Tools (Chapter 4)
This section contains the broadband router's Tools - Tools include Configuration tools, Firmware upgrade and Reset.
Configuration tools allow you to Backup (save), Restore, or Restore to Factory Default configuration for your Broadband
router. The Firmware upgrade tool allows you to upgrade your Broadband router's firmware. The RESET tool allows you
to reset your Broadband router.
7) Click on Quick Setup Wizard (see chapter 1) to start configuring settings required by your ISP so that you can start
accessing the Internet. The other sections (General Setup, Status Information and Tools) do not need to be
configured unless you wish to implement/monitor more advance features/information.
Select the section (Quick Setup Wizard, General Setup, Status Information and Tools) you wish to configure and
proceed to the corresponding chapter.
Chapter 1
Quick Setup
The Quick Setup section is designed to get you using the broadband router as quickly as possible. In the Quick Setup
you are required to fill in only the information necessary to access the Internet. Once you click on the Quick Setup
Wizard in the HOME page, you should see the screen below.
Step 1) Time Zone
The Time Zone allows your router to base its time on the settings configured here, this will affect functions such as Log
entries and Firewall settings.
Parameter
Set Time Zone
Time Server Address
Daylight Savings
Times From
Times to
Click on NEXT to proceed to the next page (step 2) Broadband Type.
Step 2) Broadband Type
In this section you have to select one of four types of connections that you will be using to connect your broadband
router's WAN port to your ISP (see screen below).
Note: Different ISP's require different methods of connecting to the Internet, please check with your ISP as to the type of
connection it requires.
Select the time zone of the country you are currently in. The router will set its time
based on your selection
You can manually assign time server address if the default time server dose not work
The router can also take Daylight savings into account. If you wish to use this function,
you must check/tick the enable box to enable your daylight saving configuration (below)
Select the period in which you wish to start daylight Savings Time
Select the period in which you wish to end daylight Savings Time
Description
9
