3Com Router Configuration Guide Addendum for V1.20
Table 1-2 Define/delete the rule matching all packets
Operation
Define the rule matching all packets
Delete the rule matching all packets
Define the class matching rule
2)
Perform the following configurations in class view.
Table 1-3 Define/delete the class matching rule
Operation
Define the class matching rule
Delete the class matching rule
Note:
This command cannot be used circularly. For example, qos class A defines the rules to match qos class
B, while qos class B cannot define a rule matching qos class A directly or indirectly.
Define the ACL matching rule
3)
Perform the following configurations in class view.
Table 1-4 Define/delete ACL matching rule
Operation
Define ACL matching rule
Delete ACL matching rule
Define the MAC address matching rule
4)
Perform the following configurations in class view.
Table 1-5 Define/delete the matching rule of a MAC address
Operation
Define MAC address matching rule
Delete MAC address matching rule
Note:
The matching rules of the destination MAC address are only meaningful for the policies in outbound
direction and the interface of Ethernet type.
Command
if-match [logic-not ] any
undo if-match [logic- not ] any
Command
if-match [ logic-not ] class class-name
undo if-match [ logic-not ] class class-name
Command
if-match [ logic-not ] acl acl-number
undo if-match [ logic-not ] acl acl-number
Command
if-match [ logic-not ] { destination-mac | source-mac } mac-address
undo if-match [logic-not ] { destination-mac | source-mac }
mac-address
5
