1 Product Description

What This Chapter Contains
1.1 Board Differences.......................................................................................................11
1.2 Overview ....................................................................................................................12
1.3 Online Support ...........................................................................................................17
1.4 Operating System Support .........................................................................................17
1.5 Design Specifications .................................................................................................18
1.6 Processor ...................................................................................................................21
1.7 System Memory .........................................................................................................22
®
1.8 Intel 865G Chipset ....................................................................................................29
1.9 I/O Controller ..............................................................................................................41
1.10 Audio Subsystem........................................................................................................43
1.11 LAN Subsystem..........................................................................................................46
1.12 Hardware Management Subsystem............................................................................48
1.13 Power Management ...................................................................................................50

1.1 Board Differences

This TPS describes these Intel
are identical with the exception of the items listed in Table 1.
Table 1.

Summary of Board Differences

D865GBF
D865GLC
NOTE
Most of the illustrations in this document show only the Desktop Board D865GBF. When there are
significant differences between the two Desktop Boards, illustrations of both boards are provided.
®
Desktop Boards: D865GBF and D865GLC. The Desktop Boards
ATX Form Factor (11.60 inches by 9.60 inches [294.64 millimeters by
243.84 millimeters])
Six PCI bus connectors
microATX Form Factor (9.60 inches by 9.60 inches [243.84 millimeters by
243.84 millimeters])
Three PCI bus connectors
11
