Operating Instructions
Manual de instrucciones
High Defi nition Plasma Display
Pantalla de Plasma de Alta Defi nición
TH-65PF9UK
Model No.
Número de modelo.
The illustration shown is an image.
Before connecting, operating or adjusting this product, please read these instructions completely.
Please keep this manual for future reference.
La ilustración mostrada es una imagen.
Antes de conectar, utilizar o ajustar este producto, lea completamente este manual de instrucciones;
English
y guárdelo para consultarlo en el futuro en caso de ser necesario.
Español
TQB2AA0721
Advertisement
Table of Contents
Related Manuals for Panasonic 65PF9UK - TH - 65" Plasma Panel
Summary of Contents for Panasonic 65PF9UK - TH - 65" Plasma Panel
-
Page 1: Operating Instructions
Operating Instructions Manual de instrucciones High Defi nition Plasma Display Pantalla de Plasma de Alta Defi nición TH-65PF9UK Model No. Número de modelo. The illustration shown is an image. Before connecting, operating or adjusting this product, please read these instructions completely. Please keep this manual for future reference. - Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualifi ed service personnel. The lightning flash with The exclamation point within arrow-head within a triangle a t r i a n g l e i s i n t e n d e d t o is in tend ed to tell the user...
-
Page 3: Important Safety Instructions
Important Safety Instructions 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifi... -
Page 4: Table Of Contents
Dear Panasonic Customer Welcome to the Panasonic family of customers. We hope that you will have many years of enjoyment from your new Plasma Display. To obtain maximum benefit from your set, please read these Instructions before making any adjustments, and retain them for future reference. -
Page 5: Fcc Statement
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifi cations to this monitor not expressly approved by Panasonic Corporation of North America could cause harmful interference and would void the user’s authority to operate this device. -
Page 6: Safety Precautions
Safety Precautions CAUTION This Plasma Display is for use only with the following optional accessories. Use with any other type of optional accessories may cause instability which could result in the possibility of injury. (All of the following accessories are manufactured by Matsushita Electric Industrial Co., Ltd.) •... -
Page 7: Maintenance
Safety Precautions / Maintenance WARNING Do not handle the power cord plug with wet hands. Setup • Doing so may cause electric shocks. Do not place the Plasma Display on sloped or unstable surfaces. Do not do anything that might damage the power cable. •... -
Page 8: Accessories
Accessories Accessories Supplied Check that you have the Accessories and items shown Operating Remote Control Batteries for the Instruction book Transmitter Remote Control EUR7636070R Transmitter (2 × AA Size) Fixing bands × 2 AC cord Remote Control Batteries Requires two AA batteries. 1. -
Page 9: Connections
Connections When connecting the speakers, be sure to use only the optional accessory speakers. Refer to the speaker’s Installation Manual for details on speaker installation. Speakers (Optional accessories) SPEAKERS Terminals (L) SPEAKERS AC cord connection (see page 13) Terminals (R) –... -
Page 10: Pc Input Terminals Connection
Connections PC Input Terminals connection COMPUTER AUDIO PC IN R - STANDBY POWER ON INPUT MENU ENTER Conversion adapter (if necessary) Mini D-sub 15p PC cable Audio Stereo plug Connect a cable which matches the audio output terminal on the computer. Notes: •... -
Page 11: Serial Terminals Connection
JUST this unit before sending the next command. SELF Panasonic AUTO • If an incorrect command is sent by mistake, this unit will send an “ER401” command back to the computer. With the power off, this display responds to PON command only. -
Page 12: Dvi-D Connection
Connections DVI-D connection PC with DVI-D DVI-D video out video cable AUDIO (Within 5 m) DVI-D IN SLOT2 Mini-plug (M3) DVI-D Input Connector Pin No. Signal Name Pin No. Signal Name Pin Layouts T.M.D.S. data 2- T.M.D.S. data 3+ T.M.D.S. data 2+ +5 V DC T.M.D.S. -
Page 13: Power On / Off
Power ON / OFF Connecting the AC cord plug to the Plasma Display. Fix the AC cord plug securely to the Plasma Display with the clamper. (see page 9) Connecting the plug to the Wall Outlet Press the Power switch on the Plasma Display to turn the set on: Power-On. -
Page 14: Basic Controls
Basic Controls Remote control sensor Volume Adjustment Volume Up “+” Down “–” When the menu screen is displayed: “+” : press to move the cursor up INPUT MENU ENTER R - STANDBY “–” : press to move the cursor down POWER ON (see page 16) Enter / Aspect button... - Page 15 Basic Controls Standby (ON / OFF) button The Plasma Display must fi rst be plugged into the wall outlet and turned on at the power switch (see page 13). Press ON to turn the Plasma Display On, from Standby mode. Press OFF to turn the Plasma Display Off to Standby mode.
