  • Page 1 SP920P Digital Projector User Manual Welcome...

  • Page 2: Table Of Contents

    Table of contents Important safety instructions ..3 Setting the presentation timer ..34 Hiding the image ......36 Introduction ........ 6 Freezing the image......36 Projector features......6 Utilizing FAQ function ....36 Shipping contents ......7 Locking control keys.....37 Projector exterior view ....8 Operating in a high altitude Controls and functions....9 environment .........37 Adjusting the sound .....38...

  • Page 3: Important Safety Instructions

    Thank you for your purchase of this quality BenQ projector! It has been designed to provide you with an enjoyable viewing experience in various situations. For the best results, please read this manual through carefully as it is your guide through the control menus and operation.
  • Page 4 In areas where the mains voltage may Do not attempt to disassemble this projector. fluctuate or cut out, it is recommended that There are dangerous high voltages inside you connect your projector through a power which may cause death if you should come stabilizer, surge protector or uninterruptible into contact with live parts.
  • Page 5 Ceiling mounting the projector We want you to have a pleasant experience using your BenQ projector, so we need to bring this safety matter to your attention to prevent possible damage to person and property. If you intend to mount your projector on the...

  • Page 6: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Selectable dual-lamp projection capable of displaying super-bright images • Wall color correction allowing projection on surfaces of several predefined colors •...

  • Page 7: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions.

  • Page 8: Projector Exterior View

    Projector exterior view Lamp cover Front/upper side Vent (heated air exhaust) Projection lens External control panel (See page for details.) Focus ring and Zoom ring (See page for details.) Vent (cool air intake) Front IR remote sensor AC power cord inlet Adjuster feet 10.

  • Page 9: Controls And Functions

    Controls and functions Projector MODE Depending upon which input signal is selected, selects an available picture setup mode. See "Selecting a picture mode" on page 31 for details. 10. ASPECT Selects the display aspect ratio. See "Selecting the aspect ratio" on page 30 for details.

  • Page 10: Remote Control

    Remote control CONTRAST Adjusts contrast. See "Adjusting Contrast" on page for details. TEST PATTERN Displays the test pattern. See "Test Pattern" on page 45 for details. LASER Emits visible laser pointer light for presentation purposes. See "Operating the LASER pointer" on page 11 for details.

  • Page 11: Remote Control Effective Range

    15. TIMER ON Remote control effective range Activates or displays an on-screen timer based on Infra-Red (IR) remote control sensors are located on your own timer setting. See "Setting the the front and the back of the projector. The remote presentation timer"...

  • Page 12: Positioning Your Projector

    Note that a special rear projection screen and the BenQ Purchase the BenQ projector ceiling mount kit from projector ceiling mount kit are required for this your dealer to mount your projector on the ceiling.

  • Page 13: Obtaining A Preferred Projected Image Size

    BenQ has provided a table of 4:3-aspect-ratio screen sizes to assist you in determining the ideal location for your projector. There are two dimensions to consider, the perpendicular horizontal distance from the center of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset).

  • Page 14: How To Determine The Position Of The Projector For A Given Screen Size

    3.0 m (3000 mm) size screen. Be aware that these different screens have different vertical offset values. There is 3% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.
  • Page 15 Projection dimensions Refer to "Dimensions" on page 52 for the center of lens dimensions of this projector before calculating the appropriate position. Maximum zoom Minimum zoom Screen Center of lens Vertical offset Projection distance 4:3 screen diagonal Distance from screen in mm Vertical offset Feet Inches Min length...

  • Page 16: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 17: Connecting A Monitor

    Connecting a monitor If you want to view your presentation close-up on a monitor as well as on the screen, you can connect the D-SUB OUT signal output socket on the projector to an external monitor with a VGA or VGA to DVI-A cable by following the instructions below.

  • Page 18: Connecting Video Source Devices

    Connecting Video source devices This section describes how to connect the projector to Video source devices using video cables. Video cable connections are recommended for Video presentations. You can connect your projector to various Video source devices that provide any one of the following output sockets: •...
  • Page 19 Connecting a HDMI source device The projector provides a HDMI input socket that allows you to connect it to a HDMI source device like a DVD player, a DTV tuner or a display. HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, DVD players and displays over a single cable.
  • Page 20 Connecting a DVI-D source device The projector provides a DVI-D input socket that allows you to connect it to a DVI-D source device like a DVD player. DVI-D format is used to directly carry a digital signal to a digital display without signal conversion. The pure digital connection provides faster and higher image quality than an analog connection, due to the nature of the digital format.

