Installation
Setting Up the System
1.
Install the battery:
a) On the bottom of the unit, slide the battery cover slightly to the right until the tabs on the cover are
positioned directly below the notches on the unit. Then lift the cover straight up and off the unit.
b) Insert one 9-volt battery.
c) Replace the battery cover.
2.
Connect the line cord: Plug one end of the line cord into TEL LINE, located at the back of the unit,
and plug the other end of the line cord into a modular wall jack.
3.
Connect your telephone: (If you do not want to connect a telephone to the system, go to step 4)
Plug your telephone line cord into TEL SET, located at the back of the unit.
4.
Connect the power cord:
a) Plug the right-angle plug on the power cord into POWER located at the back of the unit.
b) Fit the power cord behind the strain relief tab.
c) Plug the power cord into an electrical outlet that is not controlled by a wall switch.
Use only the power cord supplied with your answering system. If you need a replacement cord, call the
National Service Center 1-800-222-3111.
Formatting Digital/Computer Chip Memory
When you connect the unit to an electrical outlet, the system automatically begins formatting digital
memory. This takes about 60 seconds.
While the system is formatting memory, the ON/OFF light flashes and the Message Window begins to
count down from 63 to 0. You cannot use any system features while the formatting routine is in progress.
When memory formatting has been completed, the ON/OFF light stops flashing and remains on. Also, CL
will blink in the Message Window to indicate that you need to set the clock.
NOTE: If you did not install a battery, or if the battery is low on power or installed incorrectly,
the LOW BATTERY light goes on. To avoid losing messages in the event of a power failure,
install a battery.
System Reset
If the system does not record messages when memory is available or otherwise malfunctions, press RESET,
located on the back of the unit.
CAUTION: When you press RESET, the system begins the memory formatting process
described earlier. Your announcements and any messages stored in memory will be erased. Also,
the Remote Access code will return to the factory setting of 10.
The RESET button is recessed to prevent your pressing it accidentally.
Answering System 1343
Installation
Answering System Operation
Remote Operation
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AT&T 1343
Summary of Contents for AT&T 1343
- Page 1 Answering System 1343 Installation Answering System Operation Remote Operation Installation Setting Up the System Install the battery: a) On the bottom of the unit, slide the battery cover slightly to the right until the tabs on the cover are positioned directly below the notches on the unit. Then lift the cover straight up and off the unit. b) Insert one 9-volt battery.
-
Page 2: Answering System Operation
Answering System Operation Setting the Clock The Clock records the day and time of each message received. The clock needs to be set when CL blinks in the window. To set the clock: Set VOLUME to the middle. Hold down CLOCK for about 2 seconds until you hear a day of the week (for example, “Sunday”), then release CLOCK. -
Page 3: Volume Control
Prepare your announcement. The maximum length of an announcement is 4 minutes. A total of about 26 minutes is available for the outgoing announcement and for all incoming messages – the shorter your announcement, the more time for incoming messages. Example for Announcement A or B: Hello. -
Page 4: Ring Select
Setting System to Answer Calls After you have recorded your announcements, the ON/OFF light should be on, indicating that the system is ready to answer calls. The Message Window shows the number of messages stored in memory (0 if no messages have been received). -
Page 5: Message Alert
NOTE: Toll Saver works only when the system is on and memory is available. Otherwise calls are answered after 10 rings. Message Window and Indicators Your system provides 2 methods of informing you about the status of the system’s operation: Message Window codes and indicator lights. -
Page 6: Saving Messages
of the first new message as it begins to play. If there are no new messages, the system announces “No new messages” and the display is blank for a few seconds. To interrupt a message, press and release STOP. To continue playing the message where you stopped, press PLAY or FWD. -
Page 7: Screening Incoming Calls
Screening Incoming Calls To screen calls, set ANNC SELECT to A or B. Adjust VOLUME so that you can hear a caller’s voice. If you decide to take a call, lift the handset of any telephone on the same line. The system will stop recording and reset to answer calls. -
Page 8: Remote Operation
Remote Operation You can use many system features when you are away form your home. To protect your privacy, most features can be used only after you enter a two-digit Remote Access code. NOTE: To enter your Remote Access code and use other remote features, you must call from a touch tone telephone. - Page 9 To interrupt playback: To interrupt message playback, press and release #. To resume playing messages at the point where you stopped, press and release 5 or 7. To resume playing at the beginning of the current message, press and release 2. To save your messages: To save messages you’ve just heard, simply hang up the telephone.
-
Page 10: Voice-Help Menu
After you hear 2 beeps, press and release 4*. The system will beep and begin to record. Speak into the telephone in a normal tone of voice. When you are finished, press and release #. The system beeps to end the recording and then plays back the new announcement automatically. - Page 11 NOTE: If the system does not beep twice after you press 0, the system’s memory is full. You must enter your Remote Access code, delete some or all of the messages, and press 0 again before the system can record any new messages. After you turn the system on, you can enter * to leave a message;...
