriore fig.03.i 1. Driver HF * Non toccate il diaframma. 2. Driver LF * Non toccate il cono dell’altoparlante. 3. Dotti Bass-reflex Sono condotti per una riproduzione ricca dellagamma dei bassi. 4. Indicatore Power Si illumina ad unità accesa. 5.
  • Page 13 DM-5 per il suono stereo (con segnali digitali). Scegliete l’impostazione appropriata al vostro setup. * Col DM-5, non vi e differenza tra L ed R. Usando in connettori d’ingresso digitale di due monitor DM-5 per il suono stereo, il segnale digitale puo essere immesso in L o in R (Sinistra - Destra).

  • Page 14: Función Y Conexión

    Función y conexión Parte Frontal fig.03.s 1. Altavoz de Frecuencias Altas * No toque el diafragma. 2. Altavoz de Frecuencias Bajas * No toque el cono del altavoz. 3. Conductos de reflexión de graves Estos son conductos que proporcionan una reproducción de alta calidad del registro de graves.
  • Page 15 5 para logra un sonido estéreo (con señales digitales). Seleccione la posición de acuerdo con la configuración de su equipo. * En el DM-5 no existe distinción entre izquierda y derecha. Cuando se utiliza los conectores de entrada digital de dos monitores DM-5 para logra un sonido estéreo, se la señal digital...

  • Page 16: Reference

    Sounds Unnatural, or Output Doesn’t Sound Like Stereo • Check the setting of the Assign switch (Right, L+R, or Left). The DM-5 uses an identical construction for the left and right monitors, and makes no distinction between left and right.

  • Page 17: Specifications

    Specifications System 2 Way Bi-Amplified Monitor Enclosure Bass-reflex type Cabinet 1/2” MDF, Baffle: 3/4” MDF LF Driver 120 mm (5”) Foamed polypropylene cone type, magnetically shielded HF Driver 19 mm (3/4”) soft dome type, magnetically shielded Frequency Response 68 Hz to 22 kHz (+/-3 dB) Crossover Frequency 2.3 kHz (active third order) LF Amplifier Power...

  • Page 18: Frequency Response

    Reference Dimensions fig.08.e 197 (7-3/4") Frequency Response fig.ftoku (dB) (12-1/4") (1/4") LF: max flat LF: min Frequency 261 (10-1/4") 267 (10-1/2") * Not include the Power cord. HF: max flat HF: min (Hz)

  • Page 19: Federal Communications Commission Radio Frequency Interference Statement

    This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC. FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 20: Australia/New Zealand

    Information When you need repair service, call your nearest EDIROL/Roland Service Center or authorized EDIROL/Roland distributor in your country as shown below. HONG KONG Parsons Music Ltd. 8th Floor, Railway Plaza, 39 EUROPE Chatham Road South, T.S.T, EDIROL (Europe) Ltd.
