Preset Channels for TV
Preset
Channel
Channel
Network
Number
Key
1
2
3
4
5
6
7
8
9
0
Preset Channels for SAT•CBL• STREAM
Preset
Channel
Channel
Network
Number
Key
1
2
3
4
5
6
7
8
9
0
To program your Preset Channels:
1. Press and hold the P key. The Power key illuminates.
Continue to hold for three seconds until you see a blink of
the Power key LED. The light remains illuminated and now
you can release the P key.
2. Press the 1 key to program your fi rst preset channel. The
POWER key fl ashes once and stays on.
•
Preset channels can be set up for satellite receivers, cable boxes, and digital
TV converters (if you've programmed the SAT•CBL•STREAM key to operate
that kind of device). Streaming players do not have preset channel capability.
•
Set up all satellite, cable, or digital converter box preset channels fi rst. Then
set up your TV channels. Jumping back and forth between them might get
confusing.
3. Press the device key for this channel.
NOTE: The device key you press in this step must be
programmed to control your device in order for this preset
channel to work. See the Programming the Remote section
for information on programming these keys to control your
devices.
4. Enter the channel number you wrote down for preset
channel number 1 in the table above. In the example, you
would press 2, then 0, then 2. The POWER key flashes after
each each keypress.
5. When you've finished entering the channel number, press
the P key to save your preset channel. The POWER key light
turns off.
NOTE: If you're programming a digital sub-channel (like
59.2), you need to press the —/INPUT key between the
regular channel and the sub-channel (for example: 5, then
9, then –/INPUT, then 2).
If you're fi nished programming your Preset Channels:
Start using the remote normally.
If you want to program more Preset Channels:
Repeat steps 1 to 5 for the next Preset Channel.
Preset Programming Notes
•
To quit programming preset channels at any time, press the
The POWER key fl ashes 4 times. No changes to the Preset keys are made.
•
When you're programming presets, the remote gives you a maximum of 15
seconds between keypresses before it leaves programming mode and goes
back to normal operation. The POWER key fl ashes 4 times (this means the
remote has not saved your presets, and you'll have to start again).
•
During preset channel programming, the remote accepts only certain
keypresses: the P key, the number keys, and the device keys. If you press any
other key on the remote during preset programming, the remote exits preset
programming without saving your changes. The POWER key fl ashes 4 times.
You will have to start programming again.
Using your Preset Channels
1. Press the TV or SAT/CBL/STREAM key.
2. Press the P key. The POWER key lights up and stays on.
3. Press the number key for the preset channel you want to
access. For example, if you want to go to the channel you
programmed as
, press 3.
While the POWER key is illuminated, the remote is in preset mode. This means
you can go straight to your preset channels—you don't have to press the P key
again. Preset mode lasts for 2 minutes after the last keypress. Here's how to use
the remote in preset mode.
To go to another preset: Press the number for that preset channel.
To go to a channel that's not a preset: Press the P key to exit preset mode.
The illuminated POWER key turns off. Then enter the channel number directly.
(You can also use the CH up and down keys.)
To exit preset mode at any time: Press the P key.
Tour of the Remote
In most cases, the keys on this remote perform
the same functions as the keys on your original
remotes once you've programmed this remote
to operate your components. Many keys on this
remote have other functions as well.
Illuminated POWER key serves as an indicator
light to provide feedback. It also turns on or off all
of the devices you've programmed this remote to
operate.
Device keys (TV, SAT•CBL• STREAM) put the
remote in the right mode to control your device.
Backlight key ( ) turns backlighting on/off.
GUIDE puts the remote in guide mode; which
makes the CH+/- VOL+/- keys serve as arrow keys;
they also access the same features as the keys on
your original remotes.
OK/ENTER key selects your on-screen or
programming choices.
The INPUT and — (dash) key has two functions:
(1) it toggles through all the TV inputs; (2) when
you're entering digital channel numbers directly,
this button lets you separate the main channel
number from the sub-channel number (such as
59.1).
Channel PRESET mode provides you the
capability to program your favorites channels on
P1-P0
EXIT•BACK
key.
If you've programmed the SAT•CBL•STREAM
key with a streaming media player, the following
number keys have special functionality with that
device:
1, 2, 3, and 4 serve as arrow keys in the player's
on-screen menus (right, left, up, and down,
respectively).
9 serves as a HOME key for the player.
EXIT•BACK goes back one screen in the player's
menus.
Actual model may vary from illustration
IMPORTANT
Because this remote controls more than one device, you must fi rst "tell"
the remote which device you wish to operate. That means, if you wish to
operate your TV, you must fi rst press the TV key to put the remote in the TV
Mode. The remote stays in that device mode until you press a different device
key. For example, if your remote is in TV Mode and you want to operate the
SAT•CBL•STREAM you must press the key to change device modes.
Backlighting
Backlight illumination helps you see the remote control keys better in the dark.
You can turn backlight illumination on or off by pressing the backlight key
( ). Backlighting stays on as long as keys are being pressed and turns off four
seconds after the last keypress. Once the backlight time has timed out, any
keypress will reactivate it. If the backlight illumination is on, and you press the
backlight key, the backlight turns off.
Advanced Functions
Master Power
Each time you press the POWER key, this remote automatically turns on and
off the devices you've programmed it to operate. This feature, called "Master
Power", is enabled by default.
To disable Master Power:
1. Press and hold the P key for 3 seconds, The Power key comes on.
2. Press VOL- to disable Master Power.
3. Press the P key to confi rm. The POWER key now turns on or off only the device
you're controlling.
To enable M
1. Press and ho
2. Press VOL+ to
3. Press the P ke
Channel Lo
Channel lock au
and 0–9 numbe
when you're in
than your TV to
To turn chann
1.
Press and h
key, use yo
time.
2.
Wait until th
both keys.
3.
Press
OK/EN
To turn chann
1.
Press and h
key, use yo
time.
2.
Wait until th
both keys.
3.
Press
OK/EN
NOTE: The Pre
feature. When
Preset Channe
Code Retri
Once you've pro
record the code
this is easy. Jus
boxes below. If
remote or if you
will need to retr
writing it down
If the codes are
your remote to
TIPS: All TV co
streaming play
To exit the Cod
If you press an
will not respon
SAT•CBL•STRE
POWER key bli
1.
Press and h
wish to retr
2.
While holdi
POWER key
three secon
3.
Release bot
4.
Starting wit
keypad in th
key to blink
code, write
5.
Repeat step
fi fth numbe
!
1
