Intel Desktop Board DH55PJ Product Guide
Online Support
For more information on Intel Desktop Board DH55PJ consult the following online
resources:
• Intel Desktop Board DH55PJ
• Desktop Board Support
• Available configurations for Intel
Desktop Board DH55PJ
• Supported processors
• Chipset information
• BIOS and driver updates
• Integration information

Processor

CAUTION
Failure to use an appropriate power supply and/or not connecting the 12 V (2 x 2 pin)
power connector to the Desktop Board may result in damage to the board, or the
system may not function properly.
Intel Desktop Board DH55PJ supports the Intel Core i7, and Intel Core i5, Intel
Core i3, and Intel Pentium processors in an LGA1156 socket. Processors are not
included with the Desktop Board and must be purchased separately. The processor
connects to the Desktop Board through the LGA1156 socket.
For information on supported processors for Intel Desktop Board DH55PJ, go to
http://processormatch.intel.com.
®
Intel H55 Express Chipset
The Intel H55 Express Chipset, consisting of the Intel H55 Platform Controller Hub
(PCH), provides interfaces to the processor and the USB, SATA, LPC, audio, network,
display, PCI, and PCI Express x1 interfaces. The PCH is a centralized controller for the
board's I/O paths.
14
http://www.intel.com/products/motherboard/DH55PJ/i
ndex.htm
http://support.intel.com/support/motherboards/deskt
op/DH55PJ
http://www.intel.com/products/motherboard/DH55PJ/i
ndex.htm
http://processormatch.intel.com
http://www.intel.com/products/desktop/chipsets/inde
x.htm
http://downloadcenter.intel.com/
http://www.intel.com/support/go/buildit
