Installation
Mark and Elite Series Installation
This document covers the installation of the transducer and display unit
installation, which includes connecting the unit to power and installing the
unit on the bracket mount.
NOTE: Make sure you read all the installation instructions before drilling holes
in your vessel. Check the transducer cable and power wires to make sure they will
reach the desired mounting location for the display unit. If they will not reach,
you either will have to select a different mounting location for the display unit, or
Transducer Installation
One piece bracket (Recommended Tools and Supplies — not included)
Drill
1" (25mm) or 5/8" (15mm) drill bit
#29 (0.136") (3mm) drill bit
Phillips (Slotted-head) screwdriver
extend the transducer cable and /or power wires.
Marine grade above-or-below waterline sealant
Marine grade epoxy (Shoot-thru-hull install only)
Zip ties (trolling motor mount)
TMB-S bracket kit (Skimmer trolling motor mount)
2