-
Page 16: On-Screen Menu Displays
On-Screen Menu Displays The MENU button on the unit can also be To PICTURE adjust menu Press to select . pressed. (see page 24) INPUT MENU ENTER PICTURE NORMALIZE NORMAL STANDARD PICTURE MENU PICTURE [ from the unit ] Each time the MENU button is pressed, the BRIGHTNESS COLOR menu screen will switch. -
Page 17: To Setup Screensaver
AUTO COLOR SYSTEM VIDEO NR 3 : 2 PULLDOWN VIDEO NR 3 : 2 PULLDOWN VIDEO NR H-FREQ. 33.8 Panasonic AUTO (4 : 3) NORMAL H-FREQ. 33.8 V-FREQ. 60.0 VIDEO NR V-FREQ. 60.0 Note: “SIGNAL” setup menu displays a different setting condition for each input signal. (see page 18) -
Page 18: Initial Selections
Initial selections Selecting the input signal Select the input signals to be connected by installing the optional Terminal Boards. Press to select the input signal to be played back from the equipment which has been connected to the Plasma Display. Input signals will change as follows: INPUT1 INPUT2... -
Page 19: Aspect Controls
• For a 1125 (1080) / 60i · 50i · 60p · 50p · 24p · 25p · 30p · 24sF, 1250 (1080) / 50i, 750 (720) / 60p · 50p signal input, the mode is set to “FULL” mode, and switching is not possible. • Panasonic AUTO can be selected only during Video signal input. • The aspect mode is memorized separately for each input terminal. -
Page 20: Adjusting Pos. /Size
AUTO SETUP H-POS POS. /SIZE function. H-SIZE • If adjusting the PICTURE V-POS / V-SIZE in Panasonic AUTO with FULL mode, the V-POS adjustment is not memorized. When exiting the mode, the screen will return to a V-SIZE former adjustment. - Page 21 Adjusting POS. /SIZE AUTO SETUP Automatically adjust H-POS / V-POS / CLOCK PHASE / DOT CLOCK and set H-SIZE / V-SIZE the standard value when RGB signal is input. Notes: • If the dot clock frequency is 162 MHz or higher, DOT CLOCK cannot be made. •...