  • Page 21: Connecting A Component Video Source Device

    Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: •...
  • Page 22 Connecting an S-Video or a composite Video source device Examine your Video source device to determine if it has an unused S-Video or Video output socket available: • If it has both sockets, use the S-Video output socket for connection as the S-Video terminal provides better picture quality than the Video terminal.

  • Page 23: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Please use the original accessories (e.g. power cable) only with the device to avoid possible dangers such as electric shock and fire.

  • Page 24: Using The On-Screen Display (Osd) Menus

    Blank Timer H. Size Panel Key Lock Digital Zoom Sleep Timer Disable Splash Screen BenQ Analog RGB MENU Exit Analog RGB MENU Exit Press MENU/EXIT twice* on the projector to highlight the SYSTEM SETUP: Basic or remote control to leave and save the menu.

  • Page 25: Utilizing The Password Function

    Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. You will be inconvenienced if you activate the password functionality and subsequently forget the password.

  • Page 26: Entering The Password Recall Procedure

    Press and hold AUTO on the projector or remote control for 3 seconds. RECALL PASSWORD The projector will display a coded number on the screen. Write down the number and turn off your projector. Seek help from the local BenQ Please write down the recall code, and contact BenQ service center to decode the number.

  • Page 27: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. When starting up, the projector automatically search for the available signals. Be sure the Quick Auto Search function in the SOURCE menu is On if you want the projector to automatically search for the signals.

  • Page 28: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with 4 adjuster feet. These adjusters change the picture height and projection angle. To adjust the projector, slightly lift the front or the back of the projector and screw the feet in or out until the picture is positioned where you want it.

  • Page 29: Correcting Keystone

    Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it by following one of these steps.

  • Page 30: Selecting The Aspect Ratio

    Selecting the aspect ratio The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio. With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal.

  • Page 31: Optimizing The Image

    Optimizing the image Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures.

  • Page 32: Fine-Tuning The Image Quality In User Modes

    Setting the User 1/User 2 mode There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/2) as a starting point and customize the settings. Press MENU/EXIT and then press until the PICTURE menu is highlighted.

  • Page 33: Selecting A Color Temperature

    Adjusting Brilliant Color Highlight Brilliant Color in the PICTURE menu and select by pressing on the projector or remote control. This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in picture. It enables a greater than 50% brightness increase in mid- tone images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors.

  • Page 34: Setting The Presentation Timer

    Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its range at 0, only pure Yellow red in the projected picture will be selected. Increasing its range GREEN will include red close to yellow and red close to magenta.
  • Page 35 Press to highlight Timer Counting Direction and select your desired counting direction by pressing Selection Description Count Up Increases from 0 to the preset time. Count down Decreases from the preset time to 0. Press to highlight Timer Audible Reminder and decide if you want to activate the sound reminder by pressing / .

  • Page 36: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can use BLANK on the projector or remote control to hide the screen image. The word 'BLANK' appears in the corner of the screen while the image is hidden.

  • Page 37: Locking Control Keys

    Locking control keys With the control keys on the projector locked, you can prevent your projector settings from being changed accidentally (by children, for example). When the Panel Key Lock is on, no control keys on the projector will operate except Power. Press or go to the SYSTEM SETUP: Basic >...

  • Page 38: Adjusting The Sound

    Adjusting the sound The sound adjustments made as below will have an effect on the projector speakers. Be sure you have made a correct connection to the projector audio input. See "Connection" on page 16 for how the audio input is connected.

  • Page 39: Setting The Lamp Mode

    Setting the lamp mode This projector is capable of dual-lamp projection and provides three lamp modes for different purposes: Lamp mode User Benefit Suitable environment • Delivering super-bright and clear images Dual-Brightest Large, well lit meeting • Suitable for high-ambient-light environments (Two lamps are used in normal •...

  • Page 40: Shutting Down The Projector

    Shutting down the projector Press Power and a confirmation message displays prompting you. If you don't respond in a few seconds, the message will disappear. Do not look into the laser light window or shine the laser light beam on yourself or others. See the warning messages on the back of the remote control prior to using it.

