Please study these instructions carefully before installing your new Edelbrock Performer, Performer RPM, & Victor Pro Solenoids. If
you have any questions, contact our Technical Hotline at: 1-800-416-8628, 7 am to 5 pm, Monday-Friday, Pacific Standard Time
or e-mail us at edelbrock@edelbrock.com. Please fill out and mail your warranty card.
Solenoid Description
Performer Fuel
Performer Nitrous
Performer RPM Fuel
Performer RPM Nitrous
Victor Pro Fuel
Victor Pro Nitrous
Alcohol Fuel Solenoid
Solenoids are used to control nitrous and fuel flow into the engine. They each contain seals specifically made for compatibility with
nitrous oxide or fuel. The sealing materials for nitrous oxide and fuel are not interchangeable. Each solenoid has been tested to
ensure superior sealing traits, while enhancing flow through proper matching of the orifice to seal relationship.
Edelbrock Performer and Performer RPM systems offer a filter fitting for nitrous oxide. It is integral to the inlet fitting. Check this
filter often for foreign objects and contaminants, and clean when necessesary.
Edelbrock Performer systems include a canister fuel filter that is the inlet fitting. Check this filter often, and change it on at least a
yearly basis. Performer RPM systems rely on a customer supplied fuel filter capable of filtering fuel with high pressure and high flow.
NOTE: Remember to use thread sealing paste ONLY on pipe threads. DO NOT use thread sealing tape.
Solenoid Safety Information
1. Keep solenoid and fuel/nitrous lines away from exhaust components.
2. Trial fit the solenoids with all lines attached to ensure a proper fit. Solenoids may be mounted sideways or upside-down if
necessary.
Nitrous/Fuel Solenoid Installation
1. Remove old solenoid, paying close attention to wiring locations.
2. Hold the solenoid securely (such as in a bench vise), being careful not to damage the solenoid or block the inlet or outlet of the
solenoid.
3. Install the inlet fitting (blue for nitrous, red for fuel) using thread sealing paste in the "in" port of the solenoid.
4. Install the outlet fitting (blue for nitrous, red for fuel) using thread sealing paste in the "out" port of the solenoid.
5. Remove the solenoid assembly from the vise.
6. Attach the solenoid mounting bracket to the bottom of the solenoid
7. Verify desired mounting location and install the solenoid. If the solenoid mounting location is difficult to access, leave the
solenoid loose to provide access to the inlet and outlet ports.
8. Re-attach fuel and nitrous supply lines and reconnect wires from the electrical system.
10. Check for leaks.
Catalog #s 72000, 72001, 72002, 72050, 72051, 72052, 72054
Rev. 6/07 - DC/mc
PERFORMER, PERFORMER RPM, & VICTOR PRO SOLENOIDS
Catalog #s 72000, 72001, 72002, 72050, 72051, 72052, & 72054
Part Number
HP Level
#72050
Up to 200 hp
#72000
Up to 150 hp
#72051
Up to 400+ hp
#72001
Up to 300+ hp
#72052
Up to 400+ hp
#72002
Up to 500+ hp
#72054
Up to 600 hp
Edelbrock Corporation, 2700 California St., Torrance, CA 90503
Tech Line: 1-800-416-8628
Tech Fax: (310) 972-2730
E-Mail: Edelbrock@edelbrock.com
INSTALLATION AND MAINTENANCE INSTRUCTIONS
©2007 Edelbrock Corporation
Brochure #63-0453