-
Page 22: Multi Pip
MULTI PIP Press repeatedly. Each time pressing this button main picture and sub picture will be displayed as follows below. [Picture and Picture] [Picture out Picture] [Picture in Picture] Main picture Sub picture Main picture Sub picture Main picture Sub picture MULTI PIP MULTI PIP MULTI PIP... -
Page 23: Advanced Pip
Advanced PIP Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select Advanced PIP. Options Off-timer function Enable Onscreen display Initial INPUT Press to adjust the menu. Initial VOL level Off : Sets normal two screen display mode Maximum VOL level... -
Page 24: Picture Adjustments
PICTURE Adjustments Press to display the PICTURE menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by looking at the picture behind the menu. Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting. -
Page 25: Advanced Settings
PICTURE Adjustments Notes: Item Effect Adjustments • “COLOR” and “TINT” settings cannot be adjusted for “RGB/PC” and “Digital” input PICTURE Adjusts the proper picture contrast. Less More signal. • You can change the level of each function Adjusts for easier viewing of dark (PICTURE, BRIGHTNESS, COLOR, TINT, BRIGHTNESS pictures such as night scenes and... -
Page 26: Sound Adjustment
SOUND Adjustment Press to display the SOUND menu. Select to adjust each item. Press to select the menu to adjust. Select the desired level by listening to the sound. BASS SOUND Emits the original sound. STANDARD Adjusts low pitch sounds NORMALIZE NORMAL STANDARD... -
Page 27: Digital Zoom
Digital Zoom This displays an enlargement of the designated part of the displayed image. Display the “Operation Guide”. EXIT Press to access Digital Zoom. The “Operation Guide” will be displayed. During Digital Zoom, only the following buttons can be operated. [Remote control] [Unit] INPUT MENU... -
Page 28: Present Time Setup / Set Up Timer
PRESENT TIME SETUP / SET UP TIMER The timer can switch the Plasma Display ON or OFF. Before attempting Timer Set, confi rm the PRESENT TIME OF DAY and adjust if necessary. Then set POWER ON TIME / POWER OFF TIME. Press to display the SET UP menu. -
Page 29: Set Up Timer
PRESENT TIME SETUP / SET UP TIMER SET UP TIMER Display the SET UP TIMER SCREEN. Press to select SET UP TIMER POWER ON TIME / POWER OFF TIME. PRESENT TIME OF DAY 99:99 Press to set up POWER ON TIME / POWER OFF POWER ON FUNCTION TIME. -
Page 30: Screensaver (For Preventing After-Images)
SCREENSAVER (For preventing after-images) Do not display a still picture, especially in NORMAL mode, for any length of time. If the display must remain on, a SCREENSAVER should be used. SET UP Press to display the SET UP menu. SCREENSAVER MULTI DISPLAY SETUP SET UP TIMER Press to select the SCREENSAVER. -
Page 31: Setup Of Screensaver Time
SCREENSAVER (For preventing after-images) Setup of SCREENSAVER Time After selecting TIME OF DAY or INTERVAL, the relevant Time Setup will become available for selection and the Operating Time may be set. (Time cannot be set when “MODE” is “ON” or “OFF”.) SCREENSAVER SCREENSAVER SCREENSAVER... -
Page 32: Side Bar Adjust
SCREENSAVER (For preventing after-images ) SIDE BAR ADJUST side bars Do not display a picture in NORMAL mode for an extended period, as this can cause an after-image to remain on the side bars on either side of the display fi eld. To reduce the risk of such an after-image, change the NORMAL mode brightness of the side bars. -
Page 33: Reduces Power Consumption
Reduces power consumption • POWER SAVE: When this function is turned ON, luminous level of the Plasma Display is suppressed, so power consumption is reduced. • STANDBY SAVE: When this function is turned ON, power consumption of the microcomputer is reduced during power supply standby (see page 13-15), so standby power of the set is reduced. -
Page 34: Set Up For Multi Display
SET UP for MULTI DISPLAY By lining up Plasma Displays in groups, for example, as illustrated below, an enlarged picture may be displayed across all screens. For this mode of operation, each plasma display has to be set up with a Display number to determine its location. (Example) group of 4 (2 ×... -
Page 35: How To Set The Display Location Number For Each Plasma Display
SET UP for MULTI DISPLAY How to set the Display location number for each Plasma Display Press to select HORIZONTAL SCALE. MULTI DISPLAY SETUP MULTI DISPLAY SETUP Press to select “× 1”, “× 2”, “× 3”, “× 4”. HORIZONTAL SCALE ×... -