  • Page 41: On-Screen Display (Osd) Menus41

    On-Screen Display (OSD) Menus Menu structure Please note that the on-screen display (OSD) menus vary according to the signal type selected. Some functions are available only when certain input signals are in use. The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.
  • Page 42 Disable/5 min/10 min/15 min/20 min/25 Blank Timer min/30 min Panel Key Lock On/Off Disable/30 min/1 hr/2 hr/3 hr/4 hr/ Sleep Timer 8 hr/12 hr Splash Screen BenQ/Black/Blue Quick Cooling On/Off High Altitude Mode On/Off Mute On/Off Volume Audio Settings Power on/off ring...

  • Page 43: Description Of Each Menu

    Description of each menu FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection surface is not Wall Color white. See "Using Wall Color" on page 31 for details. There are four options to set the image's aspect ratio depending on your Aspect Ratio input signal.
  • Page 44 Sleep Timer minutes and 12 hours. Allows you to select which logo screen will display during projector start- up. The following options are available: BenQ logo, Black screen, Blue Splash Screen screen. Enables or disables the Quick Cooling function. Selecting On enables the function and projector cooling time will be shortened from a normal 90- second duration to approximately 30 seconds.
  • Page 45 FUNCTION DESCRIPTION Lamp Mode "Setting the lamp mode" on page 39 for details. Reset Lamp #1 Timer Reset Lamp #2 Timer Once the lamp is renewed, select Reset to return the corresponding lamp timer to '0'. See "Resetting the corresponding lamp timer" on page 49 Lamp Settings details.

  • Page 46: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.

  • Page 47: Extending Lamp Life

    Extending lamp life The projection lamp is a consumable item. To keep the lamp life as long as possible, you can do the following settings via the OSD menus. • Setting Lamp Mode as Dual-Reliable Compared to Dual-Brightest mode, using Dual-Reliable mode reduces system noise and power consumption. If the Dual-Reliable mode is selected, the light output for the individual lamp will be reduced.

  • Page 48: Replacing The Lamp

    This lamp contains mercury. Consult your local hazardous waste regulations to dispose of this lamp in a proper manner. • Since a pair of non-interchangeable lamps is designed for this projector, only the specified BenQ projector lamp can be used for lamp replacement. Make sure the correct lamp is purchased beforehand.
  • Page 49 Lift the handle so that it stands up. Use the handle 12. Replace the lamp cover on the projector. to slowly pull the lamp out of the projector. 13. Tighten the screw that secures the lamp cover. Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector.

  • Page 50: Indicators

    Indicators Light Status & Description POWER TEMP LAMP1 LAMP2 Power events Stand-by mode. Orange Green Powering up. Flashing Normal operation. Green The projector needs 90 seconds to cool down as it was abnormally shut down without the normal cooling Orange down process.

  • Page 51: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and There is no power from the power cable. plug the power cord into the power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 52: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Input terminals Resolution Computer input 1024 x 768 XGA RGB input D-Sub 15-pin (female) x 1 Display system DVI-D input 1-CHIP DMD Video signal input Lens F/Number S-VIDEO F=2.4 to 2.55, f=23.88 to 27.46 mm Mini DIN 4-pin port x 1 Lamp...

  • Page 53: Timing Chart

    Timing chart Supported timing for Analog RGB input Horizontal Vertical Pixel Frequency Resolution Mode Frequency (kHz) Frequency (Hz) (MHz) 31.469 59.940 25.175 VGA_60 37.861 72.809 31.500 VGA_72 640 x 480 37.500 75.000 31.500 VGA_75 43.269 85.008 36.000 VGA_85 720 x 400 31.469 70.087 28.3221...
  • Page 54 Supported timing for DVI-D and HDMI (HDCP) input Horizontal Vertical Pixel Frequency Resolution Mode Frequency (kHz) Frequency (Hz) (MHz) 720 x 400 31.469 70.087 28.3221 400_70 31.469 59.940 25.175 VGA_60 37.861 72.809 31.500 VGA_72 640 x 480 37.500 75.000 31.500 VGA_75 43.269 85.008...

  • Page 55: Other Information

    (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects. Important: The above warranty shall be void if the customer fails to operate the product in accordance with BenQ's written instructions, especially the ambient humidity must be in-between 10% and 90%, temperature in-between 0°C and 35°C, altitude lower than 4920 feet, and avoiding to operate the projector in a dusty environment.

  • Page 56: Regulation Statements

    Regulation statements FCC statement (for United States users) CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
  • Page 57 • All BenQ monitors and projectors come with user manuals on compact discs which could be easily read by commercial software such as Adobe Reader via a connected computer system. These documents are also available on the BenQ's web site (www.BenQ.com).
