Dell PowerEdge 2650 Replacement Manual

Removing and replacing a system cooling fan
Hide thumbs Also See for PowerEdge 2650:

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 1

Quick Links

Download this manual See also: Service Manual, Instruction Manual
CAUTION: A CAUTION indicates a potential for property damage, personal
injury, or death.
Removing and Replacing a System Cooling Fan
Removing a Cooling Fan
CAUTION: Only trained service technicians are authorized to remove the system
cover and access any of the components inside the system. See your System
Information Guide for complete information about safety precautions, working
inside the computer, and protecting against electrostatic discharge.
NOTICE: The cooling fans are hot-pluggable. To maintain proper cooling while the system is
on, replace only one fan at a time.
Remove the cover.
1
Remove the bezel, if applicable.
a
Loosen the three thumbscrews that secure the cover to the chassis. See Figure 1.
b
Slide the cover backward and grasp the cover at both ends.
c
Carefully lift the cover away from the system.
d
Pull the fan straight up to clear the chassis. See Figure 2.
2
P/N 6Y885 Rev. A00
December 2002
06Y885A00