Page 36: Seam Hides Video Setting
SET UP for MULTI DISPLAY SEAM HIDES VIDEO Setting To hide joints between TVs. To show joints between TVs. Reference Suitable for moving image display. Suitable for still image display. Step 6, Page 35 ID Remote Control Function You can set the remote control ID when you want to use this remote control on one of several different TVs. Switch on the right side. -
Page 37: Set Up For Input Signals
Press ACTION ( ) button Press to exit from adjust mode. [ VIDEO ] SIGNAL 3D Y/C FILTER (NTSC) COLOR SYSTEM AUTO 3 : 2 PULLDOWN Panasonic AUTO (4 : 3) NORMAL Note: VIDEO NR When ON, this setting only affects NTSC input signals. -
Page 38: Color System / Panasonic Auto
SECAM M.NTSC NTSC Panasonic AUTO Set to “NORMAL” to view 4:3 images in an unchanged format when Panasonic AUTO is (4 : 3 ) selected. If you would like to view 4:3 images in Just format, set to “JUST”. Note: Panasonic AUTO does not function when TY-FB9BD (BNC Dual Video Terminal Board (option)) is used. -
Page 39: Sync
SET UP for Input Signals SYNC Select SIGNAL from the “SET UP” menu during RGB input signal. SET UP Press to adjust. SIGNAL COMPONENT/RGB-IN SELECT INPUT LABEL POWER SAVE STANDBY SAVE POWER MANAGEMENT AUTO POWER OFF ENGLISH ( US ) OSD LANGUAGE Press ACTION ( ) button [ RGB ]... -
Page 40: Options Adjustments
Options Adjustments Press to display the Setup menu. Press to select “OSD Language”. Press and hold until the Options menu is displayed. Press to select your preferred menu. Press to adjust the menu. Options Off-timer function Enable Onscreen display Initial INPUT Press to confi... - Page 41 Options Adjustments Options Off-timer function Enable Onscreen display Initial INPUT Initial VOL level Maximum VOL level INPUT lock Studio W/B Advanced PIP Display size Item Effect Adjustments Press button to adjust the volume when TV is turned on. Off: Sets normal volume. Initial VOL Sets your preferred volume.
- Page 42 Options Adjustments Options Button lock Remocon User level ID select Remote ID Serial ID Item Effect Adjustments MENU&ENTER Off: All the buttons at the bottom of the main unit can be used. MENU & ENTER: Button lock Locks buttons on bottom face of main unit. MENU ENTER/ Locks all the button on bottom face of main unit.
-
Page 43: Shipping Condition
Shipping condition This function allows you to reset the unit to the factory setting. Press to display the SET UP menu. Press to select “OSD LANGUAGE”. Press and hold till the SHIPPING menu is SET UP displayed. SIGNAL COMPONENT/RGB-IN SELECT INPUT LABEL POWER SAVE STANDBY SAVE... -
Page 44: Troubleshooting
Troubleshooting Before you call for service, determine the symptoms and make a few simple checks as shown below. Symptoms Checks Picture Sound Electrical Appliances Interference Noisy Sound Cars / Motorcycles Fluorescent light Volume Normal Picture No Sound (Check whether the mute function has been activated on the remote control.) Not plugged into AC outlet Not switched on No Picture... -
Page 45: Dvi-D/Component/Rgb/Pc Input Signals
DVI-D/COMPONENT/RGB/PC input signals Applicable input signals for Component / RGB, Mini D-sub 15P (Component / RGB), DVI-D ( Mark) Component / RGB Horizontal frequency Vertical frequency Signal name / Mini D-sub 15P DVI-D (kHz) (Hz) (Component / RGB) 525 (480) / 60i 15.73 59.94 ∗... -
Page 46: Specifi Cations
Specifi cations TH-65PF9UK Power Source 120 V AC, 50/60 Hz Power Consumption Power on 790 W Stand-by condition Save OFF 1.0 W, Save ON 0.8 W Power off condition 0.1 W Plasma Display panel Drive method : AC type 65-inch, 16:9 aspect ratio Screen size 56.5”... - Page 47 Limited Warranty Panasonic Broadcast & Television Systems Company or inadequate signal pickup, maladjustment of consumer Panasonic Puerto Rico, Inc. (collectively referred to as controls, improper operation, power line surge, improper “the Warrantor”) will repair this product and all included voltage supply, lighting damage, or service by anyone...
-
Page 48: Limited Warranty Statement
Broadcast & Television Systems Division 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 LIMITED WARRANTY STATEMENT Panasonic Canada Inc. (also known as PCI) warrants this product to be free of WARRANTY COVERAGE PERIOD EXCEPTIONS defects in material and workmanship under normal use during the applicable...
